ZET2PHSS
Monogram 30" Built-In Double Oven
OVERALL DIMENSIONS
ZET2PHSS
SPECIFICATIONS
Overall Width 29 3/4" (75.6 cm)
Overall Height 53 1/16" (134.7 cm)
Overall Depth
Including Handle
Oven Door Clearance 20 9/16" (52.3 cm)
Overall Oven
Interior Capacity
Oven Interior Dimensions
(W x H x D) each oven
Minimum Cabinet Width* 30" (76.2 cm)
Minimum Cabinet Depth* 24" (61.0 cm)
Minimum Base Support 375 lbs. (170 kg)
Cutout Width*
Cutout Height*
Cutout Depth* 23 1/2" (59.7 cm) Min
Volts/Hertz/Amps 240/208 V AC, 60 Hz, 40A
Conduit Length
Electrical Rating
Shipping Weight 390 lbs. (178 kg)
*Additional space will be needed for flush installation.
27 1/2" (69.9 cm)
10.0 cu. ft. (283.2 liters)
25" x 17 3/8" x 20 1/4"
(63.5 x 44.1 x 51.4 cm)
28 1/2" (72.4 cm) Min
28 5/8" (72.7 cm) Max
51 13/16" (131.6 cm) Min
51 15/16" (131.9 cm) Max
40" (72" available special
order: WB18T10398)
6.8 kW at 208V
9.0 kW at 240V
5 3/16"
53 1/16"
(134.7)
overall
height
29 3/4" (75.6)
28 1/2" (72.4)
min cutout width
(13.2)
21 1/2"
(54.6)
1/2"
(1.3)
25 1/2"
(64.7)
22 1/2"
(57.2)
(SHOWING CUTOUT OVERLAP)
5/8"
(1.7)
27 1/2"
(70.0)
SHOWING DOOR CLEARANCE
28 7/16"
(72.2)
OPEN OVEN DOOR
12"
(30.5)
10 1/2"
(26.6)
15/16"
(2.5)
4 1/16"
(10.3)
51 13/16"
cutout height
4 1/16"
(10.3)
1/4"
(0.6)
5/8"
(1.7)
2 3/4"
(7.0)
(131.6) min
8 3/8"
(21.4)
20 9/16"
(52.3) min
1 3/8" (3.5)
7 15/16"
(20.2)
2 5/16"
(6.0)
24 11/16" (62.7)
14 15/16"
(38.0)
3 7/16"
(8.8)
SIDE VIEWFRONT VIEW
8 3/8"
(21.4)
1 7/8"
(4.8)
ATTENTION ELECTRICIAN:
A 240/208V, 60Hz, 40 Amp circuit is required. An
individual properly grounded branch circuit or
circuit breaker is required. Hard wired junction
box is required for built-in product.
TOP VIEW
Dimensions in parentheses
are in centimeters unless
otherwise noted. Actual product
dimensions may vary due to
manufacturing tolerances.
Product Specification Revised 7/15
23 1/2" (59.7)
min cutout depth
12"
(30.5)
Recommended
cutout location
from floor
51 13/16"
(131.6)
53 7/16"
(135.7)
24 7/8" (63.2)
min cutout depth
29 3/4" (75.6)
cutout width
30 1/4" (76.8)
3 1/4"
(8.3)
9 1/2"
(24.1)
2 1/2"
(6.4)
Side cleats
depth
1 3/8"
(3.5)
30 1/4" (76.8) flush inset width
with
1/4" (0.6) reveals
13/16"
(2.1)
Top cleat
15/16"
(2.4)
Side cleats
3/8" (1.0) Bottom cleat
(Extends full depth of cabinet)
STANDARD
INSTALLATION
ELEC.
ZET2PHSS
top
cleat
side
cleat
bottom
cleat
TOP VIEW
FLUSH INSET
INSTALLATION
FLUSH INSET INSTALLATION
FRONT VIEW
ZET2PHSS
Monogram 30" Built-In Double Oven ZET2PHSS
WALL INSTALLATION
23 1/2" (59.7)
min cutout depth
51 13/16"
(131.6)
cutout location
12"
(30.5)
Recommended
from floor
A
C
STANDARD
INSTALLATION
INSTALLATION OVER WARMING DRAWER
24 7/8" (63.2)
min cutout depth
top
cleat
side
cleat
D
FLUSH INSET
INSTALLATION
bottom
cleat
C
53 7/16"
(135.7)
TOP VIEW
1 3/8"
(3.5)
30 1/4" (76.8) flush inset width
with
15/16"
(2.4)
Side cleats
3/8" (1.0) Bottom cleat
(Extends full depth of cabinet)
FLUSH INSET INSTALLATION
2 1/2"
Side cleats
depth
1/4" (0.6) reveals
13/16"
B
(2.1)
Top cleat
3 1/4"
(8.3)
29 3/4" (75.6)
cutout width
30 1/4" (76.8)
(6.4)
ELEC.
9 1/2"
(24.1)
E
FRONT VIEW
Allow 1/4" (0.64) clearances
from side edges of oven door.
NOTES
A
Based on a user
height of 5' 6"
to 5' 10"
B
Junction box location
(May also be located
in adjacent cabinet.)
C
Platform must be
able to support 375 lbs
(169 kg)
D
Cabinet surface must
be an appearance
finished surface for
flush installation.
E
Cleats may be visible
and should be finished
to match cabinetry.
F
Dimension per
Warming Drawer
requirement.
F
9 1/4"
(23.5)
1"
(2.5) min
2"
(5.1) min
STANDARD INSTALLATION
SIDE VIEW
For more details, refer to the installation instructions
for this product on Monogram.com. Dimensions in
parentheses are in centimeters unless otherwise noted.
Product Specification Revised 7/15
Monogram 30" Built-In Double Oven ZET2PHSS
FEATURES AND BENEFITS
True European Convection with Direct Air –
Channels heated air from the top of the oven and
circulates it around food on all sides for perfectly
uniform baking and roasting
10.0 Cu. Ft. Oven Capacity (5.0 each oven) –
Accommodates even the largest meals
Ten-Pass Bake Element – Covers more surface area
for more even baking results
All-Glass Interior Door Panel – Offers a visually
striking look that's easy to clean
Theatre-Style LED Oven Lighting – Located on both
sides of the oven to enhance visibility and provide a
clear view of food, regardless of rack position
Stainless steel back-lit digital control knobs – Rotate
with smooth precision. An indicator light in each knob
makes it easy to view and select
heat settings
Notification Lighting – Allows you to check cooking
status with a quick glance
Self-Cleaning, Full-Extension Oven Racks (each
oven) – Glide in and out smoothly on stainless steel
ball bearings, and are designed to be left in the oven
during the self-clean cycle
Self-Clean with Steam Clean Option – Gives you
flexible options for thorough oven cleaning
Ten-Pass, Dual Broil Element – Evenly browns
dishes of all types and sizes
WiFi Connect – Allows you to control oven functions
from anywhere inside or even outside your home,
using your smartphone or other web-enabled
mobile device
R
Black Interior – Offers a stylish complement to the
sophisticated exterior design
Product Specification Revised 7/15
