Presentation:
The The GROOVE series stage monitors are not just powerful, accurate, compact but
beautifully designed. The series has been engineered to deliver a complete sound
reinforcement solution to fulfil the highest demands of audio professionals for both
permanent installation and rental production markets.
The GROOVE M10 stage monitor incorporates a 10" (2" VC) LF loudspeaker that
combines excellent linearity with good sensitivity and power handling characteristics
together with a 1” (1.73in) compression driver coupled to a CD rotatable (90°x60° and
60°x90°) horn and an internal passive crossover network resulting in a surprising sonic
performance inside a compact package.
To make it flexible, there are M8 and M10 inserts for wall and truss mounting.
As a high performance stage monitor, the GROOVE series is suited to sound
reinforcement applications such as front of house, floor monitor, sidefill monitoring
small and medium sized stages as well as distributed systems.
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
M10
Features:
Multipurpose 2-way stage monitor
Bass reflex wedged enclosure
10" (2in VC) MF + 1" (1.73in VC) HF EU transducers
User-rotatable CD horn 90°x60° for ideal dispersion
2x NL4 parallel-connected
Prepared for wall and Truss mounting
Elegant looking professional enclosure
Rugged and durable 15mm birch plywood, polyurea coating
Technical specifications:
Acoustical
Type
Enclosure design
Power rating (RMS/Peak)
Frequency range
Nominal impedance
Transducer type
Dispersion
Crossover frequency
SPL (1W/1kHz)
Connector
2-way passive stage monitor
Wedged cabinet - bass reflex
360W / 900W
80 - 19kHz (10dB)
8 ohm
10" MF (2in VC) EU transducer
1" HF driver (0.98in VC) EU transducer
CD horn, 90°x60° and 60°x90° user-rotatable
2000Hz
122dB @ 1m
2x NL4 parallel-connected
610 [24.02]
330 [12.99]
425 [16.73]
Dimensions in mm [in]
* PROFACTOR S.A. reserve the right to change the specification in materials or designs of its products without prior notice *
Mechanical
Enclosure
Grille
Color
Hardware
Dimensions (WxDxH)
Weight
MOOSE is a brand or PROFACTOR S.A.
15mm birch plywood, rugged polyurea coating
Custom perforated metal grilles w/ acoustic foam
Black or white textured
4 rubber feet
Side handles, 4x M8 inserts + 2x M10 inserts
Prepared to fit a ‘’U’’ bracket
610x425x330mm | 24.02x16.73x12.99in
18Kg | 39.68lb
