THE PERFECT BALANCE OF FUNCTION, STYLE AND RELIABILITY
LAUNDRY - DISHWASHING - COOKING - COOLING
Freestanding 15cm
Slimline Wine Cooler
WS7SDX
Stainless Steel
Please read these instructions carefully before attempting to install or use this appliance.
It is advisable to keep these instructions in a safe place for future reference.
Installation and Operating Manual
Description Of
The Appliance
1
This diagram is only for informative purposes about
parts of the appliance. Parts may vary according to
the appliance mode.
1. Control Panel & Blue LED Display
2. Shelves (x 6)
3. T
empered Glass Door
4. Door Handle
5. Levelling Feet
6. Ventilation Panel
2
Introduction and
2 Year Guarantee
Thank you for choosing this Montpellier appliance.
It has been designed to give years of trouble-free
use provided it is installed and maintained correctly.
N.B. This appliance is intended to be used exclusively for
the storage of wine and is for DOMESTIC USE ONLY and
specically excludes, but is not limited to use in Wine
Bars, Pubs, Restaurants, Guest Houses, Hotels and
Catering Services.
Please read these instructions carefully before
installing or using your appliance. It is advisable to
keep your purchase and installation receipts with
these instructions in a safe place for future reference.
Included is some important safety information in addition
to guidelines and recommendations that will enable you
to take full advantage of all the functions available.
This quality appliance has been tested and
certied to meet all applicable UK electrical
and safety standards.
This appliance must be installed and connected
in accordance with current regulations by a
qualied electrician.
After unpacking the appliance ensure that there is
no visible damage. If the appliance has been
damaged during transit, do not use it, contact
your retailer immediately.
THE 2 YEAR MANUFACTURERS GUARANTEE
DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free
guarantee which protects you against the cost
of repairs during the rst 24 months from date
of purchase provided that:
Any claim is accompanied by evidence of the model
reference, model serial number and proof of purchase,
such as a Sales Receipt, showing that the appliance
was purchased within the 24 months prior to the
date of claim.
What is not covered under the Guarantee:
• Any appliance not correctly installed and operated in
accordance with the manufacturer’s instructions.
• Any appliance that is used for anything other than
domestic purposes.
• Any defect caused by accident, misuse, unauthorized
modication or inexpert repair.
• Cost of Call-out where a fault cannot be found with
the appliance.
• Cost of Call-out for work covering routine maintenance,
such as, but not exclusively, cleaning of lters
or defrosting.
• Cost of Call-out for work required to correct the
alignment of doors following door reversal procedures
carried out by you.
• Use of the appliance by anyone other than the
Householder.
• Use in any commercial environment.
• Consumable items, such as, but not exclusively, fuses
in plugs, bulbs and breakable items which require
routine replacement.
• Repair costs incurred that have not been authorised
by Montpellier Service.
• Repairs carried out by a non-approved Montpellier
Service engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK & ROI.
To Register your Appliance
Simply complete the card in your appliance pack and
return it with a stamp axed or alternatively you can
register online (please see link below).
Service Helpline
Should your appliance develop a fault, please call
Montpellier Service on: 03333 234 473
Please remember to have all your product details
available, including the serial number, before
registering a fault.
Your service call cannot progress without
this information.
Register your product online
www.montpellier-appliances.com/support/register-your-product
Contents
3
Section 1 : Safety Advice
Section 2: Installation
Section 3: Operating The Appliance
Section 4: Maintenance
4
5
6 - 7
8
4
Section 1: Safety Advice
• Please read this booklet thoroughly before
installing and switching on the appliance.
The manufacturer accepts no responsibility
for incorrect installation and usage.
• If this appliance is to replace an old
refrigerator with a lock; as a safety
measure break or remove the lock and/or
door before disposal.
• Your old appliances contain insulation
gases and refrigerant that must be
disposed of correctly. Please ensure that
the refrigerant circuit is not damaged before
the appliance is taken away for correct
disposal in line with current legislation.
If there is any doubt contact your Local
Authority for instructions.
• This appliance may contain the refrigerant
isobutene (R600a). This is a natural gas with
a high level of environmental compatibility;
however, caution is required as isobutene
is a ammable gas. It is essential to ensure
that refrigerant tubes are not damaged
during transportation and the installation
of the appliance. In the event that the
refrigerant circuit is damaged, avoid naked
ames or sources of ignition and ventilate
the room in which the appliance is situated.
• Do not damage the refrigerant circuit.
• The appliance shall not be used by children
aged from 8 years and above and persons
with reduced physical, sensory or
mental capabilities, or lack of experience
and knowledge, unless they have been
given supervision or instruction on how to
use the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.
• Do not allow children to play with the
appliance. Children must never play in
or around the appliance.
• If using an adaptor, this must be used in
accordance with the manufacturer’s
instructions and ensure that the electrical
circuit is not overloaded as this could
cause overheating.
• Do not twist or bend the cables, and keep
them away from hot surfaces.
• Do not plug ın or unplug this appliance with
wet hands.
• Following installation make sure that the
power cable is not trapped underneath
the appliance.
• If the power supply cord is damaged, it
must be replaced by the manufacturer, it’s
service agent or similarly qualied persons
in order to avoid a hazard.
5
Section 2: Installation
This appliance is intended to be used exclusively for
the storage of wine.
This appliance is designed for domestic use only and
should be operated in ambient temperatures (surround-
ing air temperature) between 16°C and 32°C (61-90°F). If
these temperatures are exceeded i.e. colder or warmer,
the appliance will not operate correctly.
2.1. Before Use
Remove all securing tapes. Wash the inside of the
appliance with lukewarm water with a little bicarbonate
of soda added (5ml to 0.5 litre of water). Do not use
soap or detergent as the smell may linger. Dry the
appliance thoroughly.
1.2. Installing the Door Handle
• Carefully ease the door seal to one side
• Attach the door handle using the two screws
• Ease the door seal back into place
1.3. Installation & Ventilation Requirements
To ensure correct operation this appliance must not be
located where the temperatures may fall below 16°C or
rise above 32°C. Avoid the following locations: unheated
kitchen, outhouse, conservatory, garage. For correct
operation this appliance must be installed:
• In a dry atmosphere
• Out of direct sunlight.
• Away from extreme temperature (not next to
a cooker or other sources of heat)
Ensure the following points are observed
during installation:
• The appliance must be placed on a strong oor
• The appliance must be level. Adjust the level by
screwing the adjustable foot up or down (use your
ngers or a suitable spanner)
• The appliance must be upright and in rm contact
with the oor so that the cabinet is stable.
• You must ensure that the Front Ventilation Panel
remains clear.
6
Section 3: Operating
The Appliance
3.1. Switching on the Appliance
• Allow the appliance to stand for a minimum of
4 hours after installation.
• Plug in the appliance and switch on at the mains
supply.
• Press and hold the Power button for 10 seconds
(To turn the unit o, simply press and hold the Power
button for 10 seconds).
• Set the temperature control to the required setting
as detailed in the Temperature Control section.
• Leave the appliance for approximately 4 hours for
the correct temperature to be reached.
• To lock the control panel, press and hold the Power &
Lighting buttons for 3 seconds. (Press and hold for 3
seconds to de-activate).
3.2. Temperature Control
Please note that this is a wine cooler and not a fridge.
This appliance is intended to be used exclusively for the
storage of wine. The interior of this appliance will not get
as cold as a fridge – it is designed to maintain wines at
the correct temperature. The temperature range
is 2°– 20°C.
• Press and hold the ‘+’ & ‘-’ buttons for 5 seconds to
change between Fahrenheit (°F) & Celsius (°C).
• Press the ‘Lighting’ button to turn on or turn o
the interior light.
• The temperature can be adjusted by pressing ‘+’ or
‘-’ and set between 2° and 20° C (36-68°F) (+/-3).
• After approximately 10 seconds, the display will
revert to showing the current temperature inside
the cabinet. N.B. It will take a period of time for the
appliance to reach the actual required temperature
following the setting or adjustment of the temperature on the control panel.
7
Section 3: Operating
The Appliance
3.3. Normal Operating Sounds
You may hear faint gurgling or bubbling sounds when the
refrigerant is pumped to the cooling system and through
the coils or tubing at the rear of the appliance. When the
compressor is in operation you may hear a slight whirring
sound or pulsating noise. The thermostat controls the
operation of the compressor, and you may hear a slight
click as it cycles in and out.
3.4. Energy Saving Advice
Do not install the appliance close to sources of heat,
such as a cooker, dishwasher or radiator. Locate the
appliance in a cool well-ventilated room and make sure
that the air vents are clear.
Try to avoid keeping the door open for long time, warm
air will enter the cabinet, and may cause condensation as
well as aecting the energy consumption. Ensure there
are no obstructions preventing the door from closing
properly
3.5. In the Event of a Power Failure
If there is a power failure, keep the door closed. When
the power has been restored the appliance will start to
operate but it may take some time to achieve the pre-set
operating temperature.
8
Section 4: Maintenance
Before any maintenance or cleaning work is
carried out, DISCONNECT the appliance from
the ELECTRICITY supply.
4.1. Internal Cleaning
Clean the inside and accessories with warm water and
bicarbonate of soda (5ml to 0.5 litre of water). Rinse
and dry thoroughly. Do not use detergents, abrasive
powders, highly perfumed cleaning products, wax
polishes or cleaning products containing bleach
or alcohol.
4.2. External Cleaning
Wash the outer cabinet with warm soapy water. Do NOT
use abrasive products. There may be sharp edges on
the underside of the product, so care should be taken
when cleaning. Once or twice a year dust the condenser
(black grille) and the compressor at the back of the
appliance, with a brush or vacuum cleaner, as an
accumulation of dust will aect the performance of
the appliance and cause increased energy consumption.
4.3. When the appliance is not in use
When the appliance is not in use for long periods, i.e.
nothing is being stored in the appliance, disconnect from
the electricity supply, clean the appliance, leaving the
door ajar until you wish to use the appliance again.
4.4. What to do if something goes wrong
There is no power to the appliance:
• Check there is not a power cut
• Check there is power to the electric
socket/appliance
• Check the fuse in the plug (Must be 13 amp)
• Check that the Temperature Control has been set
correctly (section 3.2.)
The compressor runs continuously:
• Is the door closed correctly?
• Have large quantities of bottles recently been added
to the appliance? –if yes, allow the interior
temperature to recover
• Has the appliance door been opened frequently?
– if yes, allow the interior temperature to recover
• Check that the Temperature Control has not been
set to maximum
There is excessive condensation and/or frost
build-up:
• Ensure that the door has been closed correctly
• Ensure that the door seal is clean and sealing
correctly
• Check that the Temperature Control has not been
set to maximum
The appliance is making a noise:
• Refer to Normal Operating Sounds, section 3.3.
• Ensure that the appliance has been installed
correctly (see section 2)
Notes
9
Notes
10
9
Help-line
If after the previous checks there is still a
fault, please contact the Montpellier Service
Help-line below.
Please ensure that you have the model
number, serial number
, date of purchase and
retailers information available before you
make the call.
Service Help-Line
Should your appliance develop a fault, please call
Montpellier Service on: 03333 234 473
Electrical connection (for UK type plug)
For your safety please read the following information.
Warning: This appliance must be earthed.
This appliance operates from 220-240 volts and
should be protected by a 13amp fuse in the plug.
The appliance is supplied with a standard 13 amp 3-pin
mains plug tted with a 13-amp fuse. Should the fuse
require replacement, it must be replaced with a fuse
rated at 13 amp and approved to BS1362.
Insurance
The warranty provided with this product does not
cover loss of food content.
Any claim for loss, damage, costs or expenses of
an indirect or consequential nature including any
economic loss or damage to foodstus or any
other goods is excluded. We recommend that you
inspect your appliance regularly to check that it is
working correctly, losses can result from deterioration
following breakdown or accidental failure of the
appliance, fuses, plugs or public electricity supply,
these can be covered by your standard home
insurance or might require extra cover.
Check with your insurance provider.
Important Note:
This appliance is marked according to the
European directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handling of this product.
The symbol on the product, or on the documents
accompanying the product, the Crossed Out Wheelie
Bin, indicates that this appliance may not be treated
as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of
electrical and electronic equipment.
Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment,
recovery and recycling of this product, please
contact your local authority, your household
waste disposal service or the retailer where
you purchased the product.
We continuously try to improve our products for the
bene
t of our customers. For this reason we reserve
the right to make changes to any product at any time,
without notice
Issue: 30/06/17
THE PERFECT BALANCE OF FUNCTION, STYLE AND RELIABILITY
LAUNDRY - DISHWASHING - COOKING - COOLING
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product,
please contact your local city oce, your household waste disposal service or the shop where you purchased the product.
www.montpellier-appliances.com
Montpellier Domestic Appliances Ltd.
Unit 1, Tewkesbury Retail Park, Northway Lane,
Tewkesbury, Gloucestershire GL20 8JU
Loading...
