Presentation:
The DUAL C15 is a trapezoidal-wedged shape multipurpose speaker for use in PA
systems or as an on-stage monitor that features a 15" low frequency transducer of
2.5 in VC capable of delivering excellent dynamic range, flat frequency response
and a very low distortion figure which combined with 1" (1.73in VC) HF driver result
in a superb sound and exceptional performance.
This C15 is prepared to be used as a stage monitor or as a pole mount speaker as
the 90°x60° and 60°x90° CD horn can be rotated for vertical and horizontal
operation in order to achieve the ideal sound dispersion.
DUAL rugged enclosures are manufactured using 15mm birch plywood painted in
hard-wearing and durable polyurea coating, being prepared to be used in flown
configuration through 3x M8 inserts and in pole mount thanks to a Ø35mm socket
with 0°/5° tilt. This range of Speakers offers exceptional performance making it
the perfect professional solution for clubs, bands and DJs and anywhere there is a
need for dependable high performance multipurpose loudspeakers.
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
C15
Features:
Multipurpose 2-way passive speaker
Bass reflex trapezoidal enclosure
15" (2.5in VC) MF + 1" (1.73in VC) HF EU transducers
2x NL4 connected in parallel
User-rotatable CD horn 90°x60° for ideal dispersion
Ø35mm pole mount with 0° and 5° tilt
Integrated rigging system with 3x M10 inserts
Rugged and durable 15mm birch plywood
Powder coated custom perforated steel grille
Technical specifications:
Acoustical
Type
Enclosure design
Power rating (RMS/Peak)
Frequency range
Nominal impedance
Transducer type
Dispersion
Crossover frequency
SPL (1W/1kHz)
Connector
2-way passive multipurpose speake
Bass reflex, trapezoidal
410W / 1100W
50 - 18kHz
8 ohm
1x 15" LF (2.5in VC) EU transducer, front loaded
1x 1" HF (1.73in VC) EU transducer
CD horn, 90°x60° and 60°x90° user-rotatable
2000Hz
129dB @ 1m
®
2x NL4 in parallel
430 [16.93]
690 [27.17]
420 [16.54]
C15
Multipurpose speaker
410W / 8Ohm
PIN
INPUT
+1/-1
PIN
LINK
+1/-1
MADE IN
PORTUGAL
Dimensions in mm [in]
* PROFACTOR S.A. reserve the right to change the specification in materials or designs of its products without prior notice *
Mechanical
Enclosure
Grille
Color
Hardware
15mm birch plywood, rugged polyurea coating
Custom perforated metal grilles w/ acoustic foam
Black or white textured
Ø35mm pole mount with 5° tilt
3x M10 flying points
"U" bracket for horizontal and vertical installation
Dimensions
Weight
430x420x690mm | 16.93x16.54x27.17in
23Kg | 50.71lb
MOOSE is a brand or PROFACTOR S.A.
Zona Industrial de Campo, Rua Nova da Costa 55-71, 4440-049 Valongo, PORTUGAL, Telf.: +351 224 119 160, [email protected]
