RADIAL84
www.moosesound.com
INSTALLATION SPEAKER
Installation Instructions
Dear customer,
Thank you for choosing MOOSE products!
To ensure this product is installed properly, please read these instructions carefully before you begin. This high
quality speaker is prepared to provide many years of service but can be damaged by improper handling and/or
installation. Be sure your installation conforms to local codes. This MOOSE product is proudly developed and
manufactured in PORTUGAL - EUROPE (EU).
126
Technical specifications
Acoustical
1186
Configuration
Power handling capacity
LOW/MID freq.
Frequency response
Horinzal coverage angle
Vertical coverage angle
SPL (1W/1kHz)
High impedance input
Public address column speaker
8x 3" + 4x 4" rubber cone woofers
100V line transformer
90W rms
100Hz - 18kHz
aprox. 180°
30°
98dB @ 1m
Physical
Cabinet
Grille
Color
Hardware
Dimensions
Weight
Extruded aluminium construction
Custom perforated metal grille
Black or white textured powder coating
C-sup M for wall mounting
126x115x1186mm
PRE INSTALLATION
Unpack the speaker.
Take a moment to check the fixture to make sure there is no damage. Verify that you have all the necessary tools, fittings
and connection hardware to complete the installation and connection. The Speaker is supplied with the wall mount bracket
and 4 screws. Provide suitable structural support to fully support the speaker.
INSTALLATION
STEP 1: Set the location of the Speaker on the wall where is to be installed.
17Kg
STEP 2: Mark the location of the bracket holes using the 1:1 scaled diagram/mould (figure 1)
STEP 3: Drill 6mm holes and then screw brackets on the wall with the supplied screws. First fasten upper screws in bracket
only to support the weight.
STEP 4: After the Speaker is installed and well fixed to the wall using the 4 screws supplied it is possible to connect the
signal cable to the high impedance 100V line input respecting polarity (+/-).
MOOSE is a brand or PROFACTOR S.A.
Rua do Padrão 52, 4440-617 Valongo, PORTUGAL. Telf.: +351 224 119 160, Fax: +351 224 155 822, info@profactor.pt
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
RADIAL84
www.moosesound.com
INSTALLATION SPEAKER
Installation Instructions
FIGURE 1
SCALE 1:1
