Moore Industries DCA S, DCA H2, DCA H1, DCA D, DCA L2 User Manual

May 2016

DCA

Direct Current Alarm

USER’S MANUAL

No. 192-701-00 K

© 2012 by Moore Industries-International, Inc.

Table of Contents

Introduction 1

Description 1

Calibration 4

Installation 19

Maintenance 22

HR.

DELIVERY

48

United States/Canada

TOLL FREE

1-800-999-2900

United Kingdom

FREE PHONE

0800 525107

Australia

TOLL FREE

008 251928

Ask for the STAR Center

16650 Schoenborn Street
Sepulveda, California 91343, U.S.A.
Tel: [phone] • Tlx: 65-1322
FAX: [phone]
CONNECT (MacNet): MIISEPULVEDA

1 Lloyds Court, Manor Royal, Crawley
W. Sussex RH10-2QU, United Kingdom
Tel: [phone] • Tlx: 87667
FAX: [phone]

3/18 Resolution Drive, Caringbah
New South Wales 2229, Australia
Tel: [phone] • Tlx: 790-75914
FAX: [phone]

Moore Industries’ STAR Center has a
wide variety of quality instrumentation
in stock and ready to ship.

• Signal Transmitters

• Temperature Transmitters

• P/I and I/P Converters

• Isolators and Converters

• Indicators and Displays

• Alarm Trips

• Integrators and Totalizers

• Power Transducers

• Instrument Power Supplies

• Racks, Rails and Enclosures

Most instruments can be customized
to meet your needs. Even then, you’ll
never have to wait more than a few days.

Moore Industries

CENTER

* Support, Technical Assistance, and Repair (our Quick-Ship Facility)

*

Page 1

DCA

Introduction

Moore Industries’ Direct Current Alarm (DCA) is a
highly versatile, fully adjustable device that is factory­configured to accept either current or voltage input.
The unit’s internal relays are tripped when input
deviates from a customer-set “safe” range defined by
adjustable trip points. The DCA is ideal for use in an
alarm system, where it may be used to activate a
warning device, or to drive an analog indicator.

This manual provides a brief description of the DCA,
including its physical characteristics and options; a
table of performance and operating specifications; a
set of procedures for calibrating the unit; instructions
for installation, including physical mounting and
electrical connections; and finally, information on
basic maintenance and troubleshooting.

Notes, Cautions, and Warnings are included as a
means of identifying those practices that may present
unnecessary inconveniences (notes), result in dam­age to the unit (cautions), or cause injury (warnings).

bination of single, dual, high, low, fail-safe, or non-fail­safe alarm relays. The following paragraphs describe
each of these configurations.

High Alarm/Low Alarm. A DCA configured as a high
alarm is tripped when the input increases, and
reaches a customer-set trip point. A low alarm unit is
tripped by a decreasing input that drops below a
customer-set trip point.

Figure 1 illustrates the concept.

Fail-safe/Non-fail-safe. A fail-safe unit’s relay is
energized when input is within a “safe” range, i.e. is
normal, or not in an alarm condition. When the input
goes into an alarm condition, reaching a trip point or
losing power, the relay of a fail-safe DCA is de­energized.

Conversely, a non-fail-safe unit’s relay is de-energized
when input is within the customer-specified “safe”
range, and is energized when the input reaches the
trip point setting.

Figure 1 also depicts the action of fail-safe relays.

Description

The DCA comes in either Moore Industries’ standard
(STD) or plug-in card (PC) housing.

The STD unit can be used with a variety of mounting
options, including those suitable for use with explo­sion-proof and NEMA enclosures.

PC-style DCA’s are designed for use with Moore
Industries’ multi-position card racks; the surface
mounted SMR, or the rack mounted RMR.

Both STD and PC DCA’s are available with either
single or dual alarm configurations. The relays used
are single-pole/double-throw, form C. There are a
number of input ranges and alternate relay ratings
available.

Operationally, the unit can be ordered with any com-

Controls and Indicators

Every type and configuration of DCA comes with
potentiometers (pots) to set the alarm trip points of
each installed relay. Additional pots for controlling
unit dead band are available as an option, and preci­sion ten-turn vernier scales can be used instead of
the standard pots.

Trip point pots afford full 0- to 100-percent adjustabil­ity over the unit’s specified span.

Each installed relay is wired to a front panel LED,
which lights when the relay is energized. Depending
upon the type of relay ordered, i.e. fail-safe/non-fail­safe, a lit LED can indicate either an “alarm” or a “non­alarm” input condition.

Table 1 summarizes the alarm type/LED status
options for the available types of DCA.

Page 2

DCA

100 %

ANALOG

INPUT
VALUE

0 %

Model Number

Designator

HIGH-ALA RM DCA

TIME

100 %

TRIP POINT
DEAD BAND

RESET

FAIL-SAFE R ELAY ENERGIZED , LED ON
FAIL-SAFE R ELAY DE-ENERGIZED, LED OFF

ANALOG

INPUT
VALUE

0 %

LOW-ALARM DCA

RESET

DEAD BAND

TRIP POINT

TIME

Figure 1. High - and Low-alarm Relay Configurations

Table 1. DCA Alarm Types

This Unit is...

S Single Alarm - - Only one relay installed

This Unit signals an

“Alarm” condition when...

Its LED will be...

Relay(s)

D Dual Alarm - - Two relays are installed

H1 High Fail-Safe

H2 High NON-Fail-Safe

L1 Low Fail-Safe

L2 Low NON-Fail-Safe

Input increases, and exceeds

Trip Point. (See Note 2).

Input increases, and exceeds

Trip Point. (See Note 2).

Input decreases, and drops

below Trip Point

(See Note 2)

Input decreases, and drops

below Trip Point

(See Note 2)

OFF in alarm

ON in Non-alarm

ON in Alarm,

OFF in Non-alarm

OFF in alarm

ON in Non-alarm

ON in Alarm,

OFF in Non-alarm

DE-energized in alarm

Energized in Non-alarm

Energized in Alarm,

DE-energized in Non-alarm

DE-energized in alarm

Energized in Non-alarm

Energized in Alarm,

DE-energized in Non-alarm

NOTES: 1. Older DCA’s may use X1 for H1, X2 for H2, X3 for L1, and X4 for L2.

2. The “UPPER” and “LOWER” labeling on the DCA front panel is for reference only.
Configurations where “LOWER” terminals and pots pertain to the unit’s high alarm, for
example, are quite possible.

3. Relays in fail-safe alarms are DE-energized in the event of power loss to the unit.

Page 3

DCA

Table 2 lists the performance and operational specifi­cations for the unit.

Table 2. DCA Performance and Operational Specifications

Characteristic

Input

Output

Specifications

Current: 1-5 mA @ 200Ω nominal input impedance

4-20 mA @ 50Ω nominal input impedance
10-50 mA @ 20Ω nominal input impedance
Selectable Current (SC) comes with three load resistors for selecting1-5, 4-20, or
10-50 mA (See Note 1)

Voltage: 0.25-1.25 V @ 1MΩ, minimum (See Note 2)

1-5 V @ 1MΩ, minimum

Consult factory for dual input and special range options.

Factory-configured with one (Single DCA) or two (Dual DCA) single pole/double throw
(SPDT), form C, mechanical relays rated for 5 A @ 117 Vac non-inductive, or 28 Vdc.

User selects Normally Open (NO), Normally Closed (NC), or any combination of NO/NC
configurations during installation. Fail-safe/Non-fail-safe configuration factory-set. Refer to
table 1 for available combinations.

Options

Each DCA is configured according to customer
requirements. The paragraphs on the following pages
highlight some of the options available.

Power

Performance

Environmental

Ratings

NOTES: 1. One of the available resistors MUST be installed.

2. Requires extra engineering when used with some option combinations.

3. DPDT not available with some enclosures and option combinations.

Double pole/double throw (DPDT), form 2C and 7.5 A relays available as options.
(See Note 3)

24 or 45 Vdc ±10%, 5 watts nominal
100, 117, 200, 220, or 240 Vac ±10%, 50/60 Hz
AC power inputs not available with PC-style housing

Repeatability: Trip point settings repeat within ±0.1% of span.
Dead Band: 1% of span, standard. Adjustable Dead Band Option available.
Alarm Response: 50 milliseconds for step change of 1% of span.
Line Voltage Effect: ±0.005% per 1% line voltage change (ac or dc).
Isolation: No galvanic path between input, output, and power.
Accuracy: Front panel potentiometers capable of setting trip points from 0 to 100% of

span. Lockable, scaled vernier dials optional.
Effect of Ambient Temperature on Performance: Less than ±0.018% per °C through the
specified range (Less than ±0.01% per °F)

Ambient Operating Temperature: –18 to 65 °C (0 to 150 °F)

Page 4

DCA

For a complete list of available options, and for
information on other housings, mounting hardware,
and enclosures, contact your Moore Industries Sales
Representative.

AD Option —

Front panel potentiometers vary dead band 1- to 20­percent of span (nominal), 1- to 50-percent of span
(AD50), or 1- to 100-percent (AD100) of span. (AD
Option not available with some option combinations).

AR Option —

factory for output delays of 1 to 5, 10, 15, 20, 25, or
30 seconds, according to customer specification.

DA Option —

condition when the difference between two inputs
exceeds adjustable percent of full span. Requires DI
Option or 2X input. (Not available with some option
combinations.)

DI Option —

to operate as two, single-alarm units. Standard DI
unit provides a high alarm for one input and a low
alarm for the other. (DI Option not available with
some option combinations).

DPDT Option —

Relays. Contact 5 amps at 28 Vdc, or 117 Vac non­inductive. (DPDT Option not available with some
option combinations).

Externally-adjustable Dead Band.

Response Time Delay. Set by the

Deviation Input. Unit signals alarm

Dual Input. Configures dual-alarm DCA

Double Pole, Double Throw/Form 2C

TX Option

at 30 Vdc @ 25 mA.

7.5A Option —

UL at 7.5 amps, 28 Vdc or 120 Vac.

Model/Serial Number. Moore Industries uses a
system of unit model and serial numbers to keep
track of factory configuration and options for each
DCA shipped and serviced.

The example outlines the significance of each field of
information in a typical DCA model number. Refer to
table 1 for an explanation of the relay configuration
codes used.

If service information or assistance for a DCA is
needed, make a note of the unit’s model and serial
number before contacting Moore Industries’ Customer
Service Department. Our highly skilled technicians
will be happy to assist you.

STD units’ serial and model numbers are located on
an L-shaped metal tag at the top of the connection
terminal strips. On PC DCA’s, the numbers are
located on an adhesive label affixed to the side of the
front panel.

— Two-wire Transmitter Excitation. Rated

7.5 amp Relay(s). Rated by CSA and

Calibration

FU Option

PC-style unit. Use of the FU Option with the STD
housing requires special engineering.

HS Option

@ 117 Vac non-inductive, 2A @ 28 Vdc. Meets
requirements for installation in Class I, Division 2
locations.

MR Option —

button for single- and dual-alarm units. In place of
dead band, MR-equipped units return to normal only
when the process input returns to non-alarm state
the external reset push button is pressed.

TT Option —

multiturn potentiometers for setting and locking trip
points. Includes front panel ZERO potentiometer for
appropriate offsets.

— Power Fuse. 400 mA rated fuse on

— Hermetically Sealed Relays. Rated 1A

Manual Reset. External reset push

and

Lockable Vernier Dial. Front panel,

Every DCA shipped from the factory is manufactured
and tested according to Moore Industries’ exacting
standards for product quality. A bench check of basic
unit operations is recommended, however, in order to
identify any damage to the unit that may have oc­curred during shipping. This also allows the user to
effect operational adjustments to trip point settings
and unit dead band, if available.

It is recommended that the procedures in this section
be carried out at a technician’s bench or in a similar
lab environment. This is the safest means of making
adjustments to trip point values; isolated from the
intended DCA application.

The calibration of the DCA consists basically of
setting trip points and dead bands based on the
resistance across the unit contact-closure terminals
as measured by an ohmmeter. With relay contacts
closed, resistance is negligible. With relay contacts
open, resistance is infinite.

EXAMPLE

Unit Type

Input

Relay Configuration

Power

Options(s)

Housing

Page 5

DCA

DCA / 4-20MA / DH1L1 / 117AC / -AD [STD]

Basic Calibration Setup

The equipment listed in table 3 is needed for calibrat­ing the DCA. These items are not supplied with the
unit, but should be available in most testing labs.

Table 3. DCA Calibration Equipment

Equipment Specifications

Voltage

Voltage or

Current Source

Current Source

Power Source

Ohmmeter Accuracy of ±1%, minimum.

Screwdriver Slotted-tip with head width no greater than 2.54 mm (0.01 in).

Wire Jumpers

(required for

AR-equipped

DCA’s ONLY)

or

Calibrated, adjustable unit, capable of output at discrete levels in the
appropriate range, with the rated impedance for the unit being calibrated.
EDC Models MV105, MV155, or equivalent.

AC or dc power input appropriate for the type of DCA being calibrated.
Refer to table 2, earlier in this manual.

Temporary jumper wiring suitable for shorting AR Option diodes so that the
alarm delay may be defeated while adjusting the unit’s trip point settings.

Be sure to use calibrated test equipment when
performing the bench check and calibration of the
DCA. The use of inaccurate test equipment may
result in unreliable settings for the unit’s trip point(s),
etc.

Extender Card

(optional for use

with PC-style

DCA’s ONLY)

Moore Industries’ part number 350-513-00.

Page 6

DCA

Setup for the STD DCA. Figure 2 shows the labeling
used on the front panel of the STD DCA. Figure 3
shows the terminals on a unit equipped with DPDT
relays.

CDC URRENT

DCA

UPPER RELAY NORM ALLY

OPEN — UNO

COMMON — COM

UPPER RELAY NORM ALLY

CLOSED — UNC

ALARM

UPPER LOWER

ZERO

U PPER

D EADBAN D

LOWER

To access the connection terminals for a DCA in the
basic extruded housing (STD, AB, etc.), use a screw
driver to remove the securing screw from the protec­tive plastic cover on the unit front panel. With the
screw removed, the cover can be removed by hand,
revealing the terminals and the labels depicted in the
illustrations in this manual.

LNO —
LOW ER R ELAY N ORM ALLY OPEN

COM — COMMON

LNC —
LOWER RELAY NORMALLY CLOSED

ACC — –DC

AC — +DC

GND

NOTES: 1. Each uni t i s factor y- configured for ac or dc pow er .

2. Each unit is factor y-c onfi gur ed for specifi c cur r ent or voltage input.

Figure 2. STD DCA Terminal Locations

OPTION — +TX FOR TRANSMITTER
EXCITATION, +REF FOR D EVIATION ALARM

+IN — CURRENT OR VOLTAGE +INPUT

-IN — CURRENT OR VOLTAGE -INPUT

UPPER RELAY #1 NOR MALLY

OPEN — UNO1

COMMON — COM

UPPER RELAY #1 NOR MALLY

CLOSED — UNC1

ACC — –DC

AC — +DC

GND

DC CURRENT

DCA

ALARM

UPPER LOWER

ZERO

U PPER

D EADBAN D

LOWER

Page 7

DCA

UN O2 — UPPER RELAY #2
NORM ALLY OPEN

COM — COMMON

UNO2 — UPPER RELAY
#2 NORMALLY CLOSED

LNO1 — LOWER RELAY #1
NORMALLY OPEN

COM — COMMON

LNC1 — LOWER RELAY #1
NORMALLY CLOSED

LNO2 — LOWER RELAY #2
NORMALLY OPEN

COM — COMMON

LNC2 — LOWER RELAY #2
NORMALLY CLOSED

OPTION — +TX FOR
TRANSMITTER EXCITATION,
+R EF FOR D EVIATION ALARM

Figure 3. STD DCA w/DPDT Option Terminal Locations

Figure 4 shows the labeling for a STD DCA equipped
with the DI Option. Note that both inputs share the “–
IN” terminal.

+IN — CURRENT
OR VOLTAGE +INPUT

-IN — CURRENT
OR VOLTAGE -INPUT

WARNING

To guard against accidental electric

shock, it is recommended that the protec-

tive plastic cover be re-installed over the

terminal strip of the STD DCA before

applying power to the calibration setup.

Page 8

DCA

Setup for the PC DCA. There are two methods of
carrying out the calibration setup connections on the
PC DCA. Most often the unit is installed in one of
Moore Industries’ card racks, and the calibration
equipment is connected to the appropriate rack
terminal strip.

Figure 5 illustrates the PC DCA installed in the
surface mounted card rack, the SMR. Figure 6 shows
the terminal strip labeling for rack units when the DCA
is equipped with the DI Option.

As an alternative to using the card rack, individual PC
DCA’s can be checked with Moore Industries’ Pro­cess Power Supply, the PPS, equipped with its CT
Option. The CT-equipped PPS accepts the connec­tion strip of the PC DCA in a connector built into its
side panel. The PPS front panel provides access to
terminal strips similar to those used on the card
racks.

Whether using the card rack or the PPS/CT combina­tion, note that the DC power connections are not
made directly to the unit, but to the terminal strips of
either the card rack or the PPS. DC power is supplied
to the DCA at its pins 8 and 9

NOTE

The “UPPER” and “LOWER” labeling used

on the DCA is for reference purposes only.

The trip point pots allow for adjustments through 100­percent of span. It is therefore possible for the
connections to the “LOWER” labeled alarm section to
be configured as a “high alarm”, and the “UPPER”
section to be configured as a “low alarm”.

NOTE

The LED’s DO NOT always indicate an

alarm condition; rather, they light to show

that their complimentary relay is ener-

gized. It is possible for a DCA to be

configured such that the LED’s are lit

when input is in a “non-alarm” state.

ACC — –DC

AC — +DC

GND

LNO —
LOWER RELAY NORMALLY OPEN

COM — COMMON

LNC —
LOWER RELAY NORMALLY CLOSED

+IN U P — UPPER
CURRENT/VOLTAGE +INPUT

+IN LOW — LOW ER
CURRENT/VOLTAGE +INPUT

-IN — NEGATIVE INPUT

Figure 4. STD DCA with DI Option Terminal Locations

Page 9

DCA

-DC

+DC

GND

PC

DCA

1

INTERNAL RACK SLOT
AND CONNECTOR

15

PC DCA
COMPONENT SIDE

SMR

MOUNTING
FLANGES

NOTES :

7

LNO - LOWER RELAY NORMALLY OPEN

ONE POWER

CONNECTION

PER R ACK

ONE TER MINAL

STR IP PER

CARD POSITION

Rack is shown wi th protective cover s removed.1.

2.

Power is not appl i ed to eac h PC connector strip, but to the rack ter m i nal strip.
Power is supplied to the PC DCA at i ts pins 8 (-D C ) and 9 (+DC).

4

LNC - LOWER RELAY NORMALLY CLOSED

2

COM - COMMON

OPTION — +TX, +REF

5

3

+IN — CURRENT OR VOLTAGE + INPUT

10

-IN — CURRENT OR VOLTAGE - INPUT

UN O - UPPER RELAY NORMALLY OPEN

13

1

UNC - UPPER RELAY NORMALLY CLOSED

15

COM - COMMON

Figure 5. Terminals Labeling, the PC DCA in the SMR

Page 10

DCA

ONE TER MINAL

STR IP PER

CARD POSITION

7

LNO - LOWER RELAY NORMALLY OPEN

4

LNC - LOWER RELAY NORMALLY CLOSED

2

COM - COMMON

5

+IN — UPPER ALARM CURENT OR VOLTAGE +INPUT

3

+IN — LOWER ALARM CURRENT OR VOLTAGE + INPUT

-IN — CURRENT OR VOLTAGE - INPUT

10

13

UN O - UPPER RELAY NORMALLY OPEN

1

UNC - UPPER RELAY NORMALLY CLOSED

15

COM - COMMON

Figure 6. PC DCA with DI Option Terminal Locations

Setup of DCA’s in Explosion-proof Enclosures.

The DCA in an explosion-proof enclosure (EX) in­corporates a modification of the STD housing where
the connection terminals are replaced with pins on the
unit bottom panel. These pins are inserted in a
terminal block permanently mounted inside the base
of the explosion-proof enclosure.

To effect the calibration connections, unscrew the top
of the enclosure and pull the DCA up and out of the
enclosure base, exposing the terminal block. Figure 7
shows the block and its labeling. Figure 8 shows the
labeling used for units equipped with the DI Option.

Use the appropriate terminal locations figure to
connect the calibration equipment to the terminal
block in the enclosure base. Then re-connect the
DCA by aligning the pins on the bottom of the unit
housing with the holes in the terminal block. Press
down until the unit is seated firmly in the enclosure
base.

CAUTION

The EX DCA housing fits into the terminal

block in its correct orientation only. Note

the position of the connection “key”.

Attempting to “force” the unit in when the

pins are not aligned with the correct holes

will bend the pins.

Basic Calibration Hookup. Use the terminal loca­tions figure that is appropriate for the type of DCA
being checked, and connect the equipment described
in the calibration equipment table as shown in the
calibration hookup diagram, figure 9.

Set all low alarm pots fully counterclockwise. DCA
pots are equipped with slip clutches to prevent
damage in the event of over-turning. A slight change
in torque may be felt when a wiper stop is reached. If
unable to sense the stop, set pot 15 turns counter­clockwise.

Page 11

DCA

NORMALLY OPEN — LNO

NORMALLY CLOSED — LNC

EXCITATION, +REF FOR D EVIATION ALARM

CURRENT OR VOLTAGE

CURRENT OR VOLTAGE

LOWER RELAY

COMMON — COM

LOWER RELAY

+INPUT — +IN

-INPUT — -IN

Figure 7. DCA in an Explosion-proof Enclosure Terminal Locations

NORMALLY OPEN — LNO

LOWER RELAY

7

8

9

OPTION — +TX FOR TRANSMITTER

10

11

12

7

`

6

6

5

4

3

2

1

GND

+DC — AC

–DC — ACC

UNC — UPPER RELAY
NORMALLY CLOSED

COM — COMMON

UN O — UPPER RELAY
NORMALLY OPEN

GND

COMMON — COM

NORMALLY CLOSED — LNC

UPPER ALARM CURRENT OR
VOLTAGE +INPUT — +IN UPP

LOWER ALARM CURRENT OR
VOLTAGE -INPUT — +IN LOW

CURRENT OR VOLTAGE

LOWER RELAY

-INPUT — -IN

8

9

10

11

12

5

4

3

2

1

+DC — AC

–DC — AC C

UNC — UPPER RELAY
NORMALLY CLOSED

COM — COMMON

UN O — UPPER RELAY
NORMALLY OPEN

Figure 8. DCA with DI Option in an Explosion-proof Enclosure Terminal Locations

Page 12

DCA

APPROPRIATE

CALIBR ATED

ADJUSTABLE

CURRENT

VOLTAGE SOURCE

NOTES: Check unit m odel number for appr opi ate input sour c e.

1.

2.

3.

OR

(SEE NOTE 1)

Check unit m odel number for appr opr i ate power source.
X = U for upper or L for lower. Connect ohmmeter to " N O" for ter m i nals of normally open r el ay, to
NC for normally closed. “#” is used in DPDT- equipped units to refer to the number of the al ar m
output, as i n U NO1 and LN C2.

+

–

+IN

–IN

POWER SOURCE

Figure 9. The DCA Calibration Setup

Special Considerations for AR-equipped DCA’s.

Units equipped with the AR Option are factory-set for
specific alarm delay times ranging from 1 to 30
seconds (refer to Options listing). The AR is set and
fully calibrated according to customer requirements
before unit shipment.

The delay in an AR-equipped DCA’s transition from
normal to alarm condition makes the calibration of trip
points difficult, and a temporary disabling of the option
is therefore recommended during the calibration
procedures.

To defeat the AR Option, diodes on PC1 of the DCA
must be shorted. There is a diode for each installed
relay.

DCA’s in the STD housing must be partially disas­sembled to access the AR diode(s). See figure10.
Figures 11 and 12 show the location of the diodes on
the various types of AR-equipped DCA.

Access to the AR diode(s) on PC-style DCA’s may be
difficult if the unit being calibrated is already installed
in its rack. Moore Industries offers an Extender Card
accessory for calibrating units under these circum­stances.

XNO#

DCA

+

+

VDC or VAC

(SEE NOTE 2)

COM

XNC#

–

–

The Extender, P/N 350-513-00, mates with the
connector on the PC-style DCA, and then plugs in to
the rack so that the unit is clear of the rack front,
allowing for access to the diode(s).

OHM METER

(SEE NOTE 3)

Calibration Procedures

Before beginning the actual calibration of the DCA,
check the unit’s model number to verify that the
correct power supply and input simulator is being
used. Make sure that the appropriate connections are
made as shown in the figures of the preceding
section.

Using the Calibration Procedures. The Calibration
Procedures section is divided into subsections that
describe first low alarm, then high alarm trip point
setting. The procedure for calibrating the DCA dead
band, for units equipped with the AD Option, should
be conducted after the trip points are set.

If the DCA to be calibrated is equipped with the TT
Option, skip to and complete the procedure in the
section entitled “Calibrating DCA’s Equipped with the
TT Option”.

Page 13

DCA

FRONT PANEL

Figure 10. STD DCA Disassembly

FOR DUAL-ALARM

PC DCA SHORT AROUND

TH ESE DIODES

RELAY

CONNECTOR

PINS

RELAY

FOR SINGLE-ALARM
PC DCA SHORT AROUND
THIS DIODE

Figure 11. AR Option Diodes on the PC DCA

Page 14

DCA

LED’S

PC2

PC1

RELAY

Figure 12. AR Option Diodes on PC1 of the STD DCA

RELAY

FOR SINGLE ALARM
STD DCA SH OR T
AROUND THIS DIODE

FOR DUAL ALARM STD
DCA SHORT AROUND
TH ESE DIODES

Setting Low-Alarm Trip Points. Remember that the
“UPPER” and “LOWER” labeling on the DCA is for
reference purposes only. The DCA can be ordered
without low alarms, as in a “high/high” configuration.
Dual alarm units can be ordered with either one or
both relays configured as low alarms, and DPDT­equipped DCA’s may be configured with any combina­tion of high/low alarms.

Refer to the unit’s model number to determine the
alarm configuration, and perform the following proce­dure for each installed low alarm.

1. Check model number to verify correct power
input, and apply 117 or 240 Vac; 24 or 45 Vdc, as
appropriate.

2. Make sure that ohmmeter in calibration setup is
connected to appropriate -NO or -NC terminals, as
desired.

3. Apply 100% of application’s input span (current or
voltage, as appropriate) to DCA.

If low alarm is configured as fail-safe, L1 in model
number, verify that appropriate LED for that alarm
is lit. LED for non-fail-safe low alarm, L2 in model
number, will not be lit.

4. Note ohmmeter reading.

In a low alarm, 100% input is a non-alarm condi­tion. If connected to XNO and COM terminals (
= U or L, UPP or LOW; NO = normally open),
Resistance across the terminals in a fail-safe
alarm is zero. In a non-fail-safe alarm resis­tance will be near infinite.

If connected to XNC and COM terminals, resis­tance is infinite in fail-safe, zero in non-fail-safe
alarms.

X

Page 15

DCA

5. Set input to desired low alarm trip point level.

6. Turn appropriate low alarm adjustment pot (may
be labeled “UPPER” or “LOWER”) slowly clock­wise. Observe LED and ohmmeter, and stop
turning at exact point where relay changes state.

Vary pot setting slightly above and below trip
point to “zero in” on exact setting.

If low alarm is configured as fail-safe, L1 in model
number, verify that appropriate LED for low alarm
is not lit. LED for non-fail-safe low alarm, L2 in
model number, will be lit.

7. Verify desired setting by varying input above and
below trip point level (from step 6) and observing
both LED and ohmmeter to confirm change of
relay state at, and below trip point setting.

NOTE

Units equipped with any Manual Reset

Option have external push buttons that

must be pressed to reset the relays once

they have been tripped.

Setting High-Alarm Trip Points. Remember that the
“UPPER” and “LOWER” labeling on the DCA is for
reference purposes only. The DCA can be ordered
without high alarms, as in a “low/low” configuration.
Dual alarm units, on the other hand, can be ordered
with either one or both relays configured as high
alarms.

3. Apply 0% of application’s input span (current or
voltage, as appropriate) to DCA.

If high alarm is configured as fail-safe, H1 in
model number, verify that appropriate LED for that
alarm is lit. LED for non-fail-safe low alarm, H2 in
model number, will not be lit.

4. Note ohmmeter reading.

In a high alarm, 0% input is a non-alarm condi­tion. If connected to XNO and COM terminals
(X= U or L, UPP or LOW; NO = normally open),
Resistance across the terminals in a fail-safe
alarm is zero. In a non-fail-safe alarm resis­tance will be near infinite.

If connected to XNC and COM terminals, resis­tance is infinite in fail-safe, zero in non-fail-safe
alarms.

5. Set input to desired high alarm trip point level.

6. Turn appropriate high alarm adjustment pot (may
be labeled “UPPER” or “LOWER”) slowly clock­wise. Observe LED and ohmmeter, and stop
turning at exact point where relay changes state.

Vary pot setting slightly above and below trip
point to “zero in” on exact setting.

If high alarm is configured as fail-safe, H1 in
model number, verify that appropriate LED for that
alarm is not lit. LED for non-fail-safe high alarm,
H2 in model number, will be lit.

Refer to the unit’s model number to determine the
alarm configuration, and perform the following proce­dure for each installed high alarm.

1. Check model number to verify correct power
input, and apply 117 or 240 Vac; 24 or 45 Vdc, as
appropriate.

2. Make sure that ohmmeter in calibration setup is
connected to appropriate -NO or -NC terminals, as
desired.

7. Verify desired setting by varying input above and
below trip point level (from step 6) and observing
both LED and ohmmeter to confirm change of
relay state at, or above trip point setting.

NOTE

Units equipped with any Manual Reset

Option have external push buttons that

must be pressed to reset the relays once

they have been tripped.

Page 16

DCA

Setting the Dead Band. See figure 1 for a graphic
representation of the DCA dead band. The dead band
may be thought of as an “area” around a trip point in
which the alarm will not reset.

In a scenario using a high-alarm DCA as an example,
the unit will signal an alarm at its trip point, and will
continue to signal an alarm as long as the input is
above that point.

Without an adjustable dead band, the relay will reset
when the input drops below the trip point. When
equipped with the AD Option, however, no reset will
occur until the input continues to drop to the dead
band setting, presumably some percentage of span
below the trip point.

To set the DCA dead band:

1. Make sure dead band pots are turned fully
counterclockwise. Set trip points for installed
alarms as described in preceding section. Con­nect ohmmeter to UPPER alarm section to set
UPPER dead band, or to LOWER section for
setting LOWER dead band.

For Example

A single, high-alarm DCA rated for 4-20 mA input is
required to have a 25% dead band around its 14 mA
trip point setting. To calculate the input level needed
to set the desired dead band, subtract 25% of 16 mA
(span) from 14 mA:

The result, 10 mA, is the level of input to be applied in
step 2. The DCA in this example will signal an alarm
condition when the input reaches or exceeds 14 mA,
but will not reset until the input drops below 10 mA.

Calibrating TT-equipped Units. Lockable, multiturn
trip point adjustment pots on the front panel of each
TT-equipped DCA are set at the factory so that “0.00”
on the dial is equal to 0% of the application’s rated
input span. “10.00” is equal to 100% of span. The
accuracy of these settings is ±0.5% of the rated
span.

:

Trip point setting in mA = 14

– 25% of input span in mA = 16(0.25)

14 – 4 = 10

2. Apply input at the dead band setting level.
Typically, this will be lower than trip point for high
alarms, or higher than trip point for low alarms.

3. Turn appropriate dead band pot slowly clockwise,
observing LED and ohmmeter.

4. Set pot (stop turning) at exact point at which relay
changes state.

5. Verify desired setting by varying input above and
below trip point, observing both LED and ohmme­ter to confirm appropriate change of relay state.
Unit will “trip” at trip point setting, and will not
reset until input returns past dead band setting.

The DCA dead band can be expressed as a percent­age of the unit’s factory-configured span.

Calibration of DCA’s with this option consists of two
procedures. First, the internal, Full-Scale Adjust
(FSA) potentiometer(s) must be set (this involves
some disassembly of the STD DCA). Then, the unit
zero, trip points, and dead band (if so-equipped), must
be set.

Figure 13 shows the location of the STD DCA FSA
potentiometers. Figure 14 shows the location of the
pots on the PC-style unit. Refer to figure 10 when
disassembling the unit in STD housing, and refer to
figures 13 or 14 while executing the procedure.

NOTE

The following procedure assumes that the

DCA being calibrated has its “UPPER”

alarm section configured as a high alarm,

and its “LOWER” alarm section configured

as a low alarm. If this is not the case for

your DCA, interchange references to

“UPPER” and “LOWER”, as appropriate.

LED’S

Page 17

DCA

RELAY

PC1

Figure 13. Location of the FSA Potentiometers on the STD DCA PC1

RELAY

LOWER FULL-SCALE
ADJUSTMENT POT
(DUAL ALARMS ONLY)

UPPER FULL-SCALE
ADJUSTMENT POT

FRONT PANEL

FU LL-SCALE AD JU STMENT

(SINGLE ALARM ONLY)

Figure 14. Location of the FSA Potentiometers on the PC DCA

UPPER FULL-SCALE

ADJUSTM ENT

(DUAL ALARM ON LY)

CONNECTOR

PINS

LOW ER FULL- SC ALE
ADJUSTM ENT (D UAL ALARM ON LY)

Page 18

DCA

1. With the hookup described in the Calibration
Setup Section complete, disable AR Option as
described in section titled “Calibrating AR­equipped DCA’s”. Connect ohmmeter to “UP­PER” alarm terminals first.

2. Verify that all pots are set fully counterclockwise,
to 0.00.

NOTE

Steps 3 through 10 apply to high alarms.

Skip to step 11 to calibrate the ten-turn

dials on low alarms.

3. Apply 0% of appropriate input from application.
Refer to unit’s model number and specifications
listing in table 2.

4. Turn ZERO pot clockwise until both “UPPER” and
“LOWER” alarms trip.

5. Apply 100% input to setup.

6. Turn “UPPER” and “LOWER” pots clockwise to

10.0 setting.

7. Turn internal FSA pots fully counterclockwise.
High alarm will change state. Disregard low alarm
at this time.

8. Turn FSA pot for “UPPER” alarm slowly clock­wise, observing ohmmeter and appropriate front
panel LED.

9. Set FSA pot (stop turning) at exact point at which
high alarm is tripped. If high alarm is configured
as fail-safe, H1 in the unit model number, verify
that appropriate LED for high alarm is not lit. The
LED for a non-fail-safe high alarm, H2 in the
model number, will be lit.

12. Turn “LOWER” FSA pot slowly clockwise, observ­ing ohmmeter and appropriate front panel LED.

13. Set FSA pot (stop turning) at exact point at which
low alarm is tripped.

If low alarm is configured as fail-safe, L1 in the
unit model number, verify that appropriate LED for
low alarm is not lit.

The LED for a non-fail-safe low alarm, L2 in the
model number, will be lit.

14. Alternate the input between its rated 0 and 100%
level, verifying the setting of the unit’s front panel
pots (0.00 at 0% input, 10.00 at 100% input).
Readjust both FSA pots as necessary.

Calibrating DA -equipped Units. If ordered, the
Deviation Alarm Option allows the user to set alarm
trip points based on the difference between two
inputs. This difference is expressed as a percentage
of total input span, and unit relays are “tripped”
whenever process input varies, more than (high alarm)
or less than (low alarm) the set percentage.

To calibrate DA-equipped DCA’s, a second input
source will be needed. Refer to table 3, and use two
of the appropriate sources as specified.

Refer to figures 2 through 8 as appropriate, to deter­mine which of the unit terminals is used for the
second, reference input connection.

Finally, refer to the setup shown in figure 9, and add
the connection for the second input source as follows:
“+REF” is used for positive reference input, and the
negative connection for both inputs is common, the “–
IN”.

To calibrate DA-equipped DCA’s:

10. Disconnect ohmmeter, and reconnect it to
“LOWER” alarm section of DCA.

11. With input at 100%, and ohmmeter connected to
“LOWER” alarm section of unit, turn appropriate
“LOWER” FSA pot fully clockwise. Note that low
alarm trips.

1. With setup complete as described in preceding
paragraph, and all pots set fully counterclockwise,
determine percentage of rated input span that is
to serve as difference between reference input
and input #2.

2. Set reference input to 50% of rated span.

Page 19

DCA

3. Set input #2 to desired percentage above or below
reference.

4. Set trip points as appropriate, using UNC pot for
UPPER normally closed alarm, UNO pot for
UPPER normally open; LNC for LOWER normally
closed, and LNO for LOWER normally open.
Base settings on input #2.

Units factory-configured as high alarms will “trip”
when input #2 exceeds the desired difference.
Low alarms “trip” when input #2 falls below
desired difference.

For Example:

A DA-equipped DCA is rated for two, 4-20 mA inputs
(“2X” in the model number). The application calls for
an alarm condition when input #2 varies more than
25% of span from the reference input.

Span = 16 mA

25% of 16 = 4 mA

The reference input is set to 50% of rated span, or 12
mA. Input #2 is set 25% higher, 16 mA.

Installation

Installing the DCA is typically accomplished by
physically mounting the unit, then effecting the
electrical connections.

Mounting

Figures 15 and 16, respectively, show the outline
dimensions of the DCA in the STD and the PC
housing styles. The drawing of the STD housing
includes the dimensions of the U-bracket, typically
included with that type of DCA, and also of the side
housing used for DCA’s equipped with the DPDT
option.

Always try to install the DCA in an area relatively free
of dust, excessive moisture, or corrosives.

Contact your Moore Industries Sales Representative
for information on other types of DCA housings,
enclosures, and mounting hardware.

The trip point pots are turned clockwise until relays
change state.

Regardless of how the reference input is varied, from
4 to 20 mA, as long as input #2 is likewise varied at a
50% offset, the alarms are not “tripped”.

However, if the reference is at 12 mA and input #2 is
at 20 mA, the high-alarm relay will indicate an alarm
condition. Likewise, if the reference is at 12 mA and
input #2 is at 14 mA, the low-alarm relay will indicate
an alarm.

Making Electrical Connections

Figure 17 illustrates the installation hookup for the
unit. Refer to the terminal location figures in the
Calibration Section when making the electrical
connections associated with installing the DCA.

Though there is no special wiring required for standard
connections, the use of shielded, twisted wiring is
recommended for all low-level signals, or where
connecting leads are run close to other services such
as power wiring. Ground the shield wire as close to
the DCA as possible in the installation.

Page 20

DCA

9.5 mm

(0.38 in)

167 mm
(6.56 in)

6.4 mm

(0.25 in)

76.2 mm
(3.00 in)

66 mm

(2.60 in)

DC CURRENT
ALARM

DCA

UPPER LOWER

ZERO

COVER

63.3 mm
(2.49 in)

95 mm

(3.75 in)

102 mm
(4.00 in)

76.2 mm
(3.00 in)

63.5 mm

(2.50 in)

186 mm
(7.31 in)

154 mm
(6.08 in)

Figure 15. STD DCA Outline Dimensions, Including DPDT Option

When making the electrical connections for units in
explosion-proof enclosures, route the wiring through
the conduit hubs in the enclosure with enough slack
to reach the appropriate terminal.

Units in oil- or water-tight NEMA enclosures require
the use of Myer Scru-Tite (or equivalent) fittings to
maintain the enclosure integrity when routing wiring
conduit to or from the DCA.

WARNINGS

Do not apply power to the DCA until all

connections are secure. The uncovered

power input terminals of ac-powered STD

DCA’s present an electric shock hazard.

Always turn off the power to the unit

before servicing.

Page 21

DCA

CURRENT

OR VOLTAGE

SOURCE

NOTES: 1.

Figure 16. PC DCA Outline Dimensions

(SEE NOTE 2)

+OUT

–OUT

+IN

–IN

DCA

XNO

COM

XNC

+
–

+
–

VDC or VAC

POWER SOURCE

(SEE NOTE 1)

Check the m odel num ber for pow er source r equirements.

2.

X=U for upper al ar m secti on, high or low , or L for lower alarm sec ti on,
high or low .

NO=norm ally open
NC=normally closed

ALARM

INDICATOR

Figure 17. DCA Installation Hookup

Page 22

DCA

PC DCA’s slide into card slots in Moore Industries’
nineteen-inch card racks, the SMR and RMR. Each
DCA has individual contacts on its rear edge that
mate with an edge connector at the back of the rack.

Maintenance

Once the DCA is properly calibrated and installed, it
will operate indefinitely. No further adjustments
should be necessary, unless the unit is moved, or the
process input changes.

It is recommended that the unit terminals be checked
periodically for signs of oxidation or looseness.

If a problem develops with the performance of the
DCA, remove the unit from service and recalibrate.
Refer to the Calibration Section of this manual for
instructions.

Any units found to be performing below specifications
after a recalibration should be returned to the factory
immediately. Instructions for unit return can be found
on the back cover of this manual.

Customers may also contact the friendly folks in
Moore Industries’ Customer Service Department at 1­800-999-2900 for technical assistance.

August 1992

DCA

Direct Current Alarm

SUPPLEMENT

To Manual No. 192-701-00 G

Purpose

This supplement is being distributed to users of
Moore Industries' Direct Current Alarm (DCA) to in­form them of corrections/additions to the current
manual since its release date. These changes will
be incorporated in the manual during its next revi­sion.

Corrections

The wording of the second paragraph of step 4 of the
"Setting Low-Alarm Trip Points" (page 14) and "Set­ting High-Alarm Trip Points" (page 15) calibration
procedures should read:

In a low alarm, 100% input is a non-alarm condi­tion. If connected to XNO and COM terminals (X =
U or L (upper or lower); NO = normally open). Resis­tance across these terminals in a fail-safe alarm is

near zero
infinite

. In a non-fail-safe alarm, resistance will be

.

It is important to understand that the "normal" con­dition of these relays refers to the

de-energized

terminal labeling is true when power is removed from
the unit or when the unit is operating and the LED is
NOT lit. Since each LED illuminates only while the
corresponding relay is
not lit its corresponding relay is de-energized.

So, regardless if the DCA is configured for fail-safe
or non-fail-safe operation, each relay's normally-open
or normally-closed contact states are true as labeled
only when the relay is de-energized.

state of the relay. This means that the

energized

non-energized

, when the LED is

or

Addition

The hookup connections for units configured with the
TX Opton are not provided in the Installation Section
of the user's manual. For units with the TX Option,
connect the positive output lead from the external
equipment to the +TX terminal on the DCA, and con­nect the minus output lead from the external equip­ment to the +IN terminal of the DCA. Do not use the

-IN when installing DCA's with the TX Option.

Supplement

Page S-1

Low Voltage Directive

The following guidelines must be followed in order to
comply with EN 61010-1 (Low Voltage Directive).
These items affect the AC versions of the following
products: DCA, DPS-240, DPS1200, ECA, ECS,
ECT, FCA, FDT, IST, PIT-4W, PWT, RBA, SCT,
SMP, SPA-CE. If these products are to be used in
a non-CE environment, this supplement may
be disregarded.

WARNING:

If this unit is used in a manner not specified
by Moore Industries, the protection provided

by the equipment may

be impaired.

Switches and Circuit Breakers

A switch or circuit breaker must be wired in series
with the AC power conductors. This switch or circuit
breaker must be located within three meters of
the unit.

WARNING:

Terminals on this unit may be connected to

hazardous voltages. Before making ANY

connections to this unit, ALL hazardous

voltages must be de-energized.

The circuit breaker or switch will only remove power
to the unit, hazardous voltages may still be con­nected to other terminals on the unit.

Equipment Ratings

Moore Industries transmitters do not generate haz­ardous voltages. They measure voltage or current
inputs, and generate low voltages and currents
(<42Vdc and <50mAdc). Products connected to
Moore Industries transmitters should be designed to
receive these inputs.

Moore Industries alarms do not generate any hazard­ous voltages. Alarm contacts are wired in series
with power sources and their intended loads.
The correct load should be selected for the
power source.

Supply Wiring

All power connections shall be made with 14 or 16
AWG (.083mm or .064mm) wire.

The end of each conductor should be stripped no
more than 8mm. The end of the stripped wire should
be tinned with solder or inserted into a ferrule and
crimped before being placed into a terminal block.

Conductors connected to screw type connections
must have a ring or spade lug crimped on the end of
the wire.

Protective Earth Conductor

The Protective Earth Conductor shall be of equal or
larger size wire than the other two power conductors.

The Protective Earth Conductor shall be the first
conductor connected to the unit when the unit is be­ing wired. It shall be the last conductor removed
when the unit is being un-wired.

Installation Category

All terminals are rated CAT II, except for terminals
with the -RF option. These terminals are
rated CAT I.

The Interface Solution Experts

Page S-2

Supplement

Maximum Working Voltage

Table 1-s shows the maximum working voltage for
Moore Industries’ low voltage products.

Table 1-s. Maximum Working Voltage

epyTtupnI gnikroWmumixaM

DTRdna,elpuocomrehT,tlovilliMcdV84

stupnIegatloVCDcdV84

stupnIegatloVCAcaV462

stuptuOgolanAcdV84

stcatnoCyaleRcaV462

slanimreTrewoPcaV711caV921

slanimreTrewoPcaV042caV462

stuptuOerusolCtcatnoCcdV03

egatloVegatloV

egatloVegatloV

egatloV

Accessories

Contact Moore Industries for information on suitable
accessories for our products.

Mounting

When mounting the unit or installing it into an appli­cation, ensure that the unit can be easily removed
for maintenance or repairs.

Cleaning and Maintenance

Maintenance on Moore Industries’ products is limited
to keeping the unit clean and the wire terminals free
of oxidation. This is best accomplished by install­ing the unit in an area protected from dust, heat,
moisture, and corrosive atmospheres. Yearly visual
inspections should be performed to ensure that the
unit is clean and the electrical connections are in
good repair.

Symbols

Table 2-s shows the symbols used on Moore Indus­tries’ products, the corresponding IEC/ISO symbol,
and its definition.

Table 2-s. Symbols on Moore Industries’ Products

OSI/CEI

lobmySlobmyS

lobmySlobmyS

lobmyS

deificepStoN

deificepStoN

erooMerooM

erooMerooM

erooM

tcudorPtcudorP

tcudorPtcudorP

tcudorP

SP+
SP–
CCD

CA

CCA

CDroCAtnerruCgnitanretlAdnatceriD

DNG

NI+
NI–

TUO+

TUO–

nolobmyS

seirtsudnIseirtsudnI

seirtsudnIseirtsudnI

seirtsudnI

noitinifeD

tnerruCtceriD

tnerruCgnitanretlA

lanimreThtraEdetcetorP

lanimreTrotcudnoCevitcetorP

ronoitalusnielbuodyb

tnelaviuqe(noitalusnidecrofnier

)635CEIfoIIssalCot

roflaunameeS(noituaC

)noitamrofni

tupnIevitisoP

tupnIevitageN

tuptuOevitisoP

tuptuOevitageN

tuohguorhtdetcetorptnempiuqE

Replacement of
Consumable Materials

No consumable materials are used in the Moore
Industries products covered by EN 61010-1.

deificepStoN

deificepStoN

deificepStoN

deificepStoNXTnoitaiticxErettimsnarT

ON
CN

MC

ONU
CNU

ONL
CNL

The Interface Solution Experts

nepOyllamroN

desolCyllamroN

nommoC

nepOyllamroNreppU

desolCyllamroNreppU

nepOyllamroNrewoL

desolCyllamroNrewoL

RETURN PROCEDURES

To return equipment to Moore Industries for repair, follow these four steps:

1. Call Moore Industries and request a Returned Material Authorization (RMA) number.

Warranty Repair –
If you are unsure if your unit is still under warranty, we can use the unit’s serial number
to verify the warranty status for you over the phone. Be sure to include the RMA
number on all documentation.

Non-Warranty Repair –
If your unit is out of warranty, be prepared to give us a Purchase Order number when
you call. In most cases, we will be able to quote you the repair costs at that time.
The repair price you are quoted will be a “Not To Exceed” price, which means that the
actual repair costs may be less than the quote. Be sure to include the RMA number on
all documentation.

2. Provide us with the following documentation:
a) A note listing the symptoms that indicate the unit needs repair
b) Complete shipping information for return of the equipment after repair
c) The name and phone number of the person to contact if questions arise at the factory

3. Use sufficient packing material and carefully pack the equipment in a sturdy shipping
container.

4. Ship the equipment to the Moore Industries location nearest you.

The returned equipment will be inspected and tested at the factory. A Moore Industries
representative will contact the person designated on your documentation if more information is
needed. The repaired equipment, or its replacement, will be returned to you in accordance with
the shipping instructions furnished in your documentation.

WARRANTY DISCLAIMER

THE COMPANY MAKES NO EXPRESS, IMPLIED OR STATUTORY WARRAN­TIES (INCLUDING ANY WARRANTY OF MERCHANTABILITY OR OF FITNESS
FOR A PARTICULAR PURPOSE) WITH RESPECT TO ANY GOODS OR SER­VICES SOLD BY THE COMPANY. THE COMPANY DISCLAIMS ALL WARRAN­TIES ARISING FROM ANY COURSE OF DEALING OR TRADE USAGE, AND
ANY BUYER OF GOODS OR SERVICES FROM THE COMPANY ACKNOWL­EDGES THAT THERE ARE NO WARRANTIES IMPLIED BY CUSTOM OR
USAGE IN THE TRADE OF THE BUYER AND OF THE COMPANY, AND THAT
ANY PRIOR DEALINGS OF THE BUYER WITH THE COMPANY DO NOT IM­PLY THAT THE COMPANY WARRANTS THE GOODS OR SERVICES IN ANY
WAY.

ANY BUYER OF GOODS OR SERVICES FROM THE COMPANY AGREES
WITH THE COMPANY THAT THE SOLE AND EXCLUSIVE REMEDIES FOR
BREACH OF ANY WARRANTY CONCERNING THE GOODS OR SERVICES
SHALL BE FOR THE COMPANY, AT ITS OPTION, TO REPAIR OR REPLACE
THE GOODS OR SERVICES OR REFUND THE PURCHASE PRICE. THE
COMPANY SHALL IN NO EVENT BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES EVEN IF THE COMPANY FAILS IN ANY ATTEMPT
TO REMEDY DEFECTS IN THE GOODS OR SERVICES , BUT IN SUCH CASE
THE BUYER SHALL BE ENTITLED TO NO MORE THAN A REFUND OF ALL
MONIES PAID TO THE COMPANY BY THE BUYER FOR PURCHASE OF THE
GOODS OR SERVICES.

ANY CAUSE OF ACTION FOR BREACH OF ANY WARRANTY BY THE
COMPANY SHALL BE BARRED UNLESS THE COMPANY RECEIVES
FROM THE BUYER A WRITTEN NOTICE OF THE ALLEGED DEFECT OR
BREACH WITHIN TEN DAYS FROM THE EARLIEST DATE ON WHICH THE
BUYER COULD REASONABLY HAVE DISCOVERED THE ALLEGED DE­FECT OR BREACH, AND NO ACTION FOR THE BREACH OF ANY WAR­RANTY SHALL BE COMMENCED BY THE BUYER ANY LATER THAN
TWELVE MONTHS FROM THE EARLIEST DATE ON WHICH THE BUYER
COULD REASONABLY HAVE DISCOVERED THE ALLEGED DEFECT OR
BREACH.

RETURN POLICY

For a period of thirty-six (36) months from the date of shipment, and under
normal conditions of use and service, Moore Industries ("The Company") will
at its option replace, repair or refund the purchase price for any of its manu­factured products found, upon return to the Company (transportation charges
prepaid and otherwise in accordance with the return procedures established
by The Company), to be defective in material or workmanship. This policy
extends to the original Buyer only and not to Buyer's customers or the users
of Buyer's products, unless Buyer is an engineering contractor in which case
the policy shall extend to Buyer's immediate customer only. This policy shall
not apply if the product has been subject to alteration, misuse, accident, ne­glect or improper application, installation, or operation. THE COMPANY
SHALL IN NO EVENT BE LIABLE FOR ANY INCIDENTAL OR CONSE­QUENTIAL DAMAGES.

Tel: [phone] • FAX: [phone]

Tel: [phone] • FAX: [phone]

© 2006 Moore Industries-International, Inc.

United States • [e-mail]

Australia • [e-mail]

Belgium • [e-mail]

Tel: [phone] • FAX: [phone]

Tel: [phone] • FAX: [phone]

The Netherlands • [e-mail]

Tel: [phone] • FAX: [phone]

Specifications and Information subject to change without notice.

China • [e-mail]

United Kingdom • [e-mail]

Tel: [phone] • FAX: [phone]
