Monoprice 2T2R User Manual

-1-

Contents

Chapter 1 Product Introduction ................................................... 3

1.1 Package Contents ................................................................. 3

1.2 LED Indicator Description ...................................................... 3

1.3 Product Features ................................................................... 3

1.4 Product Usage ....................................................................... 4

1.5 Before Installation .................................................................. 5

1.6 Disable other manufacturers’ wireless network adapters ...... 5

1.7 Product Maintenance ............................................................. 6

Chapter 2 Installation Guide ....................................................... 7

2.1 Hardware Installation ............................................................. 7

2.1.1 Install the USB network adapter ..................... 7

2.1.2 Install the PCI network adapter ...................... 7

2.2 Software Installation ............................................................... 8

Chapter 3 How to use the Windows Built-in Wireless

Configuration............................................................................ 12

3.1 Wireless Network Connection under Windows XP .............. 12

3.2 Wireless Network Connection under VISTA ........................ 16

3.3 Wireless Network Connection under Windows 7 ................. 19

Chapter 4 Wireless Utility ......................................................... 22

4.1 Station mode (Client Mode) ................................................. 22

4.1.1 Available Networks .............................................................. 23

4.1.2 Link Information .................................................................. 25

4.1.3 Profile Settings .................................................................... 27

4.1.4 Advanced ............................................................................. 37

4.1.5 About ................................................................................... 38

4.2 AP mode .............................................................................. 38

-2-

4.2.1 Config AP ............................................................................ 40

4.2.2 Advanced ............................................................................. 41

4.2.3 Access Control List .............................................................. 42

4.2.4 Associate List ....................................................................... 43

4.2.5 AP Mode under Windows 7 .................................................. 44

Appendix 1: Acronyms and Terms ............................................ 46

Appendix 2: How to Set WPS ................................................... 47

Appendix 3: How to connect with PSP ..................................... 55

Appendix 4 :FAQ ...................................................................... 59

Appendix 5 :Regulatory Information ........................................ 63

-3-

Chapter 1 Product Introduction

Thank you for choosing this Monoprice wireless adapter!
The Monoprice wireless adapter supports IEEE wireless
standards, and is able to quickly process file transfer, video,
multi-media and other applications that require higher
bandwidth.
This Monoprice wireless adapter also integrates wireless
configuration program, which makes it easy and quick to set up
the wireless client. Besides, Soft AP is supported for fast
wireless network establishment, and WPS encryption supported
for you to quickly encrypt and secure your wireless network.
All in all, the Monoprice wireless adapter is easy-to-use, and of
robust signal, long transmitting distance.

1.1 Package Contents

One Wireless network adapter
One Software CD (includes user guide and driver)
The above list is for your reference only,the actual contents may
differ according to the product you purchase.

1.2 LED Indicator Description

There is one status LED indicator on the side of the wireless
network adapter. It lights up and stays ON when working
correctly, and flashes when transferring data.

1.3 Product Features

 Supports soft AP feature

-4-

 Detects wireless network and adjusts transmitting rate

automatically

 Provides two working modes: Infrastructure and Ad-Hoc
 Supports WEP data encryption and WPA-PSK/WPA2-PSK

encryption methods

 Supports WPS (Wi-Fi Protected Setup) encryption to

secure your wireless network

 Complies with Windows 7/XP/ 2000/Vista, Linux, MAC OS,

etc.

1.4 Product Usage

This Monoprice Wireless Adapter offers a fast, reliable and
extendable solution for wireless access.
It is mostly used in the following circumstances:

Enables staff members who require higher mobility, to have
access to the wireless network anywhere inside their company.
Enables wireless communication for companies or places which
are not suitable for wired LAN installation because of budget or
building environment restrictions, such as historical buildings,
rentals, or places for short-term usage.
Suitable for Enterprises or individuals requiring to regularly
alter the networking topology
Helps enterprises or individuals who would like to use wireless
to establish wireless network quickly and frees them from the
trouble of cable distribution.

-5-

1.5 Before Installation

1.Please read through the whole user guide before you install
and use this product.

2.Please close or uninstall the configuration programs of other
manufacturers’ before you install the configuration programs of
Monoprice network adapters to avoid possible UI (user interface)
conflict.

3.To avoid possible network conflicts between this Monoprice
network adapter and those of other manufactures’, we
recommend that you first disable the network adapters of other
manufacturers before installaing the driver.

1.6 Disable other manufacturers’ wireless network
adapters

1. Right click “My Computer” and select “Manage”

2. On the Computer Management screen ,select “ Device
Manager” － “Network adapters”, and right click the network
adapter you want to disable and click “Disable”

-6-

3. Click the “Yes” button on the dialogue box to disable the
network adapter.

1.7 Product Maintenance

Please keep the product away from water and humid
environment to guarantee its normal performance
Protect it against hazardous substances (such as acids, alkalis
etc).
Please don’t directly expose the adapter to the sunlight or
excessive heat.
Please contact Monoprice tech support if any problems occur.

-7-

Chapter 2 Installation Guide

This chapter will guide you through the process of installing the
network adapter software package, with the included software
CD. The package integrates driver and configuration software.
Thus, when you are installing the driver, the configuration
software will be installed automatically as well.
The software installation steps and operating guide in this user
guide are explained under Windows XP, Installation steps for
other operating systems are similar.

2.1 Hardware Installation

2.1.1 Install the USB network adapter

Please insert the Wireless USB Adapter into the USB port of
your computer.

2.1.2 Install the PCI network adapter

Insert the wireless adapter into the PCI slot of your computer
when it is turned off and then start it(Please make sure the PCI
adapter’s “gold fingers” are clean. If the PCI adapter can not
be identified after being inserted into the mainboard slot,or the

-8-

adapter can not scan signals after the driver being installed,
please shut down your computer and clean the adapter，and
then re-install).

2.2 Software Installation

2.2.1When The “Found New Hardware Wizard” system dialogue
pops up, we recommend that you select” Cancel” and use the
included Setup Wizard software CD for fast installation.

2.2.2 Put the included software CD into the CD drive of your
computer ,and the driver should run automatically , a Welcome
screen should pop up, just click the “RUN” button.( Double click

“wizard.exe”in the software CD and manually install when it
doesn’t auto-run).

-9-

2.2.3 Select “I accept the terms of the license agreement” and
click “Next”.

2.2.4 Two set up types are provided: one is “Install driver
only” ,the other is “Install driver and Monoprice WLAN Utility”.

-10-

NOTE: you may select the first method when you are
accustomed to use the WINDOWS built-in wireless
configuration program.However, this program doesn’t support
AP mode, WPS, and the WPS button on the wireless adapter. To
use these advanced features, the second method is
recommended.

2.2.5 Click “Install” to begin the driver installation.

-11-

2.2.6 Click “Finish” to complete the installation.

-12-

Chapter 3 How to use the Windows

Built-in Wireless Configuration

This chapter explains to users who don’t install Monoprice
configuration program how to use Windows Built-in Wireless
Configuration to connect to the wireless network .
Use of the Windows Built-in Wireless Configuration requires
enabling Wireless Zero Configuration service(the default is
enabled).

3.1 Wireless Network Connection under Windows
XP

1. Right click “My Network Places” on the desktop and select
“Properties”.

-13-

2. Open the network connection.Right click “Wireless Network
Connection” and select “View Available Wireless Networks” as

shown below.

3. On the right of the screen displayed are the currently
scanned wireless networks. If the one you want to connect has
not been scanned, click “Refresh Network List” to update the
network list.

4. Select the wireless network you want to connect, and click
“Connect” or double click this wireless network. Input the key in
the key dialogue box (the key input is case-sensitive) then click
“Connect”.

-14-

NOTE: If the wireless device you are connecting to is not
encrypted, the key dialogue box will not pop up.
When it shows “Connected” as the picture below, then you can
enjoy wireless access to Internet now.

-15-

6. You can modify wireless network key from “Change advanced
settings”.

7. Select “Wireless Networks”and choose the one you want to
modify, and then click “Properties”.

-16-

8. Modify the key in the appearing dialogue box.

3.2 Wireless Network Connection under VISTA

1. Click the Wireless Connection icon in the lower right corner of
your desktop and select “Connect to a network” as shown
below.

-17-

2．Select the wireless network you wish to connect and click
“Connect” or double click the wireless network to connect. Click
the Refresh icon in the upper right corner to update the network
list if you don’t find the specified wireless network.

3. If the wireless network that you are connecting has enabled
security mode, you’ll be prompted to enter the network
key .Click “Connect” after you enter the correct key.

-18-

The following screen will appear after successfully connected to
the wireless network.

If you want to change the wireless network key, just right click
the wireless network’s SSID and then select “Properties”.

You can modify the key from the appearing dialogue box.

-19-

3.3 Wireless Network Connection under Windows 7

Click the wireless connection in the lower right corner of the

computer’s desktop to view the available wireless networks.

Select the wireless network you wish to connect and click

“Connect” or double click the wireless network to connect. If
you don’t find the specified one, please click the refresh icon in

the upper right corner to update the list.
