Monoprice 38038 User Manual

Bluetooth Audio Receiver and Car Charger

Combo Kit

P/N 38038

User's Manual

SAFETY WARNINGS AND

GUIDELINES

Please read this entire manual before using this

device, paying extra attention to these safety

warnings and guidelines. Please keep this manual

in a safe place for future reference.

• Do not expose this device to water or

moisture of any kind. Do not place drinks or

other containers with moisture on or near the

device. If moisture does get in or on the

device, immediately power it off and allow it

to fully dry before reapplying power.

• Do not touch the device, the power cord, or

any other connected cables with wet hands.

• If operating in a humid environment, ensure

that no condensation occurs. Condensation

could cause damage and could cause a short

in the electrical components, which in turn

could cause fire or severe electric shock.

• Do not expose this device to excessively high

temperatures. Do not place it in, on, or near a

heat source, such as a fireplace, stove,

radiator, etc. Do not leave it in direct sunlight.

• Do not place or install this device in an area

where it can be exposed to excessive amounts

of dust, humidity, oil, smoke, or combustible

vapors.

• Prior to operation, check the unit and power

cord for physical damage. Do not use if

physical damage has occurred.

• Before plugging the unit in, ensure that the

outlet provides the same type and level of

power required by the device.

• Ensure that power is turned off and

CUSTOMER SERVICE

disconnected before making any electrical

connections.

• Clean using a soft, dry cloth only. Do not use

chemical cleaners, solvents, or detergents. For

stubborn deposits, moisten the cloth with

warm water.

• This device has no user serviceable parts. Do

not attempt to open, service, or modify this

device.

The Monoprice Customer Service department is

dedicated to ensuring that your ordering,

purchasing, and delivery experience is second to

none. If you have any problem with your order,

please give us an opportunity to make it right. You

can contact a Monoprice Customer Service

representative through the Live Chat link on our

website www.monoprice.com or via email at

PACKAGE CONTENTS

[e-mail]. Check the website for

support times and links.

Please take an inventory of the package contents

to ensure you have all the items listed below. If

anything is missing or damaged, please contact

Monoprice Customer Service for a replacement.

1x 38038 Bluetooth Receiver

1x User’s Manual

1x USB Charging Cable

PRODUCT OVERVIEW

OPERATION

Power On/Off - Charging

MFB button

MFB button

Note: The device can be operated

while charging via the micro USB port.

• Power On: Plug the Receiver’s 3.5mm male jack

into the auxiliary port of your vehicle or

speaker. Hold the

The LED indicator light will flash and the

device will note “Power On.”

for 3 seconds.

• Power Off: Press the

and the device will power off.

for 3 seconds

• When the battery reaches a low enough level

the device will indicate “low battery” and will

also notify compatible connected devices.

• Connect the Receiver to the included vehicle

adapter or use the Micro USB Port to charge

the device.

Bluetooth® Pairing

MFB button

blue.

MP38038.

blue

blue

Functions

MFB

button

• Paring Mode: When pairing for the first time,

make sure the device is off, then press the

Indicator light flashes

Bluetooth settings on your device and search

for “

Indicator light will slowly flash

a successful pairing then stay solid

for 3 seconds until the LED

” After a short delay, the LED

Open the

, indicating

.

• Play/Pause: A quick, single press of the

will play or pause the current track.

• Next/Previous Track: Press the “>” button to

skip to the next track. Press the “

go back to the previous track.

<“ button to

• Increase Volume: Press and hold the “+”

MFB button

MFB button

MFB

button

MFB button

button

• Decrease Volume: Press and hold the “-“

button

• Answer/End Incoming Calls: When receiving

an incoming call, a quick, single press of the

hold of the

incoming call.

will answer the call. A 2 second

will reject the

• Redial: In Standby Mode, double click the

to redial the last outgoing phone

number.

• Switch from 38038 to the Connected Device

during a call: Press and hold the

for 2 seconds during the conversation.

SPECIFICATIONS

Model 38038

Bluetooth Version

Bluetooth Profiles

Bluetooth Pairing

Name

Bluetooth Range 26 feet (8 meters)

Frequency Range 2.402GHz-2.480GHz

Battery Capacity 300mAH

Talk Time ≈5.5 hours

Audio Playing Time ≈7 hours

3.0

HSP, HFP, A2DP,

AVRCP

MP38038

Standby Time ≈150 hours

(34 x 34 x 99mm)

Operating

Temperature

Product Dimensions

Product Weight 1.9oz (54.5g)

14-131° F

1.3 x 1.3 x 3.9 in

TECHNICAL SUPPORT

www.monoprice.com

[e-mail]

Monoprice is pleased to provide free, live, online

technical support to assist you with any questions

you may have about installation, setup,

troubleshooting, or product recommendations. If

you ever need assistance with your new product,

please come online to talk to one of our friendly

and knowledgeable Tech Support Associates.

Technical support is available through the online

chat button on our website

or through email by sending a message to

support times and links.

. Check the website for

REGULATORY COMPLIANCE

Notice for FCC

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

Modifying the equipment without Monoprice's

authorization may result in the equipment no

longer complying with FCC requirements for Class

B digital devices. In that event, your right to use

the equipment may be limited by FCC regulations,

and you may be required to correct any

interference to radio or television

communications at your own expense.

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses and

can radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference to

radio communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning

the equipment off and on, the user is encouraged

to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

Radio Notice for FCC

Caution

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced

radio/TV technician for help.

This FCC Part 15 radio device operates on a non-

interference basis with other devices operating at

this frequency. Any changes or modification to

said product not expressly approved by

Monoprice, including the use of non-approved

antennas, could void the user’s authority to

operate this device.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

The Bluetooth® word mark and logos are registered

trademarks of Bluetooth SIG, Inc.
