owners manual
Silver
1
Silver
2
Silver
6
Silver
8
Silver
10
centre
series
monitoraudio.com 1
Contents
Contents 1
Introduction 2
Silver 1 3
Silver 2 3
Silver 6 3
Silver 8 3
Silver 10 3
Silver Centre 3
Silver FX 3
Setting Up 4
AV Positioning 4
Optimum AV Speaker Positioning 4
Silver FX Switch Configuration 5
2 Channel Positioning 7
Setting up the Silver FX 7
Fixing the Silver FX to a wall 8
Plinth Fixing 8
Grilles 8
Spiked Foot 9
For Carpeted Floors 9
For Wooden/ Hard Floors 9
Connecting Speaker Cables 10
Bare Wire Connection 10
Single Wire 10
Banana Plugs 10
Bi-Wire/ Bi-Amp 10
Port bungs 11
Running In 11
Specifications 12
ENGLISH
Introduction
With the extraordinary success of RX as its blueprint, the latest Silver Series advances the art of
mid-market speaker development with new models and technologies. Features introduced by
the prestigious Platinum and Gold series speakers have been refined, and recent innovations in
driver engineering incorporated across an extended new Silver series. While the Silver 1, 2, 6,
centre and FX retain the form factor of their predecessors, the Silver 8 becomes a full three way
design, and new to the Silver family, the Silver 10 offers an up-scaled floor-standing format,
featuring twin 8” bass drivers for a deeper more dynamic and consistent response in larger
rooms.
New bass and mid-range drivers
Unlike conventional cones, which incorporate a centre aperture for the voice-coil, the dimpled
RST® (Rigid Surface Technology) C-CAM® cones deployed by the Silver Series take the form
of a continuous uninterrupted radiating dish having inherently greater strength and area. The
voice coil sits beneath and is coupled to a larger motor by an innovative, more efficient drive
assembly.
In addition, the Silver 8 and 10 models feature a newly developed 4” mid-range driver, operating
in its own damped and optimised enclosure to provide accurate mid frequencies. It features
a short voice coil ‘under-hung’ in relation to the magnetic gap to ensure that the coil remains
inside the gap at all times for significantly reduced modulation and extremely low distortion.
New tweeter
Distortion from air compression at the back of a tweeter dome has been eliminated by Silver’s
new 25mm C-CAM tweeter design, which vents into a large rear-loading chamber, producing
much lower resonance and better overall damping. The frequency response from the new
tweeter is more accurate at lower frequencies for a smoother more natural handover with
the mid/bass driver. Meanwhile high frequency extension has been improved and break-up
reduced by improvements in cone geometry and drive mechanism.
Other design features
The new Silver Series retains the single bolt-through driver fixings deployed by RX to reduce
cabinet colouration. Each bolt acts as a rigid brace, but also removes the need for conventional
driver fixings as well, effectively decoupling the driver and front baffle to eliminate a further
source of resonance.
NOTE: Should this bolt become loose over time, or has worked loose during transit,
then please use the supplied hex key to tighten the bolt back up. This only needs to
be a quarter turn on after the strain has been taken by the bolt.
Evolving from Platinum, Monitor Audio’s HiVe port technology is incorporated on all but Centre,
FX and W12 subwoofer models. HiVe uses a straight rifled design to accelerate air flow and
reduce turbulence for clean powerful bass and superior transient response. Polypropylene film
capacitors, air core and laminated steel core inductors have been utilised in the crossovers
to maintain the best possible signal integrity. All models in the new Silver Series offer higher
sensitivity, reduced distortion and higher impedance than their predecessors, ensuring a wider
choice of partnering equipment.
Silver Series2
monitoraudio.com 3
Silver 1
The compact new Silver 1 features a single 6” C-CAM® bass/mid-range driver featuring dimpled
RST cone technology in a classic two-way monitor configuration. High output and dynamic
delivery make the Silver 1 an ideal choice for small to medium rooms in two-channel stereo or
multi-channel cinema systems.
Silver 2
The Silver 2 features a powerful 8” C-CAM, RST bass/mid driver in a compact two-way stand
mount design. Higher overall efficiency and driver size delivers excellent dynamic headroom
with the extended bass normally associated with floor-standing models. Exceptional resolution
combined with high output and remarkable dynamic delivery mean that the Silver 2 is suitable
for medium to large rooms in two-channel stereo or multi-channel cinema systems.
Silver 6
The Silver 6 incorporates a 6” C-CAM, RST bass driver and 6” C-CAM RST bass/mid driver in a
2.5 way system configuration. The drivers are housed in separate acoustic chambers within the
enclosure design to provide differential tuning for higher efficiency and enhanced low frequency
extension. Excellent dynamics combined with a naturally rhythmic sonic character and tight,
controlled bass make the Silver 6 an outstanding communicator of music and film audio.
Silver 8
The Silver 8 has a new three-way design featuring Silver’s 4” C-CAM, RST mid-range driver
flanked by long-throw C-CAM, RST 6” bass drivers. Introduced for Silver, this specialised
configuration is optimised for greater accuracy over a critical frequency band to deliver
superb mid-range focus and precision as well as extended bass. A taller, shallower cabinet
and improved damping allows for greater room position flexibility, while higher sensitivity and
impedance make the Silver 8 easier to drive for room-filling dynamics, even in larger spaces.
Silver 10
Silver 10 is a completely new model introduction, comprising a three-way configuration in a
large floor-standing tower system. For Silver 10 the 4” C-CAM, RST mid-range driver is flanked
by 8” C-CAM, RST long-throw bass drivers. The acoustic design is similar to the Silver 8 but
the enhanced driver size means that the 10 is equipped to energise the largest of rooms with
naturally explicit wideband audio from music and film sources.
Silver Centre
The compact Silver Centre features twin 6” C-CAM, RST bass/mid-range drivers in a familiar
Mid - Tweeter - Mid array. The Silver Centre has been tuned to match the tonal character of its
Silver range mates for a seamless front sound stage in multi-channel applications.
Silver FX
The discreetly profiled angled baffle design of the new Silver FX surround speaker incorporates a
single front-mounted 6” C-CAM, RST bass/mid driver and twin side-mounted C-CAM tweeters.
It can be flush-mounted on side or rear walls and its dispersion characteristics changed at the
flick of a switch for di-pole or bi-pole operation.
ENGLISH
Setting Up
AV Positioning
The illustrations on the following pages show optimal positioning and some suggested room
layouts for AV applications. For advice on configuring a 2 channel system, refer to page 7.
The front, and in some cases rear, floor standing and stand mount speakers should be
positioned approx 6 - 9 feet apart (1.8m - 2.5m) and start with them about 10 inches
(25cm) from the wall.
If, when playing music, the sound is too bass heavy or there is bass boom from the room,
then move them slightly further away from the rear/ side walls. If this is not possible, then
try the supplied port bungs (not included in the Silver FX or Centre). Refer to Page 11.
The Centre should be positioned so that it is pointing at you in your viewing position, and
at approximate ear height. If it is below or above ear height, use some rubber feet (small
feet supplied) to angle it slightly.
The FX’s should be positioned in accordance with the below illustrations and approx 2
feet (60cm) above ear height when in your listening position. Refer to page 7 for further
information.
Optimum AV Speaker Positioning
22°
0°
30°
90°
110°
135°
150°
Centre
Left
Right
Surround
Right
Surround
Left
Rear
Surround Left
Rear
Surround Right
Silver Series4
Di-Pole
Bi-Pole
LEFT
Di-Pole
Bi-Pole
RIGHT
Di-Pole
Bi-Pole
LEFT
Di-Pole
Bi-Pole
RIGHT
monitoraudio.com 5
Silver FX Switch Configuration
ENGLISH
Di-Pole
Bi-Pole
RIGHT
Di-Pole
Bi-Pole
LEFT
Di-Pole
Bi-Pole
RIGHT
Di-Pole
Bi-Pole
RIGHT
Di-Pole
Bi-Pole
LEFT
Di-Pole
Bi-Pole
LEFT
Silver Series6
2 Channel Positioning
For use in a 2 channel system, the listening position and the loudspeakers should
form an equilateral triangle. The speakers should be positioned approximately 6 - 10
feet (1.8 - 3m) apart. They ideally need to be between 8 - 18 inches (20 - 45cm) away
from the rear and 3 feet (1m) from the side walls.
Experimentation is strongly advised when initially setting up your speakers, as
environments and personal preference differ with each installation. If there is not
enough bass, for example, then try moving your speakers closer to a wall. The
opposite, if there is too much bass. Also see the information on page 11 referring to
Port Bungs. If you are losing stereo imaging, try ‘toeing’ them in slightly. The sound
should appear to originate from the centre point between the speakers, not the actual
speakers themselves.
Setting up the Silver FX
NOTE: When using 2 pairs of Silver FX’s in a 7.1 system, you need to use the
Right speaker for the rear surround left and the Left speaker for the rear surround
right. This is because of the tweeter phasing.
The Silver FX’s are paired, but specifically, right hand and left hand units. Of which
both can be configured to bi-pole (normal operation) or di-pole modes. The factory
setting is bi-pole.
In bi-pole mode, all speaker units (mid/bass unit and tweeters) are in phase. This
feature is designed for when the FX is set up as a rear/surround speaker in a typical
5.1 channel system, or alternatively in a 7.1 channel system without a second pair of
FX’s for rear/ surround duties.
In di-pole mode, the rear firing tweeters are out of phase with the other tweeter and
mid/bass unit. It is best to implement this configuration when using the two pairs FX’s
as part of a 7.1 channel system, with the FX’s taking up positions on the side and rear
walls. Please note that the FX’s are left and right handed. This is not an issue when
used in bi-pole mode. It is essential that they are positioned correctly if used in a 7.1
channel system. Please refer to the positioning section on page 4.
NOTE: Before changing your FX’s from bi-pole mode to di-pole mode,
please ensure that the speaker wires are disconnected from your
loudspeakers. This helps to protect your amplifier.
monitoraudio.com 7
ENGLISH
Fixing the Silver FX to a wall
CAUTION: You will need to determine where the Silver FX’s will be fixed and
the structure of the wall. For safety reasons, if you are unsure of your ability to
provide a secure and safe fixing, do not attempt to fix these speakers to your
wall, please obtain the services of a competent and qualified trades person.
CAUTION: Ensure that there are no water pipes or electricity cables running
behind where the wall brackets are going to be secured. Work from secure
steps and avoid trailing wires.
We do not supply wall fixing screws and plugs with the FX’s. Please use suitable
fixings for the type of wall construction the FX’s will be fixed to.
To fix your FX’s to the wall, we would recommend using the wall fixing template
enclosed within the packaging carton
Plinth Fixing
Floor standing models only
The Silver 6, 8 & 10’s are supplied with plinths to improve stability and acoustic
response. The plinths are secured in place by using the supplied M10 bolts. They
are not essential should space be at a premium. If you choose not to use the plinths,
fit the spiked feet direct to the cabinet.
Before you fit the plinth ensure the floor area is clear of any hard/sharp objects. To
fit the plinth turn the cabinet over so that the bottom is facing upwards. Place the
plinth onto the cabinet ensuring it is orientated correctly, lining up the bolt holes in
the plinth with the inserts in the cabinet. Using the bolts, secure the plinth to the
cabinet. Tighten them up gradually at first and ensure the plinth is fitted securely
to the cabinet. Fit the feet to the plinth before turning the loudspeaker back over.
(Please read the instructions opposite). The spikes are used to improve sound quality
and bass performance
Grilles
All of the Silver Series speakers come with grilles covered in acoustically transparent cloth. The
grilles are held invisibly in place by magnets in both the grille and the cabinet (except the FX).
To fit them, firstly ensure they are the correct way up (badge at the bottom) and offer
them up to the cabinet. The magnets should then pull it into position.
The FX comes with the grilles factory fitted. If you wish to remove them, carefully prize
them away from the cabinet with the tips of your fingers. There are three separate
grilles fitted to each cabinet.
CAUTION: Always remove grilles before lifting or moving the speakers.
Silver Series8
Spiked Foot
For Carpeted Floors
Floor standing models only
The Silver Series spiked foot incorporates a spike for use on carpeted floors and also,
a soft polymer pad for use on wooden or tiled floors.
Please ensure there are no hidden wires under the
carpet that could be damaged by the spikes.
The foot comes fully assembled for use on carpeted
floors. All that is required is fixing into the plinth
(or cabinet if you chose not to use the plinth).
This is achieved by screwing the feet fully into the
4-threaded inserts in the underside of the plinth/
cabinet. If your carpet has a very thick pile, remove
the soft polymer pad from the foot to ensure the
spike goes right through the carpet into the floor.
With great care turn your cabinet the right way
up. Place the cabinet in your desired location, and
check that it is level on all sides. If it is slightly off level, unscrew the spike at the lowest
point and check again. Continue this process until the cabinet is fully level. Use the
locking nut on the foot to fix it in place and to stop any unwanted vibrations.
For Wooden/ Hard Floors
Floor standing models only
For use on solid floors or where spikes are inappropriate, it is
possible to use the foot without the spike. To use the foot in this
manner carefully grip the knurled portion of the spike and rotate
anti clockwise and unscrew the spike fully.
You may find it easier to first remove the polymer pad so as to
gain more purchase on the spike. The pad should be replaced
before carrying out the levelling operation described above.
Locking
Nut
Main
Threaded
Assembly
Spike
Polymer
Pad
monitoraudio.com 9
ENGLISH
Silver Series10
Connecting Speaker Cables
Bare Wire Connection
Unscrew the binding posts and pass
the bare wire through the through-hole
and tighten the binding post to clamp
the wire in place.
Banana Plugs
Remove the red and black plastic plugs
from the terminals and insert the banana
plugs into the holes that are revealed.
A knife blade of flat blade screwdriver
may be required to gain purchase on
the plugs.
Single Wire
Connect the banana plugs/ bare wire to
the terminals. Connect to either the top,
bottom or diagonally (experimentation
is advisable to achieve the preferred
results).
Leave the terminal links in
place.
Bi-Wire/ Bi-Amp
Connect the banana plugs/ bare wire to
the top and bottom terminals (positive
to positive and negative to negative).
The terminal links MUST be
removed.
monitoraudio.com 11
Port bungs
WARNING: Care must be taken not to insert the port bungs too far into the
port, as this may result in the foam bung being lost inside the cabinet.
If the loudspeaker is to be installed in a small room, typically 9 sqM ( 80 sqFT), or
a room known to reproduce accentuated bass response, it may be desirable to
fit port bungs. However, experimentation is recommended with positioning of the
loudspeaker in the room prior to fitting. To optimise a loudspeakers performance,
ensure it is not positioned too close to a wall or near the corners of a room (refer to
the suggestions on pages 4 and 7).
If room aesthetics or layout predetermine speaker positioning, or experiencing the
presence of accentuated bass, please move on and read point 1 for the Silver 1 and
2 and point 2 for the Silver 6, 8 and 10.
1. Where bookshelf/ stand-mount speakers (Silver 1 & 2) are to be sited in close
proximity of less than 8 inches/ 20cm to a rear wall (such as on a bookshelf,
positioned in a cabinet or on a stand close to a wall), we recommend fitting port
bungs to the ports. This will reduce the bass ‘boom’ and assist the loudspeakers
to reproduce their best performance under these environmental conditions.
2. Where floor-standing loudspeakers (Silver 6, 8 & 10) are to be sited in close
proximity of less than 18 inches/ 45cm to a rear wall, we recommend fitting the
port bungs. This will reduce the bass ‘boom’ and assist the loudspeakers to
reproduce their best performance under these environmental conditions.
What is Bass Boom?
Bass ‘Boom’ (sometimes termed as overhang) is generally caused when bass energy
from the loudspeaker ‘excites’ room modes and causes an accentuation at a particular
frequency, or number of frequencies
When fitting port bungs the overall bass extension will not be reduced, however bass
energy/ output around the port tuning frequency will be reduced. This has the effect
of reducing bass ‘boom’ while increasing bass clarity and apparent agility.
Experimentation is highly recommended.
Running In
The speakers will require a level of “running in” before they have reached the
optimum. The running in process for the Silver Series will be approximately 60 - 70
hours of playback. During the running in process, it is recommended not to push the
loudspeakers to high levels as this can cause damage to them. During this time, you
will notice the sound open up and become clearer, tighter and a lot more controlled.
ENGLISH
Silver Series12
Specifications
MODEL Silver 1 Silver 2 Silver 6 Silver 8 Silver 10 Silver Centre Silver FX
System Format
2 - way 2 - way 2 ½ way 3 - way 3 - way 2 way (M - T - M) 2 - way
Frequency Response
45Hz - 35KHz 40Hz - 35KHz 35Hz - 35KHz 32Hz - 35KHz 30Hz - 35KHz 45Hz – 35KHz 60Hz – 35KHz
Sensitivity (1W@1M)
87dB 88dB 90dB 90dB 90dB 90dB 87dB
Nominal Impedance
8Ohms 8Ohms 8Ohms 4Ohms 4Ohms 8Ohms 8Ohms
Maximum S.P.L
110.8dBA (pair) 112.6dBA (pair) 115.5dBA (pair) 116.8dBA (Pair) 117.8dBA (Pair) 112.5dBA 110.1dBA (pair)
Power Handling (RMS)
Watts
100W 120W 150W 200W 250W 150W 85W
Recommended amplifier
requirements (RMS)
40 – 100W 40 – 120W 60 – 150W 80 – 200W 80 – 200W 60-150W 40-85W
Bass Alignment
Bass Reflex.
HiVe® port system
Bass Reflex.
HiVe port system
Dual Chamber Bass Reflex
with Differential Tuning.
Twin HiVe port system
Bass Reflex.
Twin HiVe port system
Bass Reflex.
Twin HiVe port system
Sealed Cabinet Sealed cabinet
Crossover Frequency
3.0 KHz 2.0KHz
L.F: 700Hz
M.F/ H.F: 2.7KHz
L.F/ M.F: 500Hz
M.F/ H.F: 2.7KHz
L.F/ M.F: 550Hz
M.F/ H.F: 2.7KHz
2.6KHz 2.2KHz
Drive unit Complement
1 x 6” RST®
bass/mid driver
1 x 1” (25 mm) gold
dome C-CAM® tweeter
1 x 8” RST
bass/mid driver
1 x 1” (25 mm) gold
dome C-CAM tweeter
1 x 6” RST bass driver
1 x 6” RST
bass/mid driver
1 x 1” (25 mm) gold
dome C-CAM tweeter
2 x 6” RST bass driver
1 x 4” RST
mid-range driver
1 x 1” (25 mm) gold
dome C-CAM tweeter
2 x 8” RST bass driver
1 x 4” RST
mid-range driver
1 x 1” (25 mm) gold
dome C-CAM tweeter
2 x 6” RST
bass/mid driver
1 x 1” (25 mm)
gold dome
C-CAM tweeter
1 x 6” RST
bass/mid driver
1 x 1” (25 mm) gold
dome C-CAM tweeter
Cabinet dimensions
(Excluding grille,
terminals & plinth)
(H x W x D)
312 x 185 x 240mm
12
5/16
x 7
5/16
x 9
7/16
Inch
375 x 230 x 300mm
14
3/4
x 9
1/16
x 11
13/16
Inch
885 x 185 x 240mm
34
13/16
x 7
5/16
x 9
7/16
Inch
1000 x 185 x 300mm
39
3/8
x 7
5/16
x 11
13/16
Inch
1050 x 230 x 300mm
41
5/16
x 9
1/16
x 11
13/16
Inch
185 x 500 x 200mm
7
5/16
x 19
11/16
x 7
7/8
Inch
250 x 311 x 130mm
9
13/16
x 12
1/4
x 5
1/8
Inch
External dimensions
(Including terminals)
(H x W x D)
312 x 185 x 263mm
12
5/16
x 7
5/16
x 10
3/8
Inch
375 x 230 x 323mm
14
3/4
x 9
1/16
x 12
11/16
Inch
885 x 185 x 263mm
34
13/16
x 7
5/16
x 10
3/8
Inch
1000 x 185 x 323mm
39
3/8
x 7
5/16
x 12
11/16
Inch
1050 x 230 x 323mm
41
5/16
x 9
1/16
x 12
11/16
Inch
185 x 500 x 223mm
7
5/16
x 19
11/16
x 8
3/4
Inch
250 x 311 x 130mm
9
13/16
x 12
1/4
x 5
1/8
Inch
External dimensions
(Including grille &
terminals) (H x W x D)
312 x 185 x 275mm
12
5/16
x 7
5/16
x 10
13/16
Inch
375 x 230 x 335mm
14
3/4
x 9
1/16
x 13
3/16
Inch
885 x 185 x 275mm
34
13/16
x 7
5/16
x 10
13/16
Inch
1000 x 185 x 335mm
39
3/8
x 7
3/16
x 13
3/16
Inch
1050 x 230 x 335mm
41
5/16
x 9
1/16
x 13
3/16
Inch
185 x 500 x 235mm
7
5/16
x 19
11/16
x 9
1/4
Inch
250 x 311 x 143mm
9
13/16
x 12
1/4
x 5
5/8
Inch
External dimensions
(Including plinth & feet)
(H x W x D)
N/A N/A
936 x 245 x 300mm
36
7/8
x 9
5/8
x 11
13/16
Inch
1021 x 245 x 360mm
40
3/16
x 9
5/8
x 14
3/16
Inch
1071 x 290 x 360mm
42
3/16
x 11
7/16
x 14
3/16
Inch
N/A N/A
Weight (each)
6.95kg (15lb 4oz) 9.7kg (21lb 6oz) 16.5kg (40lb 8oz) 23.33kg (51lb 6oz) 26.03kg (57lb 4oz) 9.6kg (21lb 2oz) 5.1kg (11lb 4oz)
Monitor Audio Ltd.
24 Brook Road
Rayleigh, Essex
SS6 7XJ
England
Tel: +44 (0)1268 740580
Fax: +44 (0)1268 740589
Email: info@monitoraudio.co.uk
monitoraudio.com
Designed and Engineered in the
United Kingdom, made in China
© 2013. Version 1
monitoraudio.co.uk
m
MONITOR
AUDIO®
design
for
sound
IMPORTANT SAFETY INSTRUCTIONS
GB-
SAFETY
INSTRUCTIONS
FR -
CONSIGNES
DE
SECURITE
IT-
ISTRUZIONI
PER
LA
SICUREZZA
DE -
SICHERHEITSANWEISUNGEN
ES-
INSTRUCCIONES DE
SEGURIDAD
PT-
INSTRU<;OES
DE SEGURAN<;A
NL-
VEILIGHEIDSINSTRUCTIES
CH-
~:i:~B~
RU -
111HCTPYKW111111
no
TEXHII1KE 6E30nACHOCTII1
RU -
YCnOBII1fl
rAPAHTI/1111
SPEAKERS
IMPORTANT
SAFETY
INSTRUCTIONS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Please read these instructions.
Please
keep these instructions.
Heed
all warnings.
Follow all instructions.
Do
not use this apparatus with water.
Clean only
with a dry
cloth.
Great care and attention has gone into the
materials chosen
to
produce your Monitor Audio loudspeakers. A gentle
wipe with a
drY,
clean cloth
is
all
that
is
required
to
remove any dust. Treat
them as you would a fine piece
of
furniture because that
is
how
they have
been designed.
To
clean the high gloss finishes use our
"Lacquer Polish"
that has been developed alongside Auto Glym.
It
can only be purchased
from the online shop at www.monitoraudio.com (UK customers only).
Do not
install
near
any
heat
source, such as radiators, heat registers,
stoves, or other.apparatus
(including
amplifiers) that produce heat.
Only
use
attachments/
accessories specified by Monitor Audio.
Use
only
with
the
cart, stand, tripod, bracket, or table
<I
specified by monitor Audio or sold with the apparatus. When
a cart
is
used, use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
Refer .
all
servicing
to
qualified
service
personnel.
Servicing is
required when the apparatus has been damaged
in
any
way,
such as
power supply cord or plug
is
damaged, liquid has been
spilled
or
objects
have
fallen
onto the apparatus, the apparatus has been exposed
to
rain
or moisture, does not operate normally
or
has been dropped.
This apparatus
shall
not
be
exposed
to
dripping
or
splashing
water
and that no object
filled
with liquids such as vases
shall
be placed
on the apparatus.
12. This
exclamation
point within an
equilateral triangle
&
is
intended to alert the user
to
the presence
of
important
f
maintenance (servicing) instructions
in
the literature
•
accompanying the appliance.
13.
No
naked
flame
sources, such as lighted candles, should·
be placed
on the apparatus.
RE-CYCLING
Correct Disposal of Waste Electrical and Electronic Equipment
(WEE
E)
by User
·
in
Private Households
in
the
EU.
This symbol on the product
or
accessories indicates
that they must not be disposed
of
with your household
wastes throughout the
EU.
To
prevent possible harm to
the environment or human health from uncontrolled
waste
disposal, recycle
it
responsibly
to
promote the sustainable
reuse
of
material resources.
Instead it
is
your responsibility
to
dispose of your waste equipment by handing it over
to a designated WEEE
collection
point for recycling. The
separate
collection
and recycling
of
your waste equipment
will help conserve natural resources and ensure that it
is
recycled
in
a manner that protects human health
and the environment.
For more specific information about where you can take your equipment for
recycling please contact your
local
city/council office, your
local
waste disposal
service or the
outlet where you purchased your Monitor Audio product.
ROHS
DECLARATION
OF
CONFORMITY
Directive
2011/65/EU
of the European Parliament and of
the Council on the reduction of the use
of
certain hazardous
substances
in
electrical
and electronic equipment, June
2011.
Background
RoHS2
COMPLIANT
2011/65/EU
The RoHS
directive restricts the use
of
Lead
(Pb),
Cadmium
{Cd),
Mercury
(Hg),
hexavalent Chromium
(CrVI),
polybrominated biphenyl (PBB) compounds, and
polybrominated diphenyl ether (PBDE) compounds
in
electrical and electronic
equipment sold
in
the European Union.
monitoraudio.com
1
GUARANTEE
AND
SERVICE
To
validate your warranty please visit www.monitoraudio.com within
30
days
of
purchase.
When you register online you'll gain free entry to our monthly prize draw!
What's more you'
II
be the first
to
hear about the great things happening at
Monitor Audio, including new products and events!
This equipment has been fully tested prior to dispatch from the factory.
Both the craftsmanship and the performance of this product
is
guaranteed
against manufacturing defects for the period
of
five years from the date
of
purchase
(see
conditions below), provided that the product was supplied by
an authorised Monitor Audio retailer under the consumer sale agreement. (The
words 'consumer sale' shall be construed
in
accordance with section 15
of
the supply of goods act 1973). Monitor Audio accepts no responsibility for
defects arising from accident, misuse, abuse, wear and
tear,
modification or
operation outside of that specified within this instruction manual. Neither will
responsibility be accepted for damage or loss occurring during transit
to
o~
from the parties claiming under this guarantee.
This guarantee covers both labour and parts. The liability
of
Monitor Audio
is
limited to the cost of repair or replacement of the defective parts (at
the discretion
of
Monitor Audio) and under no circumstances extends
to
consequential losses or damage.
CLAIMS
UNDER
THIS
GUARANTEE
The equipment should be returned
in
its original packaging
to
the original
supplier where possible, or
to
any other authorised Monitor Audio dealer.
If
it
is
not possible to return the equipment by hand, then it should be sent
carriage prepaid via a reputable carrier. If the original packing
is
not available
replacement packaging can be purchased from Monitor Audio.
If you have any difficulties complying with these requirements please contact
us at the following address:
Customer Service
Monitor Audio Ltd.
24 Brook Road
Rayleigh
Essex, SS6 7XJ
England
Tel:
+44 (0)1268 740580
Fax:
+44
(0)
1268 7 40589
Internet: www.monitoraudio.com
Email: info@monitoraudio.co.uk
This guarantee does not affect the statutory rights
of
the consumer under UK
law.
DATA
PROTECTION
We at Monitor Audio are committed to respecting the wishes and privacy
of
our
customers. Any information you provide will be held
in
the strictest confidence
and only used within the Monitor Audio organisation for the provision of
services such as warranty claims or spare parts.
We may wish
to
contact you
in
the future to ensure you are happy with the
products and standards
of
service we provide and to keep you up-to-date with
the latest products and promotions we have to offer.
Should you wish not
to
be contacted by us either by post, e-mail or phone,
please tick the box on the warranty form on the web site. Alternatively you can
request not
to
be contacted
in
future by writing
to
Customer Service, at the
address above.
2
Important Safety Instructions
EC
Declaration
of
Conformity
We,
Monitor Audio Ltd.
24
Brook Road
Rayleigh
Essex
SS6
7XJ
England
12
Declare
in
own responsibility, that the Monitor Audio products
described
in
this manual
is
in
compliance
with Technical Standards/
Council Directives:
(LVD)
2006/95/EC
Low
Voltage
Directive
EN60065: 2002+A 1 :
2006
Safety requirements for mains operated
electronic and related apparatus for household and similar use.
(EMC) 89/336/EEC Electro
Magnetic Compatibility
EN55013:
08.90+A12:08.94+A13:12.96
Limits and methods of
measurement of radio disturbance characteristics of broadcast
receivers and associated equipment.
EN55020:
12.94+A
11
:12.96
Electro magnetic immunity of
broadcast receivers and associated equipment.
EN61000-3-2:
04.95+A1:1998+A2:1998
Electro magnetic
compatibility
(EMC)-
Part
3:
Limits-
Section
2:
Limits for harmonic
current emissions (equipment input current up to and including 16
Ampere per phase).
EN6100-3-3:
01.95
Electro magnetic
compatibility
(EMC)-
Part
3:
Limits - Section
3:
Limits of voltage fluctuations and flicker
in
lowvoltage supply systems for equipment with rated current up and
including 16 Ampere per phase.
Signed
by:
Name:
D.S. Hartley
Position:
Technical Director
Company:
Monitor Audio Ltd
monitoraudio.com
3
Monitor Audio Ltd.
24 Brook Road
Rayleigh, Essex
886
7XJ
England
Tel:
+44 (0)1268 740580
Fax:
+44 (0)1268 740589
Email: info@monitoraudio.co.uk
Web: www.monitoraudio.com
Designed
in
the United Kingdom
© 2012. Version 3
Loading...
