Moon W-7 Brochure

M O O N Evolution Series • P-7 + W-7

The leading edge in music & film reproduction

Simplicity, musicality, ease-of-use, and seamless hassle-free operation

are some of the qualities that come to mind when describing a

desireable preamplifier. Combine these with incredible sonic resolution

and a dead silent black background and you have the MOON P-7,

a dual-mono fully balanced preamplifier. Cutting edge technology

meets extreme build quality is perhaps the best way to sum it up.

Designed for the discerning audiophile who strives to get as close to

the music as possible without ever having to look back. Completing the

equation is flexibility – an RS-232 port, IR input and 12 volt triggers are

included to allow for seamless integration of the MOON P-7 into

virtually any listening environment.

RS-232 bi-directional port with unsolicited feedback compatible with industry leading external control and automation systems • SimLink controller port

allowing for 2-way communications between other compatible MOON Evolution series components • Fully differential, no global feedback circuit

topology, using no capacitors anywhere in the audio signal path • Individual “gain offset” for each line input with a ±10dB range • Each line

input is fully configurable to be “home-theater ready”, where the gain section of the P-7 is bypassed • Discrete M-eVOL gain circuitry with

130 individual volume steps in 1dB and 0.5dB increments • Power supply voltage regulation includes i

2

DCf (Independent Inductive DC Filtering);

1 inductor for each and every chip (i.e. OpAmp, DAC, Digital Filter, etc.) in the audio circuit’s signal path – 24 stages in all • Four-layer PCB tracings

with dedicated ground and power planes. The advantages include better ground and power supply circuit layouts resulting in a much shorter signal

path and a vastly improved signal-to-noise ratio

MOON P-7 Significant Design Features and Benefits:
