MONOGRAM 30" INTEGRATED
REFRIGERATOR
ZIR301NBRII
FULLY INTEGRATED COLUMN DESIGN
With concealed hinge oers a look of seamless perfection that
installs ush with surrounding cabinetry
STATEMENT AND MINIMALIST COLLECTION
REFRIGERATOR HANDLES (SOLD SEPARATELY)
Designed to enhance choice and customization, Statement and
Minimalist Collection refrigerators do not come with handles.
Handles must be chosen separately and ordered through a
Monogram representative
PANEL-READY EXTERIOR WITH SIX-WAY
ADJUSTABILITY
Accepts Statement or Minimalist Collection stainless steel panels
ordered separately from Monogram or custom panel & handle
from your cabinet maker
RETROFIT CAPABILITY
Allows you to replace a 48" built-in side-by-side refrigerator
with two column refrigerators with no cabinet or electrical
modications
RAMP-UP LED INTERIOR LIGHTING
Throughout the fresh food compartment accentuates the
sophisticated interior and allows easy viewing of contents
REMOTE CONNECTIVITY VIA WIFI
Allows you to wirelessly control refrigerator settings from your
smartphone, using an available app
ADJUSTABLE, EDGE-TO-EDGE GLASS SHELVES
Provide convenient storage and a clean appearance
FINELY CRAFTED, ADJUSTABLE DOOR BINS WITH
CLEAR FRONTS
Oer easy access to beverages and quick-grab items
UPFRONT, ELECTRONIC-TOUCH CONTROLS
Make it easy to adjust climate settings to create ideal food
storage conditions
TEMPERATURE-CONTROLLED DRAWER
Oers added storage exibility with pre-programmed settings
for meat, beverage, and deli
SOFT-CLOSE DRAWERS
Use an innovative sliding mechanism to help the drawers close
gently and completely
HUMIDITY-CONTROLLED VEGETABLE DRAWER
Helps preserve the freshness of foods
DEDICATED EVAPORATOR SEALED SYSTEM
Helps maintain a precise temperature throughout the fresh
food compartment
SABBATH MODE
Designed to disable functions in accordance with
Sabbath-observing practices
For questions about your
appliance, please call 1-800-626-2000.
Product Specication Revised 10/21PAGE 1 OF 6
OVERALL DIMENSIONS
(75.1)
29 9/16"
24 3/4"
23 7/8"
22 1/4"
(62.9)
(60.6)
(56.5)
SPECIFICATIONS
Overall Width 29 9/16" (75.1 cm)
Overall Height 83 1/2" (212.1 cm)
Overall Depth 24 3/4" (62.9 cm)
Door Clearance at 90° 33 3/8" (84.8 cm)
Cutout Width 29 13/16" (75.7 cm)
Cutout Height 84" (213.4 cm)
Cutout Depth 25" (63.5 cm)
Plumbing Requirements GE SmartConnect kit
Net Weight (approx) 495 lb (224.5 kg)
ATTENTION ELECTRICIAN:
A 115 volt 60Hz., 15 or 20 amp power supply is required.
An individual properly grounded branch circuit or circuit
breaker is recommended. For multiple unit installation,
each unit requires separate individually properly
grounded circuit or breaker and separate properly
grounded 3-prong electrical receptacle recessed.
83 1/2"
(212.1)
3 5/8"
(9.2)
FRONT VIEW
29 1/4"
(74.3)
SIDE VIEW
TOP
VIEW
**Dim A
Door
** Dim A
Angle
(13)
5 1/8"
90°
16 9/16" (42.1)
115 °
** Dimensions based on handle height of 2 9/16" (6.5)
33 3/8"
(84.8)
** Allow 4 9/16" (11.6) min
clearance to a adjacent wall
from cutout
83 3/8"
(211.8)
WARNING:
When installing appliance, you must use and follow
the product installation instructions. These can be found
with unit or on web at monogram.com.
For questions about your
appliance, please call 1-800-626-2000.
PAGE 2 OF 6
Dimensions in parentheses are in centimeters unless
otherwise noted. Actual product dimensions may vary
due to manufacturing tolerances.
Product Specication Revised 10/21
