Monoprice 24760 User Manual
Caliber+ 60-Watt 6.5-inch Fiber 2-Way Powered
Ceiling Speakers with Bluetooth®
P/N 24760
User's Manual
CONTENTS
SAFETY WARNINGS AND GUIDELINES ....................................................................................................................................... 3
INTRODUCTION ................................................................................................................................................................................................ 3
FEATURES .............................................................................................................................................................................................................. 4
CUSTOMER SERVICE .................................................................................................................................................................................... 4
PACKAGE CONTENTS ................................................................................................................................................................................. 4
PRODUCT OVERVIEW ................................................................................................................................................................................. 5
PAINTING ............................................................................................................................................................................................................... 6
INSTALLATION TOOLS ............................................................................................................................................................................... 6
INSTALLATION .................................................................................................................................................................................................. 7
BLUETOOTH PAIRING ................................................................................................................................................................................. 9
FINE TUNING THE SOUND .................................................................................................................................................................... 10
TROUBLESHOOTING .................................................................................................................................................................................. 10
TECHNICAL SUPPORT ................................................................................................................................................................................ 11
SPECIFICATIONS ............................................................................................................................................................................................. 11
REGULATORY COMPLIANCE .............................................................................................................................................................. 12
Notice for FCC .......................................................................................................................................................................................... 12
Notice for Industry Canada ........................................................................................................................................................... 12
2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. If moisture does get in
or on the device, immediately unplug it from the power outlet and allow it to fully
dry before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
If operating this speaker in a humid environment, ensure that no condensation
occurs. Condensation could cause damage to the speaker cone and could cause a
short in the amplifier, which in turn could cause fire or severe electric shock.
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
Ensure that power is turned off and disconnected before making any electrical
connections, including speaker wire connections.
INTRODUCTION
Thank you for purchasing this Powered Ceiling Speaker with Bluetooth®! Ceiling speakers
are the ideal combination of sound quality and styling. Rather than cluttering the room
with large box speakers trailing speaker wires, the speakers are virtually invisible, while
filling the room with high fidelity audio. Featuring a removable and paintable magnetic
grille, this 2-way speaker uses a DuPont™ Kevlar® woven fiber cone woofer with rubber
surround for deep, impactful bass, and a 0.75" silk titanium dome tweeter with 15° pivoting
action for smooth, sweet highs.
3
FEATURES
6.5" DuPont™ Kevlar® woven fiber cone woofer
0.75" silk titanium dome tweeter with 15° pivoting action
Includes both master and slave speakers
Dual 30-watt (RMS) power amplifiers for driving the master and slave speakers
Includes wired RCA and wireless Bluetooth® connections
8 ohms nominal impedance
60Hz ~ 20kHz frequency response
90dB sensitivity
Removable and paintable magnetic grille
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at support@monoprice.com
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Master speaker
1x Slave speaker
1x AC power adapter and AC cord
1x Cutting template
2x Speaker grilles (installed)
1x User's Manual
4
