MOOSE LOUD+ SYSTEM MOOSE_LOUD_sp.pdf

Presentation:
Each "side" of this active line array system compromises four mid/high passive array elements each loaded with a 2x 5" (1.26in VC, rubber surround) MF woofers + 1" (0.98in VC) HF compression driver coupled to a wave guide horn. All 4 passive satellites are driven by an active bass reflex designed subwoofer that features a 15" LF (4in) EU transducer.
The latest in Class D amplifier technology is incorporated with a 2-channel Class D amplifier ensuring ultra-quiet, highly efficient and low distortion output enhanced by a DSP for real time operation and 4 user-selectable presets according to different environments and music styles providing an acoustically perfect transition between the subwoofer and the mid/high array assembly. The class D amplifier is prepared for 85-264Vac global mains voltage (SMPS with PFC) and features various electronic protections to guarantee the use of the speaker system in safe operation.
Each enclosure comes with an integrated steel rigging flyware to couple with two metal frames: one to fly or ground stack the system and another to use it on a Ø35mm pole mount.
With high quality components and high-tech amplifier LOUD+ achieves extremely high performance with tight, rock-solid low end, with smooth, detailed highs and a well-defined midrange making this system the ultimate in "all-in-one" complete and convenient "plug-n-play" PA system solution for small to medium size applications.
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
LOUD+
Features:
Compact self-powered line array system Suited for small and medium size venues 15" (4in VC) LF active subwoofers 2x 5" (1.26in VC) MF rubber surround woofer 1" (0.98in VC) HF driver, LOUD205+ passive satellite Subwoofers driven by a 2ch Class D amplifier Built-in DSP with 4 selectable presets Universal 85-264Vac mains supply Prepared for ground stacking and flying configurations Rugged and durable polyurea coating Great flexibility in shaping array curvature
Technical specifications:
Acoustical
Type Enclosure design
Power rating (RMS/Peak)
Frequency range Nominal impedance Transducer type
Dispersion
Crossover frequency
SPL (1W/1kHz)
Active line array system Bass reflex [LOUND15+] Bass reflex [LOUD205+] 1000W / 1400W [LOUD15+] 200W / 380W [LOUD205+] 40 - 19kHz (-6dB) N/A 15" (4in VC) LF woofer [LOUD15+] 2x 5" (1.26in VC) MF woofer [LOUD205+] 1" (0.98in VC) HF driver [LOUD205+] EU transducers 120° horizontal Array splay dependant vertical coverage DSP controlled with selectable presets 48KHz sampling frequency 24 bit AD/DA converter 132dB @ 1m
Mechanical
Enclosure
Grille Color Hardware
Dimensions (WxDxH)
Weight
* PROFACTOR S.A. reserve the right to change the specification in materials or designs of its products without prior notice *
15mm birch plywood [LOUD15+] 15mm birch plywood [LOUD205+] Rugged polyurea coating Custom perforated metal grilles w/ acoustic foam Black or white textured 4 rubber feet [LOUD15+] 1 side handle [LOUD15+] Integrated steel rigging flyware FL-LOUD15+, flying frame FS-LOUD205+, ground stacking frame WBLOUD205+, wall mount bracket 530x615x430mm / 20.87x24.21x16.93in [LOUD15+] 530x250x170mm / 20.87x9.84x6.69in [LOUD205+]
36.5Kg / 80.47lb [LOUD15+]
8.5Kg / 18.74lb [LOUD205+]
MOOSE is a brand or PROFACTOR S.A.
Zona Industrial de Campo, Rua Nova da Costa 55-71, 4440-049 Valongo, PORTUGAL, Telf.: +351 224 119 160, info@profactor.pt
Technical specifications:
Amplifier Module
Type Output Power
Internal Processing
Audio input/output
Cooling Indicators Controls AC Mains AC Mains connector Protections
Two channel Class D 800W + 400W Expandable system Fully programmable DSP 48KHz sampling frequency 24 bit AD/DA converter XLR/Jack combo connector XLR/M 3p Cooling by convection Power, signal/preset, status, clip Master level control, 4 selectable presets SMPS with PFC, 85-264Vac universal mains Neutrik® powerCON, Power-in/Power-out Over current, short circuit, thermal, DC and HF
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
LOUD+
Dimensions:
530 [20.87]
530 [20.87]
615 [24.21]
430 [16.93]
* PROFACTOR S.A. reserve the right to change the specification in materials or designs of its products without prior notice *
250 [9.84]
170 [6.69]
MOOSE is a brand or PROFACTOR S.A.
Dimensions in mm [in]
