Page 1
Presentation:
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
TL200DT USB
TL200DT USB
OUPUT LEVEL
-13-8-3
0dB
PUBLIC ADDRESS AMPLIFIER
USB/SD, BLUETOOTH
POWER ON
CLIP
VOLUME
USB/SD MP3 PLAYER, BLUETOOTH
/V+
/V-
MODE
RPT
DIN
G
DON
G
0
10
1
2
MIC VOLUME
SD
USB
EQ
P/P
3
TREBL
E
4
EQUALIZER
MASTER VOLUME
BASS
10
0
TL200DT USB is a public address amplifier developped for both mobile and fixed installations.
This amplifier features four balanced XLR 3p microphone + respective Euroblock terminal inputs plus two line inputs in RCA connector, low impedance (4-16Ohm)
and high impedance (100V) outputs both in screw terminals. A built-in phantom power supply with on/off push switch is available as well as a priority microphone
input in DIN 5p connector. There is also very useful Slave & REC outputs in RCA connectors, and a 2-band equalizer and MASTER level controls
As a digital audio source the TL200DT USB incorporates an MP3/WMA player that accepts files from its USB and SD ports, as well as FM radio and Bluetooth
connectivity. A blue
16*2 dot matrix screen display shows all functions available.
Solid 2U - Rack 19" enclosure construction.
Features:
Rear view:
High quality PA amplifier
Installation PA mixer-amplifier
4 Microphone inputs and 1 Line input
4-16 ohm & constant-volt. out. (70V and 100V)
Bluetooh connection
50HZ / 220VA
OUTPUT
SPK
FUSE F 6A
4/16
0-100V
MAINS
230V AC
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
To prevent electrical sh ock d o not rem ove
the cover. No user servi ceable pa rts insid e.
Refer service to q ualif ied pe rsonn el only.
PRIORITY MIC
123
MIC IN
4
5
DING DONG
(OPTIONAL)
INPUT
MIC
1
2
3
4
LINE
2
2
1
1
3
3
MIC
2
2
1
1
3
3
FM tuner and MP3 USD/SD slot
Bass and Teble tone controls
Ding-dong and Priority muting by VOX
Built-in electronic protection circuitry
Solid construction for 19” rack - 2U mounting
* PROFACTOR S.A. reserve the right to change the specification in materials or designs of its products without prior notice *
Technical specifications:
OUTPUT
SLAVE
MIC3/LINE
PHANTOM
ON
LINE
OFF
MIC
REC
MIC4/LINE
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
Type
No. of channels
RMS Power @ 8ohm
Frequency Range
T.H.D.
S/N ratio
Zones
Controls
Indicators
Inputs
Outputs
Connectors
Phantom Power
Other features
AC connector
Protections
Operating Voltage
Power consumption
Cooling
Dimensions
Weight
MOOSE is a brand or PROFACTOR S.A.
Professional
PA mixer-amplifier
4 microphone, 1 line
200W (rms)
50Hz - 14kHz, ±0.3dB
< 1.0% @ 1kHz
> 90dB @ 1kHz
No
Bass, Treble, Master, volume for MIC & LINE in
Power on, Signal and Clip
Microphone, Line
4-16 ohm, 100V
Input (XLR 3p, Euroblock), Link (RCA) & REC (RCA)
Output: touch-proof binding post
+48V DC
Ding-dong, priority MIC, MIC/LINE switch
IEC
Thermal overload, short circuit, temperature control
220~240V AC (factory configured), 50–60 Hz
220VA
Continuous speed fan, 80mm / 230V AC
2RU space, 345mm (13.58in) depth
12Kg | 26.46lb
Rua do Padrão 52, 4440-617 Valongo, PORTUGAL. Telf.: +351 224 119 160, Fax: +351 224 155 822, [email protected]
Audio module/player
Features
Auto power on
SD/card and USB ports
SD/USB individual volume control
Supports MP3/WMA
Bluetooth, two-way comm. function
Key standby function
16*2 dot matrix screen display
