MONOGRAM 18" DISHWASHER ZBD1870NSS
ZBD1870NSS
OVERALL DIMENSIONS
2.1" (5.3)17 1/2" (44.5)
26 13/16"
(68.0)
32 1/2" min
35" max
(82.55 - 88.9)
FRONT VIEW
5 11/16" min
8 3/16" max
(14.5 - 20.9)
Toe kick
height
SPECIFICATIONS
Overall Width 17 1/2" (44.5 cm)
Overall Height
Overall Depth 22 1/2" (57.2 cm)
Door Clearance 25 5/8" (14.3 cm)
Overall Dishwasher
Capacity
Minimum Cabinet
Width
Minimum Cabinet
Depth
Cutout Width
Cutout Height
Electrical
Requirements
Hose Length
Voltz/Hertz/Amps
Shipping Weight 83 lb (38 kg)
32 1/2" (82.6 cm) Min
35" (88.9 cm) Max
8 Place Settings
17 5/8" (44.8 cm)
22" (55.9 cm)
17 5/8" (44.8 cm) Min
18" (45.7 cm) Max
32 1/2" (82.6 cm) Min
35" (88.9 cm) Max
9.0 A
No more than
10' (3 m)
115 V, 60 Hz,
15 or 20 amp circuit
2"
(5.1)
3"
(7.6)
2" (5.1)
22 1/2" (57.2)
SIDE VIEW
17 1/2" (44.5)
TOP VIEW
OPEN DISHWASHER
DOOR SHOWING
DOOR CLEARANCE
32 1/2" min
35" max
(82.6 - 88.9)
Height at rear
25 5/8"
(65.1)
Dimensions in parentheses are in
centimeters unless otherwise noted.
2" (5.1)
min
clearance
to wall
2" (5.1)
min
clearance
to wall
Product Specification Revised 1/18
ZBD1870NSSMONOGRAM 18" DISHWASHER
ZBD1870NSS
INSTALLATION
32 1/2"
(82.55) min
underside of
counter to floor
Can be adjusted
up to 35" (88.9)
FLUSH CUTOUT INSTALLATION
22" (55.88)
min cutout depth
6"
(15.24)
4"(10.2)
C
ELECTRIC/
WATER
NOTES
A
The dishwasher drain
hose must be no
more than 10 feet
in length for proper
drainage.
B
A reduced-height
installation (32-1/2"
min.) beneath a 34"
countertop can be
accomplished by
screwing in the rear
legs flush with the
bottom support,
removing the front
leveling legs and
adding shims to level.
C
Water and electrical
must be routed
through the back
wall shown in shaded
area.
D
To prevent siphoning,
an air gap or high
drain loop must be
used.
17 5/8" (44.8) Min
cutout width
18" (45.7) Max
cutout width
5"
(12.7)
5"
(12.7)
C
6" (15.2) 4" (10.2)
INSTALLATION CUTOUT FRONT VIEW
ELECTRIC/
WATER
Product Specification Revised 1/18
