INTRODUCTION
Thank you for purchasing this Blackbird™ 4K 4x4 HDMI® Matrix Switch! This matrix allows
you to independently distribute any of four HDMI inputs to any of four displays. It includes
an IR remote control and allows for front panel, IR, RS232, and TCP/IP control using the
web-based GUI. The LCD screen on the front panel shows the real-time connection status.
Rear panel DIP switches allow for manual control of the EDID information sent to the
source devices. It features a maximum video resolution of 4K@60Hz 4:4:4, including 1080p
3D video. It is fully compliant with the HDMI 2.0 and HDCP 2.2 standards.
FEATURES
Independently distributes any of four HDMI® sources to any of four HDMI displays
Includes four digital coaxial S/PDIF outputs
Supports video resolutions up to 4K@60Hz 4:4:4, including 1080p 3D video
Includes an IR remote control and allows for front panel, IR, RS232, and TCP/IP
control using the web-based GUI
Features DIP switches for manual EDID management
Front panel LCD screen shows real-time connection information
4
Page 5
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at support@monoprice.com
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x 4K 4x4 HDMI® matrix
1x IR remote control
1x IR receiver
1x RS232 cable (3-pin to DB9)
2x Mounting brackets
6x Mounting screws
4x Plastic feet
1x AC power adapter (24 VDC, 1.25A)
1x User's manual
5
Page 6
PRODUCT OVERVIEW
FIRM WARE
INPU TS
OUTP UTS
12
34
12
46
3
5
1 2 3 4
ON DIP
INPU TS
OUTP UTS CONT ROL
SPDIF SPDIF SPDI F SPDI F
12
3
4142
3
On
Off
1 2 3 4
1
0
Tx Rx
TCP/ IPEDIDIR IN R S 232DC 24V
4
5
12
3
Front Panel
1. FIRMWARE: Micro USB port for performing firmware updates.
2. POWER LED: The LED illuminates red when power is on. It illuminates green when in
standby mode and flashes red when upgrading the firmware.
3. IR: IR "eye" for receiving signals from the included IR remote control.
4. SYSTEM MONITOR: LCD screen displays the real-time connection status.
5. INPUTS: Four buttons for selecting the input source.
6. OUTPUTS: Four buttons for selecting the output channel.
Rear Panel
1. INPUTS: Four HDMI® jacks for connecting the source devices.
2. OUTPUTS: Four HDMI jacks for connecting the displays and four digital coaxial
S/PDIF jacks for connecting an external amplifier or receiver.
3. CONTROL: DIP switches for setting manual EDID management. RS232 connector for
connecting to a computer for RS232 control. 3.5mm IR IN jack for connecting the
included IR receiver. RJ45 jack for TCP/IP control using the built-in web-based GUI.
4. DC 24V: DC barrel connector for connecting the included AC power adapter.
6
Page 7
5. GROUND: Ground connection.
Remote Control
1. STANDBY: Press the button to power the matrix on or to put it into
standby.
2. INPUTS: Four numbered buttons for selecting the input source.
3. OUTPUTS: Four numbered buttons for selecting the output channel.
4. MENU: ALL button for selecting all inputs or outputs. EDID button for
EDID management. CLEAR button for canceling an operation. ENTER
button for confirming the operation.
SAMPLE CONNECTION DIAGRAM
7
Page 8
INSTALLATION
Perform the following steps to install your matrix:
1. Ensure that all equipment to be connected is powered off and unplugged from its
power source.
2. Place or mount the matrix in its intended location. Use the included mounting
brackets or plastic feet, as desired.
3. Using a High Speed HDMI® Cable (not included), plug one end into the HDMI input
on one of your displays, then plug the other end into one of the OUTPUTS on the
matrix. Repeat for the other three displays.
4. (Optional) Using a digital coaxial S/PDIF cable (not included), plug one end into the
digital coaxial input on your external amplifier or receiver, then plug the other end
into the SPDIF output on the matrix. Repeat for the other three SPDIF connections,
as desired.
5. Using a High Speed HDMI Cable (not included), plug one end into one of the INPUTS
on the matrix, then plug the other end into the HDMI output on one of your source
devices. Repeat for the other three source devices.
6. (Optional) If the IR "eye" on the front panel will be obstructed, plug the included IR
receiver into the IR IN jack on the matrix, then position the IR "eye" where it can
receive signals from the included IR remote control.
7. (Optional) If you will be controlling the matrix using a third party RS232 control
software (not included) on your PC, plug the included RS232 cable into the RS232
connector on the matrix, then plug the other end into a serial port on your
computer.
8. (Optional) If you will be controlling the matrix using the built-in web GUI, plug one
end of an Ethernet cable (not included) into the TCPIP jack on the matrix, then plug
the other end into either an Ethernet router or switch in your existing network
(recommended) or directly into the Ethernet jack on your PC (not recommended).
9. Plug the DC barrel connector on the included AC power adapter into the DC 24V
jack on the matrix, then plug the adapter into a nearby AC power adapter. The
8
Page 9
POWER LED on the front panel will illuminate green, indicating that the matrix is in
standby mode.
10. (Optional) Determine the maximum resolution and audio capabilities of your least
capable display (the one with the lowest resolution and fewest audio channels),
then set the DIP switches on the rear panel to the appropriate positions for the
video and audio capabilities. See the
how to set the DIP switches.
11. Plug in and power on all connected equipment. Start video playback on each source
device and verify that the video can be seen on each display. Use the IR remote
control to verify that you can switch each output to view the video from each input.
Refer to the
OPERATION
section for operating instructions.
EDID MANAGEMENT
section for details on
Congratulations, your new matrix is now installed and ready for normal operation.
CONNECTION STATUS
Press any of the four OUTPUTS buttons on the front panel. The LED for the connected
INPUT will briefly illuminate.
CONFIGURING FOR DIRECT TCP/IP CONTROL
If you connected the matrix to an Ethernet switch or router, there is nothing special that
needs to be done for TCP/IP control. Refer to either the
GUI Control
details.
However, if you connected the matrix directly to the Ethernet jack on your PC, you will
need to configure it to communicate with the matrix. Perform the following steps to
change the network connection settings:
1. Open Control Panel.
2. Click the Network and Internet option.
3. Click the View network status and tasks link.
portions of the
OPERATION
section below for connection and operation
9
TCP/IP Software Control
or
TCP/IP
Page 10
4. Click the Change adapter settings link.
5. Right click the Local Area Connection icon and select Properties from the menu.
6. Left click the Internet Protocol Version 4 (TCP/IPv4) entry, then click the Properties
button.
7. Click the radio button next to the Use the following IP address: entry, then input
the following:
IP Address: 192.168.0.178
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.0.1
8. Click the OK button to close the TCP/IPv4 Properties dialog, then click the Close
button to close the Local Area Connection Properties dialog.
10
Page 11
EDID MANAGEMENT
#
Switch
Video
Audio
0
0000
Pass-through (default)
1
0001
720p 2D
Pass-through
2
0010
720p 3D
Pass-through
3
0011
1080p 2D
Pass-through
4
0100
1080p 3D
Pass-through
5
0101
4K@30Hz
Pass-through
6
0110
4K@30Hz
2-channel
7
0111
4K@30Hz
7.1-channel
8
1000
4K@60Hz 4:2:0
Pass-through
9
1001
4K@60Hz 4:2:0
7.1-channel
10
1010
4K@60Hz 4:4:4
Pass-through
11
1011
4K@60Hz 4:4:4
7.1-channel
1111
Enable software EDID
management (RS232 or TCPIP)
The DIP switches on the rear panel allow you to set the EDID information that is passed to
the source devices. Use the following table to determine the settings for the DIP switches
for specific video resolution and audio capabilities. When in the down position, each
switch represents a 0, while putting the switch in the up position represents a 1.
11
Page 12
OPERATION
Front Panel
Perform the following steps to connect an input to one or more outputs.
1. Press the INPUTS button corresponding to the desired source device.
2. Press one or more of the OUTPUTS buttons, corresponding to the display(s) on
which you want to view the selected input.
3. The LED corresponding to the buttons pressed will blink three times if the operation
was successful. If not, the LEDs will remain off.
Examples:
To connect input 1 to output 3, press the INPUTS 1 button, then press the OUTPUTS 3
button.
To connect input 2 to both output 2 and output 4, press the INPUTS 2 button, then
press the OUTPUTS 2 button, followed by the OUTPUTS 4 button.
IR Remote Control
Perform the following steps to direct one of the inputs to one or more
outputs.
1. Press the numbered button in the INPUTS section of the remote
control corresponding to the desired source device.
2. Press one or more numbered buttons in the OUTPUTS section
corresponding to the display on which you want to view the
selected input. Alternatively, press the ALL button if you want
to view the selected input on all output displays.
3. Press the ENTER button in the MENU section to confirm the
operation. Alternatively, press the CLEAR button in the MENU
section if you want to cancel the operation.
12
Page 13
Examples:
To connect input 1 to output 3, press the 1 button in the INPUTS section, then press
the 3 button in the OUTPUTS section, and finally press the ENTER button.
To connect input 2 to both output 2 and output 4, press the 2 button in the INPUTS
section, then press both the 2 and 4 buttons in the OUTPUTS section, and finally
press the ENTER button in the MENU section.
Perform the following steps to manage the EDID settings for one or more inputs.
1. Press the EDID button in the MENU section.
2. Press one of the numbered buttons in the INPUTS section corresponding to the
source device you want to send the EDID information. Alternatively, press the ALL
button in the MENU section if you want to send the EDID information to all the
source devices.
3. Press the numbered button in the OUTPUTS section corresponding to the display
whose EDID settings you want to send to the selected source devices.
4. Press the ENTER button in the MENU section to confirm the operation. Alternatively,
press the CLEAR button in the MENU section to cancel the operation.
Examples:
To send the EDID information from display 3 to input 1, press the EDID button in the
MENU section, then press the 1 button in the INPUTS section, then press the 3
button in the OUTPUTS section, and finally press the ENTER button in the MENU
section.
To send the EDID information from display 4 to all the inputs, press the EDID button
in the MENU section, then press the ALL button in the MENU section, then press the
4 button in the OUTPUTS section, and finally press the ENTER button in the MENU
section.
13
Page 14
RS232 Control
For RS232 control you will need to connect your PC to the matrix using the included RS232
cable. You will also need to use a third party RS232 control software, such as CommWatch
(not included). The following image shows the basic interface of CommWatch.
Use the following communications parameters:
Baud Rate: 9600
Data Bits: 8
Stop Bits: 1
Parity: none
To allow for RS232 control, you must set the EDID DIP switches on the rear panel to 1111.
The matrix responds to the commands contained in the following table. Note that the
braces in the following commands (i.e., [ and ]) are not part of the commands and are used
only for clarity. The other punctuation marks ARE part of the commands.
14
Page 15
System Commands
Command
Function
Feedback Example
/*Type;
Query the model
XXXXX
/^Version;
Query the firmware version
VX.X.X
Demo.
Puts the matrix in "demo" mode,
which switches the inputs and
outputs every 2 seconds. After
switching through all inputs and
outputs, the matrix will return
to normal operation mode.
Demo Mode
AV:01->01
AV:01->02
AV:01->03
AV:01->04
AV:02->02
...
Normal Mode
Undo.
Cancels the current operation
Undo OK!
PWON.
Turns the matrix on
PWON
PWOFF.
Puts the matrix into standby
mode. Send the PWON
command to turn the matrix on.
PWOFF.
STANDBY.
Puts the matrix in standby
mode. Press any button to turn
the matrix on.
STANDBY
%9962.
Query the power status
STANDBY, PWOFF, or
PWON
%9964.
Query the IP address
IP:XXX.XXX.X.XXX
%0911.
Reset the matrix to the factory
defaults
Factory Default
15
Page 16
Lock/Unlock Commands
Command
Function
Feedback Example
/%Lock;
Lock the front panel buttons
System Locked!
/%Unlock;
Unlock the front panel buttons
System Unlock!
%9961.
Query the system lock status
System Locked! or Unlock!
Switching Commands
Command
Function
Feedback Example
[x]All.
Connect input [x] to all output
channels
X To All. (X=01~04)
All#.
Connect each input to the
corresponding output channel,
i.e., 1->1, 2->2, etc.
All Through.
All$.
Switch off all output channels
All Closed.
[x]#.
Connect input [x] to output [x}
X Through. (X=01~04)
[x]$.
Switch off output [x]
X Closed. (X=01~04)
[x]@.
Switch on output [x]
X Open. (X-01~04)
All@
Switch on all output channels
All Open.
[x1]V[x2].
Connect input [x1] to one or
several output [x2]. Separate
multiple output channels with a
comma.
AV:X1->X2 (X1/X2=01~04)
Status[x].
Query the connection status of
output [x]
AV:Y->X (X/Y=01~04)
16
Page 17
Switching Commands (continued)
Command
Function
Feedback Example
Status.
Query the connection status of
each input and output channel
AV:01->01
AV:01->02
AV:01->03
AV:01->04
%9971.
Query the connection status of
the inputs
In 01 02 03 04
Connect Y Y Y Y
%9972.
Query the connection status of
the outputs
Out 01 02 03 04
Connect Y Y Y Y
%9975.
Query the connection status of
the inputs and outputs
In 01 02 03 04
Out 04 04 04 04
%9976.
Query the output resolution
Resolution
Out 1 1920x1080P
Out 2 1920x1080P
Out 3 1920x1080P
Out 4 1920x1080P
Scene Commands
Command
Function
Feedback Example
Save[Y].
Save the current operation to
the preset command [Y]
Save to FY (Y=1-10)
Recall[Y].
Recall the preset command [Y]
Recall From FY (Y=1-10)
Clear[Y].
Clear the preset command [Y]
Clear FY (Y=1-10)
17
Page 18
HDCP Compliance
Command
Function
Feedback Examples
/%[Y]/[X]:[Z].
HDCP management command.
Y=output channel
X=input port Y=1~4 or ALL)
Z=HDCP status (1=compliant,
0=non-compliant)
/%Y/ALL:0.
%0801.
Auto HDCP management,
activate carrier native mode
%0801
%9973.
Query the HDCP status of the
input signals
In 01 02 03 04
HDCP Y N Y N
%9974.
Query the HDCP status of the
output signals
Out 01 02 03 04
HDCP Y N Y N
EDID Commands
(note that the DIP switches must be set to 1111 for these to work)
Command
Function
Feedback Examples
EDIDH[x]B[y].
Input port [y] learns the EDID
from output port [x].
If the EDID data is available and
the audio portion supports only
PCM, then force-set it to
support PCM mode only. If the
EDID data is not available, then
set it as initialized EDID data.
EDIDH1B1
EDIDPCM[x].
Set the audio for input port [x]
to PCM
EDIDPCM[x]
18
Page 19
EDID Commands (continued)
(note that the DIP switches must be set to 1111 for these to work)
Command
Function
Feedback Examples
EDIDG[x].
Get EDID data from output [x]
and display the output port
number
Hexadecimal EDID data and
carriage return character
EDIDMInit.
Restore the factory default EDID
data for each input
EDIDMInit.
EDIDM[X]B[Y].
Manual EDID switching. Enable
input [Y] to learn the EDID data
of output [X]. If the EDID data is
not available, then set it as
initialized EDID data.
EDIDM3B1
EDID/[x][y].
Set the EDID data of input port
[x] to built-in EDID # [y].
[y]=0~11 corresponding to the 12
embedded EDID settings. Refer
to the
EDID MANAGEMENT
section above.
EDID/[x]/[y]
EDIDUpgrade[x].
Upgrade EDID data through the
RS232 connection. [x]=input
port 1~4, 5=All input ports.
When the switch receives the
command, it will show a
message to prompt you to send
the EDID file (.bin file). The
operation will be canceled after
10 seconds.
Please send the EDID file
EDID Upgrade OK!
19
Page 20
EDID Commands (continued)
(note that the DIP switches must be set to 1111 for these to work)
Command
Function
Feedback Examples
GetInPortEDID[X]
Get the EDID data of input [X].
[X]=1~4
%9979.
Get the DIP switch status
EDID RS232 GUI CONTROL
1111
Digital Audio Commands
Command
Function
Feedback Example
DigitAudioON[x].
Enable SPDIF audio output port
[x]. [x]=1~4, 5=All ports
DigitAudio ON [x]/ALL
Outputs
DigitAudioOFF[x].
Disable SPDIF audio output port
[x]. [x]=1~4, 5=All ports
DigitAudio OFF [x]/All
Outputs
%9977.
Query the status of digital audio
for all output channels
Out 01 02 03 04
Audio Y Y Y Y
20
Page 21
TCP/IP Software Control
You can connect to the matrix using a third party TCP/IP control software program, such as
TCPUDP (not included). Use the following settings to connect to the matrix:
IP Address: 192.168.0.178
Port: 4001
21
Page 22
TCP/IP GUI Control
Username
Password
admin
admin
user
user
You can use the built-in web based GUI to control the matrix. To do so, open your internet
browser and type the following into the address bar:
192.168.0.178
You will be presented with the GUI login screen, as shown below:
There are two sets of usernames and passwords you can use:
After typing in the username and password, click the Login button
22
Page 23
Once you have logged in, you will see the Scene screen, as show below. This screen allows
you to select and load a previously saved "scene". Each "scene" is a saved configuration
preset. By default the matrix has no saved configuration presets.
To load a "scene", click one of the Scene buttons, then click the Load button.
Click the tab to display the Control screen. This screen allows you to direct specific
inputs to specific outputs and to save the result as a "scene".
To change a connection, first click one of the INPUT buttons, then click one of the OUTPUT
buttons, and finally click the Confirm button.
23
Page 24
If you want to direct the input to all outputs, first click one of the INPUT buttons, then click
the All button, and finally click the Confirm button.
Click the Clear button at any time prior to clicking the Confirm button to cancel the
change.
To save the current connection status as a "scene", first make the changes you want to
make, then use the Scene drop-down list to select a scene number, and finally click the
Save button.
Click the button to display the Configuration / Embedded EDID screen. This screen
allows you to set the EDID data for each input.
Use the drop-down lists next to each Input label to change the EDID for each specific
input, then click the Confirm button to save your changes.
Click the Cancel button at any time prior to clicking the Confirm button to cancel the
change.
24
Page 25
Click the EDID Copy radio button to display the Configuration / EDID Copy screen. This
screen allows you to copy the EDID data from one of the OUTPUT channels to one or all of
the INPUT devices.
To copy the EDID data, first click the radio button corresponding to the desired OUTPUT,
then click the radio button corresponding to the desired INPUT, and finally click the
Confirm button to make the change.
To copy the EDID data to all inputs, first click the radio button corresponding to the
desired OUTPUT, then click the To All Inputs radio button in the center, then click the
Confirm button.
Click the Cancel button at any time prior to clicking the Confirm button to cancel the
change.
25
Page 26
Click the Audio Out radio button to display the Configuration / Audio Out settings screen.
This screen allows you to enable or disable the S/PDIF outputs.
To enable or disable the S/PDIF audio output for any port, simply click the button to
change the status to ON or OFF.
Click the Status tab to display the Status / LCD screen. This screen allows you to change
the name and model that are displayed on the front panel LCD screen.
To change the name and model, simply click inside the text box, type in the desired name
and model, then click the Confirm button to save the changes.
26
Page 27
Click the Cancel button at any time prior to clicking the Confirm button to cancel the
change.
Click the Button radio button to display the Status / Button screen. This screen allows you
to change the name that is displayed on the front panel LCD screen for each INPUT and
OUTPUT.
To change the button names, simply click inside the text box, type in the desired name,
then click the Confirm button to save the changes.
Click the Cancel button at any time prior to clicking the Confirm button to cancel the
change.
27
Page 28
Click the Scene radio button to display the Status / Scene screen. This screen allows you to
change the names shown on the front panel LCD screen for each custom "scene".
To change the scene names, simply click inside the text box, type in the desired name, then
click the Confirm button to save the changes.
Click the Cancel button at any time prior to clicking the Confirm button to cancel the
change.
28
Page 29
Click the Network tab to display the Network screen. This screen displays the MAC address,
allows you to swap between DHCP and Static IP, and change the IP Address, Subnet Mask,
and Gateway addresses.
To change between DHCP and Static IP, click the button to toggle its position, then click
the Confirm button to save the change.
To change the IP Address, Subnet Mask, or Gateway, click simply click inside the text box,
type in the desired address, then click the Confirm button to save the change.
Click the Cancel button at any time prior to clicking the Confirm button to cancel the
change.
29
Page 30
Click the Password tab to display the Password screen. This screen allows you to change
the Admin and User passwords from their defaults of admin and user, respectively. It also
displays the GUI and Hardware version numbers and allows you to lock or unlock the front
panel controls.
To change a password, simply click inside the text box, type in the desired password, then
click the Save button to save the change.
To lock or unlock the front panel control, click the Front Panel button to change the status
to OFF or ON, as desired, then click the Save button to save the change.
Click the Cancel button at any time prior to clicking the Save button to cancel the change.
Click the button in the lower left corner to display the Scene screen. Refer to the
description of the Scene screen at the beginning of this section.
30
Page 31
TCP/IP PORT CONFIGURATION
While you can change the IP Address, Subnet Mask, and Gateway addresses using the
built-in GUI, you cannot make other network changes using the GUI. Instead, you need to
use the built-in WebServer to configure the IP Port, reset the IP addresses to the factory
default values, reset the password to the factory default, and update the firmware.
To access the WebServer, open your internet browser and type 192.168.0.178:100 into the
address bar. If you changed the default IP address, use the new on instead. Use admin for
both the Username and Password.
To upgrade the GUI firmware, click the Administration / Upload Program option. Next, click
the Browse... button and use the file browser to locate the update file. Finally, click the
Apply button to perform the upgrade.
USB FIRMWARE UPGRADE
In the event that a firmware upgrade is made available, perform the following steps to
upgrade the matrix.
1. Go to Monoprice.com, type 24179 into the search bar, then press the ENTER key or
click the search icon.
2. Download the .zip file containing the firmware upgrade program.
3. Extract the .zip file to get the DfuSe Demonstration firmware upgrade program.
31
Page 32
4. Download the .zip file containing the firmware upgrade file.
5. Extract the .zip file to get the .dfu firmware upgrade file.
6. Using a micro USB cable (not included), plug one end into one of your PC's USB
ports, then plug the other end into the FIRMWARE port on the front panel.
7. Using the included IR remote control, put the matrix into Standby mode.
8. While pressing and holding the INPUT 2 and INPUT 3 buttons, use the remote
control to power the matrix on. The Power LED will begin flashing red, indicating
that the matrix is in firmware upgrade mode. If it does not, put the matrix back into
standby mode and try again.
9. Double-click the DfuSe Demonstration icon to launch the firmware upgrade
program.
32
Page 33
10. Verify that the Leave DFU mode button is available. If not, your PC is not properly
connected and you should repeat the process starting at step 6 above.
11. Click the Choose... button. Use the file browser to locate and select the .dfu
firmware upgrade file.
12. Once the .dfu file is selected, the Upgrade button will be available. Click it to begin
the firmware upgrade process.
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to tech@monoprice.com
33
Page 34
SPECIFICATIONS
Model
24179
Inputs
4x HDMI®
Outputs
4x HDMI, 4x S/PDIF Digital Coaxial Audio
Maximum Resolution
4K@60Hz 4:4:4
HDMI Version
2.0
HDCP Version
2.2
Control Options
Front panel buttons, IR remote control, RS232
software, TCP/IP GUI, TCP/IP software
Input Power
24 VDC, 1.25A
AC Adapter Input Power
100 ~ 240 VAC, 50/60 Hz
Maximum Power Consumption
14 watts
Operating Temperature
+14 ~ +131°F (-10 ~ +55°C)
Operating Humidity
10 ~ 90% RH, non-condensing
Dimensions
17.2" x 9.3" x 1.7" (437 x 237 x 44 mm)
Weight
3.9 lbs. (1.75 kg)
REGULATORY COMPLIANCE
Notice for FCC
Modifying the equipment without Monoprice's authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
34
Page 35
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Blackbird™ is a trademark of Monoprice Inc.
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
PlayStation® is a registered trademark of Sony Computer Entertainment Inc. PS4™ is a
trademark of the same company.
35
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
