Monogram ZIFS240HSS Specsheet
SPECIFICATIONS
Overall Width 23 1/2" (59.7 cm)
Overall Height 34 1/8" (86.7 cm)
Overall Depth 23 3/16" (58.9 cm)
Door Clearance 9 3/8" (23.8 cm) @ 110°
Overall Capacity 5.4 cu. ft.
Minimum Cabinet
Width
Minimum Cabinet
Depth
Cutout Width 23 3/4" (60.3 cm)
Cutout Height 34 1/2" (87.6 cm) Min
Electrical
Requirements
Voltz/Hertz/Amps 120 V, 60 Hz,
Shipping Weight 126 lb (57 kg)
2" (5.1 cm) @ 90°
23 7/8" (60.6) door
length
23 3/4" (60.3 cm)
24" (61.0 cm)
35" (88.9 cm) Max
1.0 A
15 or 20 amp circuit
OVERALL DIMENSIONS
23 5/8" (60.0)
FRONT VIEW
25 1/2" (64.8)
23 1/2" (59.7)
21 3/4" (55.2)
SIDE VIEW
23 5/8" (60.0)
ZIFS240HSSMONOGRAM FRESH-FOOD REFRIGERATOR
34 1/8"
(86.7)
9 3/8"
(23.8)
ATTENTION ELECTRICIAN:
A 115 volt 60Hz., 15 or 20 amp power
supply is required. An individual properly
grounded branch circuit or circuit breaker
is recommended. Install a properly
grounded 3-prong electrical receptacle
recessed into the back wall.
Dimensions in
parentheses are in
centimeters unless
otherwise noted.
Actual product
dimension may
vary due to
manufacturing
tolerances.
TOP VIEW
(SHOWING
DOOR SWING)
Product Specification Revised 1/18
2"
(5.1)
23 7/8"
(60.6)
ZIFS240HSSMONOGRAM FRESH-FOOD REFRIGERATOR
ZIFS240PSS
STANDARD INSTALLATION
24" (61.0)
min cutout depth
34 1/2"
(87.6) min
underside of
counter to floor
35" (88.9) max
CUTOUT INSTALLATION
SIDE VIEW
REFRIGERATION MODULES, TOP VIEW
23 3/4" min.
Standard
Installation
CABINET CABINET
Dim. A
In a standard installation, the
product will project forward of
adjacent cabinets. See Dim. A.
Front Edge of
Product Case
Front Face
110º
120º
23 3/4" (60.3)
min standard
24" (61.0)
min flush inset
10 1/2" (26.7)
9"
(22.9) max
ELECTRIC
1 1/2" (3.8)
INSTALLATION CUTOUT
FRONT VIEW
24" min. width
stainless steel models
Flush
Installation
Filler panel or cleat to be set
back even with front of case.
CABINET CABINET
These products will fit flush to adjacent
cabinets when installed with a Dim. A - width
filler panel or cleat. The filler panel should be
recessed or set back behind the door and
even with the front edge of the product case.
Front Edge of
Product Case
Front Face
Dim. A
110º
120º
NOTES
Installation Space: This
module can be installed
beneath a countertop
or can be used freestanding.
For a standard
installation of stainless
steel unit: The product
must be installed so
that the front face will
project 2-5/8" forward
of adjacent cabinets.
For a flush installation
of stainless steel unit:
Install a 1" wide filler
strip on the hinge
side. The width of
the opening must be
24" min. wide. See
installation instructions
for details.
Location Requirements:
All Monogram
Refrigeration Modules
may be closed in on
the top and sides as
long as the front is
unobstructed for air
circulation and door
swing.
• Do not install these
products where the
temperatures will go
below 55° F (13 C) or
above 90° F (32 C).
• Products must operate
from separate properly
grounded receptacles.
• These products are
not designed to be
stacked one over the
other.
See installation
instructions for side-byside information.
PRODUCT DIM. A
ZDWI240, ZDB1240 2"
ZDWR240, ZDBR240 1-3/4"
ZIFS240, ZIF1240 1-5/8"
ZDOD240 1-7/8"
ZIB1240, ZIBS240 2-5/8"
PRODUCT DIM. A
ZDWI240, ZDB1240 1"
ZDWR240, ZDBR240 1"
ZIB1240, ZIF1240 1"
ZIFS240, ZIBS240 1/4"
ZDOD240 1-1/4"
