Product Specifications
Model No: 83842, 83843, 83844, 83841, 83845, 83846, 83843-1X576, 83843-1X576, 83845-
2X576, 83846-2X576, 84061, 84062, 84064, 84065, 84061-1X576, 84062-1X576, 84064-
2X576, 84065-2X576, 83844-XXXX, 83846-XXXX, 83846-XXXX, 83907, 83908, 83906, 83909,
83910, 83849, 83850
Visionary Magnetic Glass Board
OVERVIEW
The Visionary Magnetic Glass Board provides the best of a quality
whiteboard with smart style.
BOARD
The marker board comes in a variety of sizes from 17.72” x 23.62” to
27.24” x 94.49”. Boards are made of 0.15” thick, tempered glass. Boards
are available in gloss white, gloss black, low-iron white, matte gray, red,
orange, yellow, green, blue, and navy. Visionary glass boards are backed
with 20 Ga steel to allow for the attachment of rare earth magnets.
MOUNTS
Silver finish wall mounts come standard with gloss white, gloss black,
and hierarchy colored boards. The mounts are made up of a 1” diameter
machined stainless steel cap attached with an M6 x 9mm stem to a 1”
diameter cast zinc board support. This assembly is attached to a stamped
sheetmetal back plate with two M4 x 6mm countersunk screws. Each
mount is attached to the wall with an M5 x 34mm pan head screw and
comes with masonry and drywall anchors. A set of four mounts come with
boards 47.24” x 47.24” and smaller, a set of 6 mounts for 47.24” x 70.87”
boards, and a set of eight mounts for 47.24” x 94.49” boards.
The Aluminum Exo Trays offer a 12 Ga aluminum 2.25” x 20” detachable
tray. The tray rests in a 23.75” long tackless display rail. A T-slot in the
tackless display holds two M6 x 10mm bolts. These bolts screw into two
12mm diameter 2.5” long standoffs which slot into 8” long board supports.
These board supports, as well as two on the top side of the markerboard
attach to the wall with two M5 x 34mm pan head screws each. Masonry
and drywall anchors are included. One exo tray is used on boards 35.43”
x 47.24” and smaller, two are used for boards 47.24” x 70.87” and larger.
Low-iron white boards and matte gray projection boards come standard
with two concealed Z bars that engage with two punched clips on the
back of the markerboards. Z bars are 16 Ga aluminum bars of varying
length attached to the wall with M5 x 34mm pan head screws. Masonry and
drywall anchors are included.
COLORS:
Black White Navy Blue Green Yellow Orange Red
Matte Gray
OPTIONS / ACCESSORIES
A glass accessory tray comes standard with low-iron white and matte
gray projection boards. The tray is 3.9” x 11.75” x .3845” tempered glass
and is cantilever mounted in two .845” diameter 1.2” long brackets with 1”
deep slots and M10 set screws. These brackets attach to the wall with one
M4 x 34mm countersunk screw each. Masonry and drywall anchors are
included. The glass tray is also available for purchase separately for use
with other boards.
Mounting standoffs with a brass fi
separately.
nish are available for purchase
COMPLIANCE
Indoor Advantage Gold certified.
Page 2
DIMENSIONS:
Base Model No. Description Dimensions
83842 Visionary Gloss White Magnetic Glass Board 17.72”H X 23.62”W
83843 Visionary Gloss White Magnetic Glass Board 23.62”H X 35.43”W
83844 Visionary Gloss White Magnetic Glass Board 35.43”H X 47.24”W
83841 Visionary Gloss White Magnetic Glass Board 47.24”H X 47.24”W
83845 Visionary Gloss White Magnetic Glass Board 47.24”H X 70.87”W
83846 Visionary Gloss White Magnetic Glass Board 47.24”H X 94.49”W
83843-1X576 Visionary Gloss White Exo Magnetic Glass Board 23.62”H X 35.43”W
83844-1X576 Visionary Gloss White Exo Magnetic Glass Board 35.43”H X 47.24”W
83845-2X576 Visionary Gloss White Exo Magnetic Glass Board 47.24”H X 70.87”W
83846-2X576 Visionary Gloss White Exo Magnetic Glass Board 47.24”H X 94.49”W
84061 Visionary Gloss Black Magnetic Glass Board 23.62”H X 35.43”W
84062 Visionary Gloss Black Magnetic Glass Board 35.43”H X 47.24”W
84064 Visionary Gloss Black Magnetic Glass Board 47.24”H X 70.87”W
84065 Visionary Gloss Black Magnetic Glass Board 47.24”H X 94.49”W
84061-1X576 Visionary Gloss Black Exo Magnetic Glass Board 23.62”H X 35.43”W
84062-1X576 Visionary Gloss Black Exo Magnetic Glass Board 35.43”H X 47.24”W
84064-2X576 Visionary Gloss Black Exo Magnetic Glass Board 47.24”H X 70.87”W
84065-2X576 Visionary Gloss Black Exo Magnetic Glass Board 47.24”H X 94.49”W
83844-XXXX Visionary Hierarchy Board 35.43”H X 47.24”W
83845-XXXX Visionary Hierarchy Board 47.24”H X 70.87”W
83846-XXXX Visionary Hierarchy Board 47.24”H X 94.49”W
83907 InSight Low Iron Magnetic Glass Board 23.62”H X 35.43”W
83908 InSight Low Iron Magnetic Glass Board 35.43”H X 47.24”W
83906 InSight Low Iron Magnetic Glass Board 47.24”H X 59.72”W
83909 InSight Low Iron Magnetic Glass Board 47.24”H X 70.87”W
83910 InSight Low Iron Magnetic Glass Board 47.24”H X 94.49”W
83849 InSight Projection Gray Magnetic Glass Board 47.24”H X 47.24”W
83850 InSight Projection Gray Magnetic Glass Board 47.24”H X 70.87”W
ACCESSORIES:
Base Model No. Description Dimensions
572 Glass Accessory Tray 1”H X 12”W X 4”D
B574V Brass Finish Mounts (set of 4) For Boards 47.24”H X 47.24”W And Smaller
B574V6 Brass Finish Mounts (set of 6) For Boards 47.24”H X 70.87”W
B574V8 Brass Finish Mounts (set of 8) For Boards 47.24”H X 94.49”W
MooreCo, Inc.
2885 Lorraine Avenue | Temple, TX 76501
p: 800.749.2258 | f: 866.888.7483
www.moorecoinc.com
Rev 10/11/18 CJE
