MOOSE TL200D User Manual

USER’S MANUAL

MAN193_0

www.moosesound.com

PROUDLY DEVELOPED AND

MANUFACTURED IN PORTUGAL

Public address amplifier

Mixer-amplifier

TL120D & TL200D

PUBLIC

ADDRESS

ADDRESS AAMMPPLLIIFFIIEERR

DDIINNG

G

DDOONNG

G

TTRREEBBLLE

E

BASS

MASTER VOLUME

-13

-13-8-8-3-3

0dB

CLIP

VOLUME

OUPUT LEVEL

POWER ON

0010

10

MIC

MIC/LINE

VOLUME

EQUALIZER

TL120D

TL200D

1

2

3

4

Dear customer,

Thank for choosing MOOSE branded products!

MOOSE is a brand of professional audio & lighting products, proudly developed and manufactured in PORTUGAL.

In order to operate this product in a safe and reliable manner, please follow the instructions in this booklet and before operating the equipment read the instructions carefully and please note the technical information.

Our products undergo very rigorous testing under strict conditions and they are monitored continuosly during the manufacturing process. In order to guarantee the product function and safety, the original parts of the manufacturer's design must be used. If any parts other than those of the manufacturer are used, or the product is modified in any way, the user forfeits all warranty rights to claim.

MAN193_0

CAUTION

RIS K OF EL ECTRI C SH OCK. DO NOT OPE N.

To pr eve nt ele ct ric al sho ck do not remov e the cover. N o u se r se rv ice ab le p ar ts ins id e.

Refer ser vi ce to qu alified personnel only.

Introduction

www.moosesound.com 2

Caution

The light nin g flash with a rrowhead symbol w ithin an equila teral t riangle is intended to alert t he user to the p resence of u ninsulated "dangerous vo ltage" withi n the prod uct's enclosure that m ay be of su ffi cient magnitu de to consti tute a ri sk of electrical sho ck.

The exclamatio n mark within an equilateral triangle is intended to alert the user to the presence of important operatin g and maintenance instruc tions.

The ampli fie r is marked w ith t his instructi on so p le ase proc eed according ly in order to avoi d any hazard.

1. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match the values specified on the equipment.

2. If the power cord of the device is equipped with an earthing contact, then it must be connected to an outlet with a protective ground. Never deactivate the protective ground of a power cord.

3. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or before extended periods of disuse.

4. Replace fuses only with fuses of the same type and rating. If a fuse blows repeatedly, please contact an authorised service company.

5. Do not open or modify this equipment.

6. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to tripping

hazards.

7. Do not turn on the Amplifier ON before checking that all volumes to zero .

IMPORTANT: Never remove the cover, because otherwise there may be a risk of electric shock. There are no user

serviceable parts inside. Have repairs carried out only by qualified service personnel.

PA mixer-amplifier

TL120D & TL200D

www.moosesound.com 3

Manufacturers Declaration

PROPER DISPOSAL OF THIS PRODUCT

(Valid in the European Union and other European countries with waste separation)

This symbol on the product, or the documents accompanying the product, indicates that this appliance may not be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled waste disposal. Please dispose of this product separately from other waste and have it recycled to promote sustainable economic activity.

Household users should contact either the retailer where they purchased this product, or their local government office, for details on where and how they can recycle this item in an environmentally friendly manner. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal .

ENVIRONMENTAL PROTECTION AND ENERGY CONSERVATION

Energy conservation is an active contribution to environmental protection. Please turn off all unneeded electrical devices. To prevent unneeded devices from consuming power in standby mode, disconnect the mains plug.

EC DECLARATION OF CONFORMITY

The equipment marketed by MOOSE complies (where applicable) with the essential requirements and other relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional information can be requested to info@profactor.pt.

PROUDLY DEVELOPED AND MANUFACTURED IN PORTUGAL

MAN193_0

PA mixer-amplifier

TL120D & TL200D

www.moosesound.com 4

Connections and Controls

Please refer to the following scheme and instructions:

MAN193_0

1. POWER ON: Illuminated on/off switch. Before switching the system on, always adjust the volume to zero.

2. VOLUME 1: Channel 1 Volume Control.

3. VOLUME 2: Channel 2 Volume Control.

4. VOLUME 3: Channel 3 Volume Control.

5. VOLUME 4: Channel 4 Volume Control.

6. TREBLE: Master tone equalizer control - Treble.

7. BASS: Master tone equalizer control - Bass.

8. MASTER: Master Volume Control;

9. DING DONG: This Trimmer allows you control Ding Dong´s volume.

10. OUTPUT: 100V Line transformer terminal output for Speakers - respect polarity.

11. OUTPUT: Low impedance (4-16ohm) terminal output for Speakers - respect polarity.

12. MIC1: Channel 1 microphone input socket - Jack ¼’’.

13. MIC2: Channel 2 microphone input socket - Jack ¼’’.

14. MIC3: Channel 3 microphone input socket - Jack ¼’’.

15. MIC4: Channel 4 microphone input socket - Jack ¼’’.

16. MIC3 / LINE3: This switch allows you to choose between MIC3 or LINE3 Input. You can adjust Volume with

VOLUME3 Pot ( 4 ).

Main volume adjustment. Sets the relative level of input signal.

PA mixer-amplifier

TL120D & TL200D

PUBLIC ADDRESS AMPLIFIER

DING DONG

TREBLE

BASS MASTER VOLUME

-13 -8 -3 0dB CLIP

VOLUME

OUPUT LEVEL

POWER ON

0 10

MIC MIC/LINE

VOLUME EQUALIZER

TL120D

1 2 3 4

2

4

5

6

7

8

1

9

3

SLAVE

REC

MAINS

230V AC

50HZ / 150VA

FUSE F 6A

1PRIORITY MIC 2 3 4

MIC

LINE

MICLINE

PHANTOM

OFFON

MICLINE

MIC INPUT

DING DONG

123

45

(OPTIONAL)

INPUT

CAUTION

RISK OF ELECTRIC SH OCK. DO NOT OPE N.

To prevent ele ctrica l shock d o not remo ve the cover. No use r service able pa rts insi de. Refer ser vice to q ualif ied pe rsonn el only.

PROUDLY DEVELOPED AND

MANUFACTURED IN PORTUGAL

0-100V

OUTPUT

4/16

24

10

11

23

15

16

18

19

21

14

17

20

12

13

22

www.moosesound.com 5

Connection diagram

MAN193_0

PA mixer-amplifier

TL120D & TL200D

4 - 16ohm

100V

YOU GET MAXIMUM OUTPUT POWER WITH 4Ohm

100V

8Ohm

S SPEAKER´S POWER = AMPLIFIER RATED POWER

In order to ensure the right procedure, please folow as described:

1 - Verify that all Volume Control Pots ( 2 - 5 / 8 ) are at their minimum value ( 0 );

2 - Connect the Mains Supply Cable ( 24 );

3 - Connect all Microphones and Devices that will be working with TL120D/TL200D to their respective Inputs

just like next page´s picture;

4 - Connect the Speakers. If you have Low Impedance Speakers then you must connect them to Terminals ( 11 ). In case your Speakers have 100V Line Transformer then you must connect them to Terminals ( 10 ), always respecting polarity;

5 - Connect the Amplifier applying on the On/Off Power Switch ( 1 );

6 - Adjust Volumes and Equalization;

Your Amplifier is ready to start working. If something wrong occurs you must turn off the Amplifier and verify all connections and steps again.

17. LINE 3: Signal Input to connect a CD Player or an AM/FM Transmitter ( Radio ).

18. LINE 4: Signal Input to connect a CD Player or an AM/FM Transmitter ( Radio ).

19. MIC4 / LINE4: This switch allows you to choose between MIC4 or LINE4 Input. You can adjust volume through

front panel volume pot ( 5 ).

20. SLAVE:

21.

22. PHANTOM: This switch allows you to connect/disconnect Phantom Power supply.

23. PRIORITY MIC: Input Socket for connection of a Priority Mic.

Signal output in RCA for connection of another device such as an amplifier.

REC: Signal output in RCA for connections of a recorder device.

24. MAINS IN: Power socket with fuse holder, AC 230V - 50~60Hz. Replace the fuse only with a fuse of the same type and rating. If the fuse blows repeatedly, please contact an authorised service company.

Connections and Controls

PRI ORI TY

MIC

MIC 1

MIC 2

REC ORD ER

AMP LIF IER

CD

LINE 3

LINE 4

MIC 4

MIC 3

SLAVE

REC

MAINS

230V AC

50HZ / 150VA

FUSE F 6A

1PRIORITY MIC 2 3 4

MIC

LINE

MICLINE

PHANTOM

OFFON

MICLINE

MIC INPUT

DING DONG

123

45

(OPTIONAL)

INPUT

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OP EN.

To prevent electri cal sho ck do not re move the cover. No user serv iceable p arts in side. Refer service to qual ified perso nnel on ly.

PROUDLY DEVELOPED AND

MANUFACTURED IN PORTUGAL

0-100V

OUTPUT

4/16

www.moosesound.com 6

MAN193_0

PA mixer-amplifier

TL120D & TL200D

Dimensions

Unit: mm (mi limete rs)

Technical specifications

MODE L TL12 0D TL20 0D

TYPE Public address mixer-amplifier Public address mixer-amplifier

POWER OUTPUT (RMS) 120W 200W

FREQUENCY RANGE 50Hz - 14kHz 50Hz - 14kHz

T.H.D. (20Hz - 20kHz) < 1% @ 1kHz < 1% @ 1kHz

S/N RATIO > 90dB @ 1kHz > 90dB @ 1kHz

ZONES No No

CONTROLS Bass, Treble, Master, volume for MIC and LINE in

INDICATORS Power on, Signal and Clip Power on, Signal and Clip

INPUTS Microphone and Line Microphone and Line

OUTPUTS

CONNECTORS

PHANTOM POWER

OTHER FEATURES

PROTECTIONS

OPERATING VOLTAGE

POWER CONSUMPTION

COOLING

4-16ohm, 100V 4-16ohm, 100V

Input in 6.3mm Jack, Link in RCA & Output: touch-proof binding post, REC in RCA

+48V DC +48V DC

Ding-dong, priority MIC, MIC/LINE switch

Short circuit, thermal overload Short circuit, thermal overload

230V AC (factory config.), 50~60Hz

150VA 220VA

Continuously speed fan, 80mm / 230V AC

DIMENSIONS (WxDxH) 2RU space, 345mm depth 2RU space, 345mm depth

WEIGHT 7Kg 9Kg

484

430

88

PUBLIC

ADDRESS

ADDRESS AAMMPPLLIIFFIIEERR

DDIINNG

G

DDOONNG

G

TTRREEBBLLE

E

BASS

MASTER VOLUME

-13

-13-8-8-3-3

0dB

CLIP

VOLUME

OUPUT LEVEL

POWER ON

0010

10

MIC

MIC/LINE

VOLUME

EQUALIZER

TL120D

TL200D

1122334

4

SLAVE

REC

MAINS

230V AC

50HZ / 150VA

FUSE F 6A

11PRIORITY MIC

PRIORITY MIC223344

MIC

LINE

MIC

LINE

PHANTOM

OFF

OFFONON

MIC

LINE

MIC INPUT

DING DONG

1

2

3

445

5

(OPTIONAL)

INPUT

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

To prevent electrical shock do not remove

the cover. No user serviceable par ts inside.

Refer service to qualifie d personnel only.

PROUDLY DEVELOPED AND

MANUFACTURED IN PORTUGAL

PROUDLY DEVELOPED AND

MANUFACTURED IN PORTUGAL

0-100V

OUTPUT

4/16

www.moosesound.com

PROUDLY DEVELOPED AND

MANUFACTURED IN PORTUGAL

PROFACTOR S.A

Rua do Padrão 52

4440-617 Valongo

PORTUGAL

Telf.: +351 224 119 160

Fax: +351 224 155 822

info@profactor.pt

MOOSE is a brand or PROFACTOR S.A.
