Moon W-5.3 Brochure

Technical information

P5.3 Specifications

Configuration 2-channel

Power Supply Transformers 2 x 10VA

Power Supply Capacitance 26,400µF

Circuit Topology Open Loop

Balanced inputs (XLR) 1 pair

Single-ended inputs (RCA) 4 pairs

Input Impedance 22,000 ohms

Input Sensitivity 200mV – 4.0V RMS

Balanced outputs (XLR) 1 pair

Single-ended outputs (RCA) 2 pairs (fixed and variable)

Output Impedance (RCA / XLR) 50 ohms / 100 ohms

Gain Control M-eVOL

Gain 9dB

Signal-to-noise Ratio (20Hz-20kHz) 109dB at full output

Maximum Output Voltage 12 Volts (XLR) / 6 Volts (RCA)

Frequency Response 5Hz – 100kHz +0/-0.1dB

Crosstalk @ 1kHz < -110dB

Intermodulation Distortion Unmeasureable

THD (20Hz - 20kHz) < 0.002%

Remote Control All Aluminum Full-Function (FRM-2)

Power Consumption at idle 6 watts

AC Power Requirements 120V / 60Hz or 240V / 50Hz

Shipping Weight 25 lbs / 11 kgs

Dimensions

Specifications subject to change without notice.

17.00” (w) x 3.92” (h) x 15.29” (d)

This M-eVOL volume circuit is based on a resistive array configuration and
employs a pair (for balanced circuitry) of highly-regarded BurrBrown PGA2310
volume control circuits which yield a very low inter-channel crosstalk in the

. As well, This circuit yields absolutely no measureable sonic degradation of the

P 5.3

audio signal regardless of the chosen volume setting.

All volume control circuits suffer from imperfect level matching between the left and
right channels, especially at low and high output levels. In simple terms this means
that the actual volume level is not identical for both channels at various setting

A high quality potentiometer-based volume circuit will typically have a variance of as
much as 1.5dB (red) between the left and right channels at the volume extremeties
as shown above. Our
consistent variance across the entire volume range of less that 0.05dB (blue); Signal
matching between channels is significantly more accurate over the entire volume
range as compared to a potentiometer type volume.

M-eVOL volume circuit maintains an extremely low and

MOON

Perfect level matching between channels that no othe

volume control can achieve ... Recorded music heard

as it was intended to be - pure, natural and uncolored.

P 5.3 Preamplifier
W 5.3 Power Amplifier

www.simaudio.com

Independent Inductive DC Filtering (I2DCf) is a unique type of DC voltage
regulation that Simaudio initially developed for the
components and has found its way into other
I2DCf uses one inductor, and is dedicated to each integrated circuit type component
(DAC, Op-Amp, etc.) in the audio circuit’s signal path. This unique voltage regulation
circuit achieves better noise filtering, substantially lower THD, improved channel
separation and lower crosstalk, a reduction in jitter for CD players, and more consis­tent DC voltage throughout the entire circuit as shown below. The end results are a
dramatically reduced noise floor, a dead quiet “black” background, a more realistic 3D
portrayal of the recording and perfect level matching between channels.

MOON Evolution series of

MOON audio components. A stage of

Sheer realism ... the genuine impression that the

musical performance is taking

place in your very own listening space ...

your audio system will feel as if its

effortlessly running on its own, without

any electricity.

Shown in silver; also available in black

MANUFACTURED IN CANADA

Distributed by:

Simaudio Ltd.

: 95 Chemin du Tremblay, Unit 3, Boucherville, Quebec CANADA J4B 7K4

Simaudio Ltd.

: 2002 Ridge Road, Champlain, NY 12919 US

[phone] [phone]
[e-mail] www.simaudio.com

A

LITHO CANADA

Graphic Design: Art•Image Communication Design Inc.

Power Emotion Soul

Four-layer circuit board tracings; The
advantages include better ground and
power supply circuit layouts resulting in a
much shorter signal path and dramatically
improved signal-to-noise ratio.

An oversized power supply.

M-eVOL volume control circuit based on
a resistive array configuration, resulting in
no sonic degradation of the audio signal
regardless of the selected volume setting.

Pure copper circuit board tracings with
extremely low impedance characteris

tics.

The MOON P 5.3 Preamplifier follows in the footsteps of the legendary, award
winning P-5. Representing a genuine leap forward from earlier
preamplifiers, the
series. Call it trickle-down technology if you will – the audio circuitry is based

MOON P-7 preamplifier. The result is incredible sonic transparency,

on the
a dead-quiet black background and genuine ease-of-use. Offering balanced

circuitry, 5 line-level inputs and an optional internal phono section with adjustable
gain, resistance and capacitance, the
heights with respect to the price-to-performance ratio.

With features such as a large and easily legible display, an IR input for external
control, a 12 Volt trigger output, a user configurable Home-Theater input and a lux­urious industrial-grade build quality, the
listening pleasure and unprecedented reliability as the control center for your
music system.

P 5.3 employs numerous advancements from our Evolutions

MOON P 5.3 pushes the envelope to new

MOON P 5.3 will provide for many years of

MOON series

MOON W 5.3 Power Amplifier boasts 150 watts per channel into 8 ohms and

The
300 watts into 4 ohms of continuous power output. It can easily be configured for
mono operation, yielding a robust 500 watts of power. This heir apparent to the
world-reknowned
Rennaisance” amplifier technology. The result is a warm, grain-free sound with
tight, authoritative bass, ultra-fast transients and incredible timbral accuracy. The
MOON W 5.3 will sound effortless at any output level.

A two-channel or multi-channel system built around the
for many years of high-performance operation and unprecedented reliabilty.
Housed inrugged yet elegant chassis, with a 12 Volt trigger input and balanced
audio circuitry, the

MOON high-performance amplification.

W-5.3 encompasses our award winning “Advanced

MOON W 5.3 will provide

W 5.3 represents the most affordable entry into the universe of

Simaudio Ltd. has been designing and manufacturing innovative, leading-edge
audio and video products since 1980.
recognized for their world-class performance, garnering numerous accolades
for this outstanding achievement. Our products are engineered and built in Canada,
utilizing advanced, efficient, "green" assembly techniques with strict quality control.
Furthermore, our manufacturing processes are part of our philosophy, whereas the
high quality and long-life of
environment, avoiding premature obsolesence.
international requirements for safety, performance and durability. At Simaudio, great
music matters. However, great music for a lifetime matters most.

P 5.3 Significant Design Features W 5.3 Significant Design Features

A 12 Volt trigger for remote operations.

Extremely rigid chassis construction to
minimize the effects of external vibrations.

Power supply voltage regulation includes
Evolution series i
DC Filtering) - 14 stages in all.

Extremely rigid chassis construction
to minimize the effects of external
vibrations.

• IR input for external control (all discrete codes)

and 12 Volt trigger output.

• An exceptionally short signal path measuring

only 10 inches in length from the rear panel's
input to output connectors, yielding a much
faster transient response.

• Open loop zero feedback circuit topology

using absolutely no capacitors anywhere in
the audio signal path.

• One single-ended audio input, of your choice,

which functions as a “pass-through”, bypass­ing the gain stage to accommodate a compo­nent such as a home-theater processor,
whose own volume control is used instead.

2

DCf (Independant Inductive

Pure copper circuit board tracings with
extremely low impedance characteristics.

Precision matched Bipolar output devices
which offer both high-current and superb
linearity throughout the entire audio
frequency spectrum (8 per channel).

A custom, oversized proprietary toroidal
transformer design with lower magnetic,
electrical and thermal loss, yielding an
Improved power transfer and lower
regulation factor, resulting in increased
current speed and better dynamics.

MOON products have been globally

MOON products are the best way to preserve our

MOON products meet or exceed all

A "zero global feedback" design resulting
in real-time amplification, a more accurate
musical reproduction with respect to tonality,
virtually non-existent intermodulation
distortion and the elimination of common
phase errors resulting from feedback.

• A very short signal path for a faster transient

response.

• A high damping factor which yields superior

musical dynamics, improved signal speed
and refined timbre accuracy.

• Stable to any known speaker impedance.

• "Class" A output to 5 watts for greater efficiency.

.

Technical information

W 5.3 Specifications

Configuration 2-channel

Power Supply Transformer 1.0kVA

Power Supply Capacitance 115,000µF

Class of Operation A/AB

Design Balanced Differential to output

Input Impedance 47,500 ohms

Input Sensitivity 1000mV

Output Device Type Bipolars – 8 per channel

Output Power at 8 ohms 150 watts per channel

Output Power at 4 ohms 300 watts per channel

Output Power – Bridged Mono 500 watts @ 8 ohms

Frequency Response 10Hz – 125kHz +0/-3dB

Output Impedance 0.01 ohms

Damping Factor (static) 800

Gain 31dB

Signal-to-noise Ratio > 100dB @ full power

Maximum Current 38A (Peak) / 20A (Continuous)

Crosstalk @ 1kHz -100dB

Intermodulation Distortion Unmeasureable

THD (20Hz - 20kHz @ 1 watt / 150 watts) < 0.02% / < 0.05%

Power Consumption at idle 45 watts

AC Power Requirements 120V / 60Hz or 240V / 50Hz

Shipping Weight 50 lbs / 22 kgs

Dimensions

Specifications subject to change without notice.

17.00” (w) x 7.70” (h) x 17.90” (d)

Without the blocking capacitors at the amplifier’s input, sound quality is improved as
the phase-shift caused by these capacitors is eliminated. Frequency response in
the bass region approaches 0Hz. As well, by removing all capacitors from the direct
audio signal path, ultimate soundstage focus is attained with less “smear’ or “blur”.

The frequency response curve in top figure is virtually flat throughout, and beyond,
the entire audible range as a result of the

MOON amplifiers. Conversely, the frequency response curve of a traditional

our
AC-Coupled amplifier design is far from perfect, as seen in the bottom figure; both low
and high frequencies in the audible range are noticeably diminished.

DC-Coupled circuit employed on

Deeper, more accurate and articulate bass ...

You will clearly distinguish

between a double-bass and an electric

bass in a heart-beat.

A power supply transformer with a tight regulation (low) factor assures that
power into more difficult speaker loads will be delivered closer to the theoretical
ideal. These transformers are significantly more expensive, but are the only way to
assure stability and consequently excellent sound quality under all conditions.

The three response curves in figure 3 demonstrate (i) a theoretically perfect transform
er regulation factor of 0% (green), whereby voltage remains stable regardless of the
current draw, (ii) a remarkably low regulation factor of 3% (black), found in

amplifier, where the voltage drops very slightly as the current draw increases

W 5.3

and (iii) a typical regulation factor of 10% (red), whereby, as the current draw increas­es, power supply voltage drops significantly, as found in most competing amplifier
designs.

MOON

Powerful musical passages are faithfully and

thoroughly reproduced in an effortless manner.
