Presentation:
The BASS series offers a professional and compact passive and active subwoofers
range becoming the perfect choice for sound reinforcement challenges demanding
high SPL and natural sounding bass response designed to enhance the ultra-low bass
of an existing PA system.
This G15 is built on a Reflex Loaded design equipped with a 15" (4in) LF transducer
capable of delivering 1200W AES (4800W peak), chosen to provide clean, undistorted
low frequency reproduction at very high sound pressure levels and able to withstand
high power levels without damage.
To ensure a perfect matching and avoid undesired vibrations during high SPL
operation the enclosures are constructed in 18mm reinforced birch plywood with a
rugged and durable polyurea coating.
The ergonomic carrying handles permit a secure grip from all sides and convenient
transport and all models are prepared to accept 4 swivel castors with 16x M6 inserts
on the back. Punch and bass sensation do not have to be incompatible factors and this
BASS series truly is a great example.
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
G15
Features:
Bass reflex subwoofer
1x 15" (4in VC) LF EU transducer
1200W AES / 7000W Peak power
2x NL4 connected in parallel
Versatile, compact and coherent subwoofer
Made for an impact bass
Recesses on the top to facilitate the stacking
Rugged and durable 18mm birch plywood construction
Powder coated custom perforated steel grille
Technical specifications:
Acoustical
Type
Enclosure design
Power rating (RMS/Peak)
Frequency range
Nominal impedance
Transducer type
Crossover frequency
SPL (1W/1kHz)
Connector
Compact passive subwoofer
Reflex loaded
1200W / 7000W
32 - 250Hz (-10dB)
8Ohm
1x 15" LF (4in VC) EU transducer
35Hz Butterworth 18dB (low cut filter)
132dB @ 1m
2x NL4 speakon parallel-connected
590 [23.23]
440 [17.32]
590 [23.23]
Dimensions in mm [in]
* PROFACTOR S.A. reserve the right to change the specification in materials or designs of its products without prior notice *
Mechanical
Enclosure
Grille
Color
Hardware
Dimensions
Weight
MOOSE is a brand or PROFACTOR S.A.
18mm birch plywood, rugged polyurea coating
Custom perforated metal grilles w/ acoustic foam
Black or white textured
4 rubber feet, 2 side handles
Ø35mm pole mount socket
Prepared for stacking
590x590x440mm | 23.23x23.23x17.32in
35Kg | 77.16lb
Zona Industrial de Campo, Rua Nova da Costa 55-71, 4440-049 Valongo, PORTUGAL, Telf.: +351 224 119 160, [email protected]
