INSTALLATION INSTRUCTIONS
Installation Instructions
1. If using the pre-construction bracket, place this into position now prior to plaster-boarding. The plasterer can then x the plasterboard around
the pre-construction bracket.
400mm
2. If not using the pre-construction bracket and the plaster is all ready up, the location of the studs needs to be accurately determined. Draw
around template ensuring the speaker is between the centres of the 400mm studs.
400mm
3. Cut around the marked line.
4.
Test t the speaker ensuring it ts neatly in the cut out and that the screw holes line up with the studs.
Do not try to remove the printed membrane o the front of the speaker.
5. Check the depth of the speaker is correct. The front white membrane of the speaker should be ush with the plasterboard. If using 12mm
plasterboard, there should need to be any additional work to carry out but checking is advisory.
If it is lower than the plasterboard, use the supplied card shims to space it o of the studs.
If it is proud of the plasterboard then some material will need to be taken o the studs to ensure it is ush.
6. Once you are happy with the t, wire up the speaker and test that it works.
More bass can be achieved by removing the rear plastic square panel just below the terminal panel.
Note: The sound heard outside of the wall and without plaster is not a true representation of the nal sound you will get.
50 100 150 200 250 Hz
7. Once you are happy with your installation and sound choice, screw the speaker in place
8.
C
L
400mm (16”)
5
4
5
4
5
3mm
50 100 150 200 250 Hz
Apply webbed tape over the screws so that it bridges the gap between
the speaker membrane and the plasterboard. The card shims can be
used here as well if you wish to reduce the void between the outer
edge of the frame and the membrane - plasterboard level.
9. Plaster the speaker into the wall with no more than 3mm of plaster.
C
L
400mm (16”)
5
4
5
4
5
3mm
50 100 150 200 250 Hz
3mm
