M10, M12 & M15

Passive stage monitors

MADE IN

PORTUGAL

100%

EUROPEAN

MAN175_1

USER’S MANUAL

M10, M12 & M15

Passive stage monitors

Introduction

Dear customer,

Thank for choosing MOOSE branded products!

MOOSE is a brand of professional audio & lighting products, proudly developed and manufactured in
PORTUGAL.

In order to operate this product in a safe and reliable manner, please follow the instructions in this booklet and
before operating the equipment read the instructions carefully and please note the technical information.

Our products undergo very rigorous testing under strict conditions and they are monitored continuosly during the
manufacturing process. In order to guarantee the product function and safety, the original parts of the
manufacturer's design must be used. If any parts other than those of the manufacturer are used, or the product is
modified in any way, the user forfeits all warranty rights to claim.

Caution

1. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match

the values specified on the equipment.

2. If the power cord of the device is equipped with an earthing contact, then it must be connected to an outlet
with a protective ground. Never deactivate the protective ground of a power cord.

3. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or before
extended periods of disuse.

4. Replace fuses only with fuses of the same type and rating. If a fuse blows repeatedly, please contact an
authorised service company.

5. Do not open or modify this equipment.

6. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to tripping

hazards.

7. Do not turn on the Amplifier ON before checking that all volumes to zero .

IMPORTANT: Never remove the cover, because otherwise there may be a risk of electric shock. There are no user

serviceable parts inside. Have repairs carried out only by qualified service personnel.

The lightnin g flash with arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to constitute a risk o f
electrical shock.

The exclamation mark within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions.

RIS K OF EL ECTRI C SH OCK. DO NOT OP EN.

CAUTION

The amplifie r is marked with this instruction so please
proceed accordingly in order to avoid any hazard.

To pr event e lec tr ic al sh oc k do not rem ove
the cov er. No us er se r vi cea bl e p ar ts in si de .

Refer ser vice to qu al ified personnel only.

www.moosesound.com 2

MAN175_1

M10, M12 & M15

Passive stage monitors

Manufacturers Declaration

PROPER DISPOSAL OF THIS PRODUCT

(Valid in the European Union and other European countries with waste separation)

This symbol on the product, or the documents accompanying the product, indicates that this appliance may not
be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled
waste disposal. Please dispose of this product separately from other waste and have it recycled to promote
sustainable economic activity.

Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an environmentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal .

ENVIRONMENTAL PROTECTION AND ENERGY CONSERVATION

Energy conservation is an active contribution to environmental protection. Please turn off all unneeded electrical
devices. To prevent unneeded devices from consuming power in standby mode, disconnect the mains plug.

EC DECLARATION OF CONFORMITY

The equipment marketed by MOOSE complies (where applicable) with the essential requirements and other
relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional
information can be requested to [e-mail].

PROUDLY DEVELOPED AND MANUFACTURED IN PORTUGAL

www.moosesound.com 3

MAN175_1

Connections and Controls

Please refer to the following scheme and instructions:

M10 Side panels

Side panelsM12

Side panels

M15

M10, M12 & M15

Passive stage monitors

M15

Stage monitor

Power

450W rms

8Ohm

Impedance

INPUT THRU

IN/THRU

+1 -1

1

PROUDLY DEVELOPED
AND MANUFACTURED
IN PORTUGAL

PIN
SIGNAL

EXPOSURE TO HIGH
SOUND PRESSURE LEVELS
MAY CAUSE A PERMENENT

2

GROOVE

2-way Stage monitors

CAUTION

RISK OF ELECTR IC SHOCK . DO NOT OPEN.

To prevent elect rical s hock d o not r emove
the cover. No use r serv iceabl e part s insid e.
Refer servi ce to qu alifie d pe rsonn el o nly.

PROUDLY DEVELOPED
AND MANUFACTURED

OUTPUT/LINK

PIN
SIGNAL

IN PORTUGAL

2

+1 -1

1. INPUT: Speakon compatible input.

2. THRU: Speakon compatible output (parallel wired with Speakon compatible input 1+/1-). You can use one of

the two THRU/LINK outputs available.

Technical specifications

MODE L M10 M12 M1 5

TYPE 2-way passive monitor

ENCLOSURE DESIGN Wedged cabinet

Bass reflex

POWER OUTPUT (AES/PEAK) 360W / 900W 360W / 900W 410W / 1100W

FREQUENCY RANGE 75Hz - 18kHz 68Hz - 18kHz 50Hz - 18kHz

NOMINAL IMPEDANCE 8Ohm 8Ohm 8Ohm

TRANSDUCER TYPE 10" MF + 1" HF 12" MF + 1" HF 15" MF + 1" HF

DISPERSION 90°x60° rotatable horn

CROSSOVER FREQUENCY 2000Hz 2000Hz 2000Hz

MAX. S.P.L. (PEAK) 125dB @ 1m 127dB @ 1m 129dB @ 1m

CONSTRUCTION 15mm birch plywood with polyurea coating

GRILLE Custom perforated metal grille with acoustic foam

INSTALLATION, RIGGING, FLYING 4 rubber feet, Ø35mm pole mount socket

DIMENSIONS (WxDxH) 620x320x490mm

24.41x12.60x19.29in

WEIGHT 17Kg

37.48lb

660x350x540mm

25.98x13.78x21.26in

20Kg

44.09lb

750x350x540mm

29.53x13.78x21.26in

22Kg

48.5lb

www.moosesound.com 4

MAN175_1

Dimensions

M10

M10, M12 & M15

Passive stage monitors

320mm

M12

M15

490mm

620mm

Unit: mm (m ilime ters)

PROFACTOR S.A., all right s reserved. The tech nical data and the funct ion al produ ct characte ris tics can be subject
to mod ifi cations. The photocopying, the translation, and a ll other forms of co pying of f rag ments or of the integrlity
of this user's ma nua l is prohi bited.

www.moosesound.com 5

MAN175_1

MOOSE is a brand or PROFACTOR S.A.

PROFACTOR S.A

Rua do Padrão 52
4440-617 Valongo
PORTUGAL
Telf.: [phone]
Fax: [phone]
[e-mail]
