Monoprice SSW-8, SSW-10, SSW-12 User Manual

MP SSW-8 8" Powered Slim Subwoofer
MP SSW-10 10" Powered Slim Subwoofer
MP SSW-12 12" Powered Slim Subwoofer
P/N 33829, 33830, 35847
User's Manual
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future
reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks
or other containers with moisture on or near the device. If moisture does get in
or on the device, immediately unplug it from the power outlet and allow it to
fully dry before reapplying power.
Do not touch the device, the power cord, or any other connected cables with
wet hands.
If operating this subwoofer in a humid environment, ensure that no
condensation occurs. Condensation could cause damage to the speaker cone
and could cause a short in the amplifier, which in turn could cause fire or severe
electric shock.
Do not subject the product to extreme force, shock, or fluctuations in
temperature or humidity.
Do not expose this device to excessively high temperatures. Do not place it in,
on, or near a heat source, such as a fireplace, stove, radiator, etc. Do not leave it
in direct sunlight.
Do not place or install this device in an area where it can be exposed to
excessive amounts of dust, humidity, oil, smoke, or combustible vapors.
Prior to operation, check the unit and power cord for physical damage. Do not
use if physical damage has occurred.
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
Disconnect the unit from the power source when replacing the fuse. Replace the
fuse only with the same type.
Unplug this device from the power source when not in use.
3
Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that
the power cord does not present a tripping hazard.
Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body.
Ensure that power is turned off and disconnected before making any electrical
connections.
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your
ordering, purchasing, and delivery experience is second to none. If you have any
problem with your order, please give us an opportunity to make it right. You can
contact a Monoprice Customer Service representative through the Live Chat link on our
website www.monoprice.com or via email at support@monoprice.com. Check the
website for support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service
for a replacement.
1x 8", 10", or 12" Powered Slim Subwoofer
1x User's Manual
4
PRODUCT OVERVIEW
SSW-8 (33829)
1. POWER MODE: Controls the power status of the subwoofer. The unit is powered
OFF when the switch is in the Off position. The unit is powered ON, regardless of
the presence of an audio signal or not, when the switch is in the On position.
When placed in the Auto position, the unit automatically powers ON when an
audio signal is detected and will automatically power OFF after several minutes
of no audio signal.
5
2. LINE IN/SUB IN: The two RCA jacks accept a line level signal from the
preamplifier output of a receiver or preamplifier. Use both jacks when
connecting a stereo preamplifier output. Use the L channel input when
connecting to a mono LFE subwoofer output.
3. PHASE: Depending on the location of the subwoofer, the sound that reaches
your listening position may be out of phase with the sound from the rest of the
system. If the bass sounds out of timing, muddy, or attenuated, try flipping the
phase switch to the other position. The default, which will provide the best bass
sound most of the time, is with the phase switch set to 0°.
4. LOW-PASS FILTER: The rotary control sets the upper frequency for the
subwoofer to handle, from 40-150 Hz. Initially, you should set the LOW-PASS
FILTER to the lower frequency for the main speakers, then adjust it until the
sound from the subwoofer blends in with the sound from the rest of the system.
5. VOLUME LEVEL: The rotary control adjusts the overall volume level of the
subwoofer. For best results, the subwoofer volume should be set to where it
seamlessly blends in with the sound from the other speakers.
6. SPEAKER LEVEL IN: If your amplifier or receiver does not have a stereo
preamplifier or mono LFE output, you can connect to its speaker output. This is
the least favored method of connecting the subwoofer.
7. 120V - 60Hz 1.0A: Plug the AC power cord into a nearby AC power outlet. The
subwoofer accepts a nominal 120 VAC, 60Hz power source.
6
SSW-10 (33830) and SSW-12 (35847)
1. OFF/ON: The power switch turns the subwoofer ON or OFF.
2. CROSSOVER: The rotary control sets the upper frequency for the subwoofer to
handle, from 50-150 Hz. Initially, you should set the CROSSOVER to the lower
frequency for the main speakers, then adjust it until the sound from the
subwoofer blends in with the sound from the rest of the system.
3. LINE IN/LINE OUT: The LINE IN RCA jacks accept a line level signal from the
preamplifier output of a receiver or preamplifier. Use both jacks when
connecting a stereo preamplifier output. Use the L channel input when
connecting to a mono LFE subwoofer output. The LINE OUT jacks pass-through
7
the original LINE IN signal without modification for connecting to another
powered subwoofer or amplifier.
4. HI LEVEL IN/HI LEVEL OUT: If your amplifier or receiver does not have a stereo
preamplifier or mono LFE output, you can connect its speaker output to the HI
LEVEL IN connectors. This is the least favored method of connecting the
subwoofer. The HI LEVEL OUT connectors pass-through the original amplified
signal for connecting the main speakers.
5. AC 120V/60Hz: Plug the AC power cord into a nearby AC power outlet. The
subwoofer accepts a nominal 120 VAC, 60Hz power source.
6. LEVEL: The rotary control adjusts the overall volume level of the subwoofer. For
best results, the subwoofer volume should be set to where it seamlessly blends
in with the sound from the other speakers.
7. POWER: The LED illuminates red when the subwoofer is plugged in and powered
on.
8. AUTO ON/ON: When set to the AUTO ON position, the subwoofer will
automatically power on when an audio signal is detected and will automatically
power off after several minutes of no audio signal. When set to the ON position,
the subwoofer powers on an off normally using the ON/OFF power switch. Note
that for the AUTO ON function to operate, the ON/OFF power switch must be
set to the ON position.
SUBWOOFER PLACEMENT
In most rooms, the optimum location for your subwoofer is the closest solid front
corner or somewhere along the front wall in line with your front speakers. This location
typically offers optimal energy coupling with the room, front speakers, and the deepest
low frequency extension, with the best high impact bass. Try to avoid a location that is
far away from walls or near the center of the room.
Bass output is maximized when the subwoofer is tucked into a corner. An ideal corner is
far from wall divisions and has at least 6 feet or more of wall to either side. Try to keep
the subwoofer placement away from any large openings into other rooms. When corner
loading a subwoofer, you might want to experiment with how close the subwoofer sits
to the closest wall, with a general rule of thumb that it should be within about 1 foot.
8
Placing the subwoofer in close proximity to the seating position, such as next to or
behind the sofa, maximizes the output and can reduce room effects.
A great technique for determining the best placement for your subwoofer is known as
the Subwoofer Crawl. The first step is to place the subwoofer at your listening position.
Ensure that audio with constant bass content or a test tone is playing. Next, crawl
around the room (after all, the subwoofer will not be 5 or 6 feet in the air) and listen for
where the bass sounds most full, with definition, punch, and depth. This will generally
be the best location for your room and listening position. Finally, place the subwoofer in
that location and complete the reset of your setup and configuration.
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with
any questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come
online to talk to one of our friendly and knowledgeable Tech Support Associates.
Technical support is available through the online chat button on our website
www.monoprice.com or through email by sending a message to tech@monoprice.com.
Check the website for support times and links.
9
SPECIFICATIONS
SSW-8 (33829)
Model
33829
Inputs
Mono LFE, stereo line level, and speaker
level
Woofer Size
8"
Frequency Response
30Hz ~ 150Hz (-10dB)
Low-Pass Filter
40Hz ~ 150Hz @ 18dB/octave
Phase Control
0° or 180°
Output Power
100 watts
Total Harmonic Distortion
< 0.5%
Dimensions
21.3" x 15.7" x 6.2" (540 x 400 x 158 mm)
SSW-10 (33830)
Model
33830
Inputs
Mono LFE, stereo line level, and speaker
level
Woofer Size
10"
Frequency Response
25Hz ~ 150Hz (-10dB)
Low-Pass Filter
50Hz ~ 150Hz @ 18dB/octave
Phase Control
0° or 180°
Output Power
150 watts
Total Harmonic Distortion
< 0.5%
Dimensions
25.0" x 15.7" x 7.0" (635 x 400 x 178 mm)
10
SSW-12 (35847)
Model
35847
Inputs
Mono LFE, stereo line level, and speaker
level
Woofer Size
12"
Frequency Response
20Hz ~ 150Hz (-10dB)
Low-Pass Filter
50Hz ~ 150Hz @ 18dB/octave
Phase Control
0° or 180°
Output Power
150 watts
Total Harmonic Distortion
< 0.5%
Dimensions
29.9" x 19.7" x 7.0" (760 x 500 x 178 mm)
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the
equipment no longer complying with FCC requirements for Class B digital devices. In
that event, your right to use the equipment may be limited by FCC regulations, and you
may be required to correct any interference to radio or television communications at
your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
11
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Loading...
