Presentation:
Super-efficient class D technology amplifiers developed to deliver high output power
and proven reliability for touring and portable applications.
The DLINE series amplifiers are designed to meet the specialized needs of sound
contractors. Four models have been developed to deliver high output power, wide
dynamic range, low distortion, high efficiency and ease of use for a wide variety of
sound reinforcement applications.
There are two models of 2-channel plus two models of 4-channel all prepared to
work @.2ohm with front panel LEDs to monitor power, signal and clipping at a glance
and parallel XLR/M and XLR/F connectors for simple loop-through connectivity.
The series applies classical PWM circuit design and new technology protection circuit,
high stability and usability, high efficiency SMPS and big current storage, intelligent
limiter, multi-protection functions built for demanding environments packed in a
Rack 19" – 1U lightweight enclosure. The DLINE series amplifiers are powerful,
affordable, rugged and reliable, a superior solution to any portable or permanent
installation.
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
DQ2000
Features:
High quality and reliable class D amplifier series
Classical PWM circuit design and new technology
Output power @ 8ohm: 4x 350W
Output power @ 4ohm: 4x 500W
XLR/F input connectors and Speakon 4p outputs
Modular design, no interference between channels
Front panel LEDs to monitor power, signal and clipping
Integrated protection circuitry to protect amplifier and speakers
Solid construction for 19" Rack - 1U lightweight enclosure
Technical specifications:
Type
No. of channels
RMS Power @ 8ohm
RMS Power @ 4ohm
Frequency Range
T.H.D.
Damping Factor
Crosstalk
S/N ratio
Input sensitivity
Controls
Indicators
Inputs
Outputs
AC connectors
Protections
Operating Voltage
Power consumption
Cooling
Dimensions
Weight
Professional class D amplifier
4
4x 350W (1kHz / 0.1%)
4x 500W (1kHz / 0.1%)
20Hz - 20kHz, ±0.3dB
< 0.3%
> 800 (8Ω, 20Hz~200Hz)
> 75dB
> 105dB
20kΩ (balanced), 10kΩ (unbalanced)
Mains switch (on/off), 4x volume, Power on: Green; Signal: Green;
Clip/Protect: Red (1 per channel)
XLR/F 3p connectors
Speakon 4p connectors
PowerCON AC input
Thermal overload, DC protection, short circuit, clip limiter, temperature control
220~240V AC (factory configured), 50–60 Hz
2000VA
Continuous speed fan, automatic
1RU space, 375mm depth (14.76in)
8Kg | 17.64lb
482 [18.98]
375 [14.76]
Dimensions in mm [in]
