Distortion Pedal
1. TRUE BYPASS
3
Push down the f oot swi tch
to switch bet wee n effects
76
TONE
GAI N
5
6. VOLUME Kno b:
Adjust the vol ume o f the d ist ort ion sound.
7. TO NE Kn ob:
Adjust the ton e col or of t he di sto rtion sound.
8. GAIN Knob:
Adjust the gai n of th e dis tor tio n sound.
and bypass st atu s.
2. ON/OFF LED :
Instructs e ffe cts or bypass
8
status of CRU NCH ER, w hen
the LED is lit up , the e ffects is
4
on.
3. DC IN Power Ja ck:
Fo r pow er su pply, use a 9- vol t
DC regulate d AC ada pte r(p lug
polarity is p osi tiv e on th e bar rel
and negativ e in th e cen ter ).
4. INPUT Jack :
1/4” mono aud io ja ck, f or
connectin g gui tar.
5. OUTPUT Jac k:
1/ 4” mo no au dio j ack , outputs
the signal.
Footswitc h:
Main Features
A high gain distort ion s oun d wit h powerful mid freq uen cy
Full metal sh ell
Very small and exqu isi te
True bypass
DC 9V Adapter po wer s upp ly
Input: 1/4” m ona ura l jac k (im pedance: 1M )
Output: 1/4 ” mon aur al ja ck (i mpedance: 1k O hms )
Power Requi rem ent s: AC a dap ter 9V DC (cente r min us pl ug)
Current Draw: 7 mA
Dimension s: 93 .5m m (D) × 4 2mm ( W) × 52mm (H)
Wei ght : 160 g
Accessories: O wne r’s M anu al
* Dis claim er: Any s pecif icati on’s up date wo n't be am ended i n this ma nual.
Ohms
