Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Welcome
Thank you for choosing this Montpellier Induction Hob.
Our hobs have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Induction Hob to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Induction Hob is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your Hob,
you can rest assured that you are fully protected against the cost of repairs for the first 24 months . Please note that any claim must be accompanied by the
model reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can
be found on the rear of the machine.
There are two ways to register your Guarantee:
YEAR
GUARANTEE
PAR TS & LA BOU R
ACROSS ALL OUR MODELS
• Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
By Post: Simply detach and ll in the form provided, attach a stamp and send
•
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
www.montpellier-appliances.com
Note: We are unable to take registrations over the phone.
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the
operation and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
7.1. Energy Fiche ...............................................................................................................18
EN - 4
1. SAFETY INSTRUCTIONS
• Carefully read all instructions before using your
appliance and keep them in a convenient place for
reference when necessary.
• This manual has been prepared for more than one
model therefore your appliance may not have some
of the features described within. For this reason, it is
important to pay particular attention to any figures
whilst reading the operating manual.
1.1. General Safety Warnings
• This appliance can be used by children aged from 8
years and above and by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children should not play with the
appliance. Cleaning and user maintenance should
not be made by children without supervision.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Keep children less than 8
years of age away unless they are continually
supervised.
WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in fire.
NEVER try to extinguish such a fire with water, but
switch off the appliance and cover the flame with a lid
or a fire blanket.
WARNING: Danger of fire: Do not store items
on the cooking surfaces.
WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of electric shock.
EN - 5
• For induction hobs, metallic objects such as knives,
forks, spoons and lids should not be placed on the
hob surface because they can get hot.
• For induction hobs, after use switch off the hob
element using the control knob. Do not rely on the
pan detector.
• For models which incorporate a hob lid, clean any
spillages off the lid before use and allow the cooker
to cool before closing the lid.
• Do not operate the appliance with an external timer
or separate remote-control system.
• Do not use harsh abrasive cleaners or scourers to
clean oven surfaces. They can scratch the surfaces
which may result in shattering of the door glass or
damage to surfaces.
• Do not use steam cleaners for cleaning the
appliance.
• Your appliance is produced in accordance with all
applicable local and international standards and
regulations.
• Maintenance and repair work should only be carried
out by authorised service technicians. Installation
and repair work that is carried out by unauthorised
technicians may be dangerous. Do not alter or
modify the specifications of the appliance in any
way. Inappropriate hob guards can cause accidents.
• Before connecting your appliance, make sure
that the local distribution conditions (nature of the
gas and gas pressure or electricity voltage and
frequency) and the specifications of the appliance
are compatible. The specifications for this appliance
are stated on the label.
CAUTION: This appliance is designed only for
cooking food and is intended for indoor domestic
EN - 6
household use only. It should not be used for any
other purpose or in any other application, such as for
non-domestic use, in a commercial environment or
for heating a room.
• All possible measures have been taken to ensure
your safety. Since the glass may break, care should
be taken while cleaning to avoid scratching. Avoid
hitting or knocking the glass with accessories.
• Make sure that the supply cord is not trapped or
damaged during installation. If the supply cord is
damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in
order to prevent a hazard.
1.2. installation Warnings
• Do not operate the appliance before it is fully
installed.
• The appliance must be installed by an authorised
technician. The manufacturer is not responsible for
any damage that might be caused by defective
placement and installation by unauthorised people.
• When the appliance is unpacked, make sure that
it is has not been damaged during transportation. In
the case of a defect do not use the appliance and
contact a qualified service agent immediately. The
materials used for packaging (nylon, staplers,
Styrofoam, etc.) may be harmful to children and they
should be collected and removed immediately.
• Protect your appliance against atmospheric effects.
Do not expose it to effects such as sun, rain, snow,
dust or excessive humidity.
• Materials around the appliance (i.e. cabinets) must be
able to withstand a minimum temperature of 100°C.
EN - 7
• The temperature of the bottom surface of the hob
may rise during operation, therefore a board must
be installed underneath the product.
1.3. During Use
• Do not put flammable or combustible materials in or
near the appliance when it is operating.
Do not leave the cooker unattended while
cooking with solid or liquid oils. They may catch fire
under extreme heating conditions. Never pour water
on to flames that are caused by oil, instead switch the
cooker off and cover the pan with its lid or a fire
blanket.
• If the product will not be used for a long period of
time, turn the main control switch off. Turn the gas
valve off when a gas appliance is not in use.
• Always position pans over the centre of the cooking
zone, and turn the handles to a safe position so they
cannot be knocked or grabbed.
• Make sure the appliance control knobs are always in
the “0” (stop) position when it is not in use.
1.4. During Cleaning & Maintenance
• Make sure that your appliance is turned off at
the mains before carrying out any cleaning or
maintenance operations.
• Do not remove the control knobs to clean the control
panel.
• To maintain the efficiency and safety of your
appliance, we recommend you always use original
spare parts and to call our authorised service agents
in case of need.
EN - 8
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements listed
in the standards referenced.
This appliance has been designed to be used only for
home cooking. Any other use (such as heating a room) is
improper and dangerous.
The operating instructions apply to several models. You
may notice differences between these instructions and
your model.
Disposal of your old machine
This symbol on the product or on its packaging
indicates that this product should not be treated
as household waste. Instead it should be handed
over to the applicable collection point for the
recycling of electrical and
electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences for the environment and
human health, which could otherwise be caused by
inappropriate waste handling of this product. For more
detailed information about recycling of this product,
please contact your local city office, your household
waste disposal service or the retailer who you
purchased this product from.
EN - 9
2. INSTALLATION AND
PREPARATION FOR USE
WARNING: This appliance must be
installed by an authorised service
person or qualified technician,
according to the instructions in this
guide and in compliance with the current
local regulations.
•Incorrect installation may cause harm
and damage, for which the manufacturer
accepts no responsibility and the
warranty will not be valid.
•Prior to installation, ensure that the local
distribution conditions (electricity
voltage and frequency and/or nature of
the gas and gas pressure) and the
adjustments of the appliance are
compatible. The adjustment conditions
for this appliance are stated on the label.
•The laws, ordinances, directives and
standards in force in the country of use
are to be followed (safety regulations,
proper recycling in accordance with the
regulations, etc.).
hood)
Minimum
42 cm
Minimum
65 cm (with
Minimum 70
HOB
hood)
cm (without
Minimum
42 cm
•The appliance should not be installed
directly above a dishwasher, fridge,
freezer, washing machine or clothes
dryer.
•If the base of the appliance is accessible
by hand, a barrier made from a suitable
material must be fitted below the base of
the appliance, ensuring that there is no
access to the base of the appliance.
•If the hob is installed above an oven, the
oven should have a cooling fan.
•Make sure that the induction hob is well
ventilated and the air inlet and outlet are
not blocked.
2.1. inStruCtionS for the inStaller
General instructions
•
After removing the packaging material
from the appliance and its accessories,
ensure that the appliance is not
damaged. If you suspect any damage,
do not use it and contact an authorised
service person or qualified technician
immediately.
Make sure that there are no flammable
•
or combustible materials in the close
vicinity, such as curtains, oil, cloth etc.
which may catch fire.
The worktop and furniture surrounding
•
the appliance must be made of
materials resistant to temperatures
above 100°C.
•If a cooker hood or cupboard is to be
installed above the appliance, the safety
distance between cooktop and any
cupboard/cooker hood should be as
shown below.
2.2. inStallation of the hob
The appliance is supplied with an
installation kit including adhesive sealing
material, fixing brackets and screws.
•Cut the aperture dimensions as
indicated in the figure. Locate the
aperture on the worktop so that, after
the hob is installed, the following
requirements are followed.
W (mm)290min. A (mm)50
D (mm)520min. B (mm)50
H (mm)56E (mm)10
C1 (mm)270
C2 (mm)490
EN - 10
D
H
B
C1
W
A
C2
D
H
B
C1
W
E
E
C2
•Apply the supplied one-sided selfadhesive sealing tape all the way
around the lower edge of the cooktop.
Do not stretch it.
Separator
A
G
Worktop mounting
bracket
Self-adhesive
sealing tape
•Screw the 4 worktop mounting brackets
to the side walls of product.
EN - 11
•Insert the appliance into the aperture.
2.3. eleCtriCal ConneCtion anD Safety
WARNING: The electrical connection
of this appliance should be carried out
by an authorised service person or
qualified electrician, according to the
instructions in this guide and in compliance
with the current local regulations.
WARNING: THE APPLIANCE MUST
BE EARTHED.
•Before connecting the appliance to the
power supply, the voltage rating of the
appliance (stamped on the appliance
identification plate) must be checked for
correspondence to the available mains
supply voltage, and the mains electric
wiring should be capable of handling the
appliance’s power rating (also indicated
on the identification plate).
•During installation, please ensure
that isolated cables are used. An
incorrect connection could damage your
appliance. If the mains cable is damaged
and needs to be replaced this should be
done by a qualified person.
•Do not use adaptors, multiple sockets
and/or extension leads.
•The supply cord should be kept away
from hot parts of the appliance and must
not be bent or compressed. Otherwise
the cord may be damaged, causing a
short circuit.
•If the appliance is not connected to the
mains with a plug, a multi-pole isolator
switch (with at least 3 mm contact
spacing) must be used in order to meet
the safety regulations.
•The fused switch must be easily
accessible once the appliance has been
installed.
•Ensure all connections are adequately
tightened.
•Fix the supply cable in the cable clamp
and then close the cover.
•The terminal box connection is placed
on the terminal box.
Yellow+Green
Blue
PE
Brown
EN - 12
3. PRODUCT FEATURES
Important: Specifications for the product vary and the appearance of your
appliance may differ from that shown in the figures below.
List of Components
1. Induction
zone
2. Control Panel
1
2
EN - 13
4. USE OF PRODUCT
4.1. Control of hob
Control of the Induction zone
The information given in the following table
is for guidance only.
SettingsUse for
0Element off
1-3Delicate warming
4-5Gentle simmering, slow warming
6-7Reheating and rapid simmering
8Boiling, saute and searing
9Maximum heat
PBoost function
Cookware
•Use thick, flat, smooth bottomed
cookware that has the same diameter as
the element. This will help reduce
cooking times.
•Cookware made of steel, enamelled
steel, cast iron and stainless steel
(if appropriately labelled by the
manufacturer) will give the best results.
•Cookware with enamelled steel,
aluminium or copper bottoms can cause
a metallic residue to remain on the hob.
If left, this becomes difficult to remove.
Clean the hob after every use.
•Cookware is suitable for induction
cooking if a magnet sticks to the bottom
of it.
•Cookware must be placed centrally on
the cooktop. If it is not placed correctly,
is displayed.
•When using certain pans, you may hear
various noises coming from them, this is
due to the design of the pans and does
not effect the performance or safety of
the hob.
Circular Saucepan
Base
Small Saucepan
Diameter
Saucepan base that
has not settled
The appliance is operated by touching
buttons and the functions are confirmed
by displays and audible sounds.
Use the induction cooking zones with
suitable cookware.
After mains voltage is applied, all displays
are illuminated briefly. After this, the hob is
in stand-by mode ready for operation.
The hob is controlled by the pressing the
appropriate electronic button. Each button
press is followed by a buzzer sound.
Switching the appliance on
Switch the hob on by touching ON/OFF
button . All heater displays show a static
´0
` and the bottom right dots blink.
EN - 14
9
8
(If a cooking-zone is not selected within 20
seconds, the hob will automatically turn off).
Switching the appliance off
Switch the hob off at any time by touching
.
The ON/OFF button
always has priority
in the switch off function.
Switching the cooking-zones on
Touch the heater selection button that
corresponds to the heater you wish to
cook on. A static dot will be shown on the
selected heater display and the blinking
dots on all other heater displays will no
longer illuminate.
Select the temperature setting by using the
increase heat setting button
or decrease
heat setting button . The element is
now ready to cook on. For faster boil times,
select the desired cooking level and then
touch the P button to activate the Boost
function.
Switching the cooking-zones off
Select the element you want to switch off by
pressing the heater selection button. Using
button, turn the temperature down to
the
´0`. (Also, pressing the and buttons
simultaneously turns the temperature to
´0`).
If the cooking zone is hot, ´H` will be
displayed instead of ´0`.
Switching all cooking-zones off
To turn all the cooking zones off at once,
press the
button
In the stand-by mode, an ´H` appears on all
cooking zones which are hot.
Residual heat indicator
The residual heat indicator indicates that
the glass ceramic area has a temperature
that is dangerous to touch.
After switching off the cooking zone, the
respective display shows ´H` until the
corresponding cooking zone temperature is
at a safe level.
Smart Pause
Smart Pause, when activated, reduces
the power of all burners that have been
switched on.
If you then deactivate the Smart Pause,
the heaters will automatically return to the
previous level.
If the Smart Pause is not de-activated, the
cooktop will turn off after 30 minutes.
Touch (
) to activate Smart Pause. The
power for the activated heater(s) will reduce
to level 1 and ´II` will appear at all displays.
Touch (
) again to deactivate Smart
Pause. ´II` will disappear and the heaters
will now run at the level previously set.
Safety switch off function
A cooking zone will automatically be
swiched off if the heat setting has not been
modified for a specified duration of time. A
change in the heat setting of the cooking
zone resets the time duration to the initial
value. This initial value depends on the
selected temperature level.
Heat setting Safety switch off after
1-26 Hours
3-45 Hours
54 Hours
6-91.5 Hours
Child Lock
After switching on the appliance, the child
lock function can be activated. To activate
the child lock, simultaneously press the
increase heat setting button and
decrease heat setting button and then
press the increase heat setting key
again. ´L` indicating LOCKED will appear
on all heater displays and the controls
can not be used. (If a cooking zone is in
the hot condition, ´L`and ´H` will display
alternately).
The hob will remain in a locked condition
until unlocked, even if the appliance has
been switched off and on.
To deactivate the child lock, first switch
on the hob. Simultaneously press the
increase heat setting button
and
decrease heat setting button and then
press the decrease heat setting button
again.´L`will no longer be displayed and the
hob will be switched off.
Key Lock
The key lock function is used to set
‘save mode’ on the appliance during
operation. It will not be possible to make
any adjustments by touching the buttons
(for example heat settings). It will only be
possible to switch the appliance off.
The lock function is active, if the key lock
button
is pressed for at least 2 seconds.
This operation is acknowledged by a
buzzer. After successful operation, the key
lock Indicator flashes and the heater is
locked.
EN - 15
Buzzer
While the hob is in operation, the following
activities will be signalled by the buzzer:
•Normal button activation will be
accompanied with a short sound signal
•Continuous button operation over a
longer period of time (10 seconds)
will be accompanied with a longer,
intermittent sound signal.
Boost Function
To use this function, a cooking zone must
be selected,with the desired cooking level
set. Then press the P(Boost) button.
The Boost function can only be activated
if it is applicable with the cooking zone
selected If Boost Function is active a ´P` is
shown on the corresponding display.
Activating the booster can exceed the
maximum power, in which case the
integrated power management will be
activated.
The necessary power reduction is shown
by the corresponding cooking zone display
blinking. Blinking is active for 3 seconds
and allows further adaptations of the
settings before power reduction.
Error Codes
If there is an error, an error code will be shown on the
E1Cooling Fan is disabled. Call an authorised
E3Supply voltage is other than the rated values.
Turn the hob off by touching
disappears for all zones, turn the hob on by
touching and continue to use. If same error
is displayed again, call an authorised service
E4Supply frequency is different from the rated
values. Turn the hob off by touching
until “H” disappears from all zones, turn the
hob on by touching and continue to use. If
same error is displayed again, turn the plug
for the appliance off and on. Turn the hob on
by touching and continue to use. If same
E5Internal temperature of the hob is too high,
turn the hob off by touching
E6Communication error between touch control
and heater. Call an authorised service agent.
E7Coil temperature sensor is disabled. Call an
E8Cooler temperature sensor is disabled. Call
heater displays.
service agent.
,wait until “H”
agent.
, wait
error is still dispayed again, call authorised
service agents.
cool down.
authorized service agent.
an authorized service agent.
let the heaters
E9 Calibration error. Call authorised service
agent.
5. CLEANING AND
MAINTENANCE
5.1. CleaninG
WARNING: Switch off the appliance
and allow it to cool before cleaning is
to be carried out.
General Instructions
•Check whether the cleaning materials
are appropriate and recommended by
the manufacturer before use on your
appliance.
•Use cream cleaners or liquid cleaners
which do not contain particles. Do not
use caustic (corrosive) creams, abrasive
cleaning powders, rough wire wool or
hard tools as they may damage the
cooker surfaces.
Do not use cleaners that contain
particles, as they may scratch the
glass, enamelled and/or painted parts
of your appliance.
•Should any liquids overflow, clean them
immediately to avoid parts becoming
damaged.
Do not use steam cleaners for
cleaning any part of the appliance.
Cleaning the Ceramic Glass
Ceramic glass can hold heavy utensils but
may be broken if it is hit with a sharp object.
WARNING : Ceramic Cooktops - if the
surface is cracked, to avoid the
possibility of an electric shock, switch
off the appliance and call for service.
•Use a cream or liquid cleaner to clean
the vitroceramic glass. Then, rinse and
dry them thoroughly with a dry cloth.
Do not use cleaning materials meant
for steel as they may damage the
glass.
•Spilt sugary or sweet foods must be
cleaned immediately after the glass has
cooled.
•Dust on the surface must be cleaned
with a wet cloth.
•Any changes in colour to the ceramic
glass will not affect the structure or
EN - 16
durability of the ceramic and is not due
to a change in the material.
Colour changes to the ceramic glass
may be for a number of reasons:
1. Spilt food has not been cleaned off the
surface.
2. Using incorrect dishes on the hob will
erode the surface.
3. Using the wrong cleaning materials.
Cleaning the Stainless Steel Parts (if
available)
•Clean the stainless steel parts of your
appliance on a regular basis.
•Wipe the stainless steel parts with a soft
cloth soaked in only water. Then, dry
them thoroughly with a dry cloth.
Do not clean the stainless steel parts
while they are still hot from cooking.
Do not leave vinegar, coffee, milk, salt,
water, lemon or tomato juice on the
stainless steel for a long time.
EN - 17
6. TROUBLESHOOTING&TRANSPORT
6.1. troubleShootinG
If you still have a problem with your appliance after checking these basic tr
steps, please contact an authorised service person or qualified technician.
ProblemPossible CauseSolution
Hob control card’s display is
blacked out. The hob or
cooking zones cannot be
switched on.
The hob switches off while it is in
use and an 'F' flashes on each
The hob switches off while it is
working and the child lock LED is
The saucepans make noise
during cooking or your hob
makes a clicking sound during
The 'U'
display of one of the cooking
automatically reduced. If you
select power level 'P' or 9 on two
cooking zones, which are on the
same side, at the same time.
display.
use.
The hob controls are not
on.
cooking.
symbol lights up in the
zones.
Power level 9 or 'P' is
There is no power supply.
The controls are damp or an
object is resting on them.
One of the cooking zones has been
on for too long.
Child lock is active.Switch off the child lock.
This is normal with induction hob
cookware. This is caused by the
transfer of energy from the hob
to the cookware.
There is no pan on the
cooking zone, or the pan is
unsuitable.
Maximum power level for the two
zones is reached
Check the household fuse for the
Check whether there is a power cut by
trying other electronic appliances.
Dry the controls or remove the object.
You can use the cooking zone again
by switching it back on.
This is normal. There is no risk,
neither to your hob nor to your
Operating both zones at power level
'P' or 9 would exceed the permitted
maximum power level for the two
oubleshooting
appliance.
cookware.
Use a suitable pan.
zones.
6.2. tranSport
If you need to transport the product, use the original product packaging and carry it using
its original case. Follow the transport signs on the packaging. Tape all independent parts to
the product to prevent damaging the product during transport.
If you do not have the original packaging, prepare a carriage box so that the appliance,
especially the external surfaces of the product, is protected against external threats.
EN - 18
7. TECHNICAL SPECIFICATIONS
7.1. Energy Fiche
Brand
ModelINT300
Type of HobElectric
Number of Cooking Zones2
Heating Technology-1Induction
Size-1cmØ16,0
Energy Consumption-1Wh/kg189.0
Heating Technology-2Induction
Size-2cmØ20,0
Energy Consumption-2Wh/kg189.0
Energy Consumption of HobWh/kg189.0
This hob complies with EN 60350-2
Energy Saving Tips
Hob
- Use cookwares having flat base.
- Use cookwares with proper size .
- Use cookwares with lid.
- Minimize the amount of liquid or fat.
- When liquid starts boiling , reduce the setting.
EN - 19
Here For You
After-sales assistance
If you continue to experience problems with your Hob, please call the Montpellier customer service helpline on:
01759 487839.
Please have all your product details available, including the model number, serial number, date of purchase,
and your retailer’s details before registering a fault.
The service call cannot progress without this information.
Your 2 year Manufacturer’s guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the
rst 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such
as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date
of claim.
What is not covered under the Guarantee
• Any appliance not correctly installed and operated in accordance with the manufacturer’s instructions.
• Any appliance that is used for anything other than domestic purposes.
• Any defect caused by accident, misuse, unauthorised modification or inexpert repair.
• Cost of Call-out where a fault cannot be found with the appliance.
• Cost of Call-out for work covering routine maintenance, such as, but not exclusively, cleaning of filters or
defrosting.
• Cost of Call-out for work required to correct the alignment of doors following door reversal procedures
carried out by you.
• Use of the appliance by anyone other than the Householder.
• Use in any commercial environment.
• Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items which require
routine replacement.
• Repair costs incurred that have not been authorised by Montpellier and/or carried out by a non-approved
Montpellier engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK & ROI.
To register your appliance simply complete the card in your appliance pack and return it with a stamp axed or
alternatively you can register online at www.montpellier-appliances.com/support
Here For You
SERVICE HELP-LINE
Should your appliance develop a fault, please call the Montpellier customer service helpline on: 01759 487839.
Please remember to have all your product details available, including the model number, serial number, date of
purchase and your retailer’s details before registering a fault.
Your service call cannot progress without this information.
Montpellier Domestic Appliances Ltd.
Unit 1, Tewkesbury Retail Park, Northway Lane,
Tewkesbury, Gloucestershire GL20 8JU
www.montpellier-appliances.com
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product,
please contact your local city oce, your household waste disposal service or the shop where you purchased the product.
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
