monolith MA 501-I User Manual
Paper Shredder
MA 501-I
User Manual
Before operating this unit, please read all instructions
1. Description of MA 501-I components .............................................................................................3
2. Technical Data ..........................................................................................................................................3
3. Safety instructions ...................................................................................................................................4
4. Safety symbols ..........................................................................................................................................4
5. Proper use ...................................................................................................................................................5
6. Motor protection ......................................................................................................................................6
7. Using the machine ..................................................................................................................................6
8. Machine malfunctions ...........................................................................................................................7
9. Cleaning ......................................................................................................................................................7
10. Storage .........................................................................................................................................................7
11. Disposal .......................................................................................................................................................8
12. Declaration of conformity .....................................................................................................................8
13. Limited Product Warranty .....................................................................................................................8
14. Warranty card ............................................................................................................................................9
Contents
Information on safety instructions
!
2
Items supplied / content of package
1x paper shredder
All safety instructions and other important information are highlighted in grey.
The item has safety features.
However, to avoid damage or injury, read the safety instructions carefully and only use the
shredder as described in this guide.
Keep the guide for future reference.
If you are giving the machine to someone else, please keep this guide with the product.
3
1. Description of MA 501-I components
2. Technical Data
1
Slide switch (REV/OFF/AUTO)
2
READY/ON light
3
Plug
4
extendable rail for xing to the waste container
5
Feed-in slot for paper
6
Paper sensor
3
Model MA 501-I
Dimensions (WxDxH) 302 x 113 x 68.5 mm
Weight approx. 0.93 kg
Working width 220 mm (DIN A4)
Cutting performance per operation up to 6 sheets max. (80 g/m
2
)
Speed 2.2 m per minute
Cutting type strip cut
Strip width 6 mm cutting width
Supported waste baskets 27.5 to 37.5 cm
Automatic start/stop function yes
REV reverse function yes
Rated operating time 1 minute
Rated nonoperating time 30 minutes
Decibel approx. 70 dB
Voltage AC 220 – 240 V; 50 Hz
Power consumption 190 W / 1.0 A
Protection class II
6
5
41 2
