M O O N Orbiter Universal Digital Player

The leading edge in music & film reproduction

The MOON Orbiter Universal Digital Player represents a genuine

high-end “all-in-one solution” for digital media playback. Capable of

processing the following disc formats: CD, SACD, DVD-Video,

DVD-Audio, Video CD, MP3-CD, CD-R/RW, DVD-R/-RW, the Orbiter

features a vast array of standard features such as virtually every

conceivable audio/video connector including DVI-D. The end result is

a non-compromising digital source component, yielding ground-

breaking audio and video performance, that will fill a common void in

most high-performance home entertainment systems.

Full function RS-232 port control for custom integration or automation • Advanced switch mode power supply with additional analog filtering and 8 stages

of voltage regulation, housed in an integral shield to ensure no high frequency noise will interfere with audio and video signals • DVI-D output for

progressive scan (480p) using SiI504 Video Scan Converter • Optional Serial Digital Interface (SDI) video output • S/PDIF (BNC & RCA), AES/EBU (XLR)

and Optical (Toslink) digital audio outputs • Audiophile-grade 24-bit/192kHz digital-to-analog converters (3) with 8X oversampling digital filter for 2 & 6

channel analog audio output • 10-bit/54MHz oversampled video with active current-to-voltage converter • "Rack mount ready" faceplate with

removeable aluminum cheeks to cover the holes when not in use • Front panel "VIDEO OFF" switch to disable all video circuitry, enhancing "audio only"

sonic performance • Support for both NTSC and PAL video formats • A complete array of various video output connections • Animated on-screen-

display menus • SRS Labs TruSurround™ 3D surround DSP effects for optional analog audio outputs • 1/8" IR Remote jack input for multi-room operation

• "Parental Control" setting to allow authorized access to specific DVD-Video discs • Extremely rigid chassis construction to minimize the effects of

external vibrations • Accurate matching of the high quality electronic components • Very short signal paths to maintain the integrity of audio and video

information • Designed to be powered up at all times for optimal performance • Low operating temperature for a longer than normal life expectancy.

MOON Orbiter Significant Design Features
