Introduction

CWT speakers have been developed to provide synergy with Monitor Audio’s other custom ﬁt and home speakers. We apply our innovative design skills and experience in making high-end hi-ﬁ and home theatre speakers to the custom ﬁt environment providing un-rivalled performance and reliability.

The new CWT series offer versatile installation options for both in-ceiling and in-wall applications. This high performance range of loudspeakers has been created to provide ﬂexible installation in stealthy ‘trim-less’ round or square grilles styles. Featuring proven technologies and unique design features. CWT models combine high efﬁciency and wide frequency range to facilitate ﬂexible system design across a wide range of demanding residential and commercial installations. The CWT 140, 160 & 180 bass drivers feature MMP® II cone technology coupled with Monitor Audio’s trade mark C-CAM® gold dome tweeter. High frequency performance has been enhanced further by recent improvements to our C-CAM tweeter, taking the frequency band way past the limits of human hearing. The pivoting tweeter can be directed towards the listening space to provide ideal imaging and reduce un-wanted reﬂections when installed close to corners or wall boundaries. Simple crossover design implemented using high grade audiophile components to preserve the signal and provide a smooth yet detailed character.

All models have been designed to be less than 100mm (4”) deep, which means both round and square grille styles can ﬁt into a standard stud wall, or where mounting depth is restricted. By integrating the bass driver basket and frame, our engineers have managed to reduce the overall size by around 25% compared to its counterparts, whilst maintaining the same driver size and performance. Grilles are held in place magnetically by high power Neodymium magnets which provide simple installation and servicing. Since the sub structure for the units are identical, it’s possible to change the grille styles from round to square (or viceversa), should you so desire by simply removing the magnetic grille and replacing with a new one.

Features Overview

• Three driver sizes - 4”, 6” and 8”

• Round or Square grille options to suite wall or ceiling installations

• All models less than 100mm (4”) deep to ensure ﬁtting in restricted spaces are assured

• Tri-Grip - All models feature the unique Tri-Grip ﬁxing design. This 3 –position ‘dog’ style ﬁxing provides greater contact

• MMP

• C-CAM gold dome tweeter with pivoting of up to 15 degrees in all directions.

• Trim-less frame and low proﬁle grille for installations where discreet aesthetic appearance is critical.

• All grilles are held in place with ultra-powerful Neodymium magnets for easy installation and servicing.

• Paint-able grille to allow perfect integration into the décor. An additional scrim material is provided to facilitate trouble free

• All models use ﬁre retardant materials speciﬁed to U.L V0 rating.

• All models are splash and humidity proof for installation in shower room or pool areas.

• All models feature dust protection covers that are designed to prevent the ingress of loose building materials or dust into

• Dedicated pre-construction (rough-in kits) brackets (CB4, CB5 & CB6)

• Alignment marks to ensure the products are in correct alignment with each other.

surface area than other types of ﬁxings whilst saving important installer ﬁtting time. The Tri-Grip dog ﬁxings are made from a tough re-enforced polymer providing a secure ﬁxing without the risk over-tightening

II cone technology

painting process.

the driver and crossover network

I n s t a l l a t i o n G u i d e

Monitor Audio Ltd.

Unit 2, 24 Brook Road

Rayleigh, Essex

SS6 7XJ

England

Tel: +44 (0)1268 740580

Fax: +44 (0)1268 740589

Email: info@monitoraudio.co.uk

monitoraudio.com

Designed in the United Kingdom

cu t o u t t e m pl a te

How to use this template:

1) Remove the Protective backing from the “low tack”

adhesive tape on rear of this template.

2) Align centre lines.

3) The outside profile is an accurate indication of the speaker box hole required.

4) Draw around the profile, remove template and cut hole.

5) The template can be repositioned a number of times if required.

Diameter: 170mm (6 11/16”)

Optimum Speaker Positioning Painting Grilles

Left Right

Centre

0°

22°

30°

Connect speaker cables Guide speaker into cut out

The grilles can be painted. It is recommended that a spray paint is used. If this is not possible, use a paint brush in a dabbing/ stippling technique rather than a conventional stroke. Also, do not over load the brush with paint, the grille holes will get clogged up.

Prior to painting, remove the inner scrim from the grille. A spare is supplied to replace this when the paint is dry.

Speciﬁcations

Model CWT 140 (R & S) CWT 160 (R & S) CWT180 (R & S)

Frequency Response 75Hz - 30kHz 60Hz - 30kHz 48Hz - 30kHz

90°

Impedance (Nominal) 6 Ohms 6 Ohms 6 Ohms

Sensitivity (1W @ 1m) 85dB 88dB 90dB

Surround

Left

110°

Surround

Right

Maximum SPL (Single unit in free space)

Power Handling (RMS) 50W 70W 120W

Recommended Amp Requirements 10 - 50W 15 - 70W 30 - 120W

Rear

Surround Left

Fitting the CWT Series Speakers.

150°

135°

Rear

Surround Right

Drive Unit Complement 1 x 4” MMP

Acoustic Conﬁguration 2 Way 2 Way 2 Way

Overall Size Round: 180.2mm (7

The same steps apply for both square and round products and when ﬁxing to a wall or ceiling.

CAUTION: The CWT loudspeakers can only be ﬁxed into plasterboard (dry-lined) or suspended ceilings/ walls upto

3/4

45mm (1

”) thick. For safety reasons, if you are unsure of your ability to provide a secure and safe ﬁxing, do not

attempt to ﬁx these speakers, please obtain the services of a competent and qualiﬁed trades person.

CAUTION: Ensure that there are no water pipes or electricity cables running behind where the hole will be cut and the loudspeaker will be placed. Work from secure steps and avoid trailing wires.

Draw around template and mark centre lines if necessary

Cut around marked line

Tighten 3 Tri-Grip screws

Fit grilles. They are held in place

magnetically and should ‘snap’ into place.

Overall Depth 103.4mm (4

Cut Out Hole Diameter 149mm (5

Mounting Depth 98.6mm (3

Fixing Type 3 Position ‘Tri Grip

Cable Connection Gold plated ‘push’ type

Construction Material Mineral ﬁlled ABS

Weight 1.18Kg (2.6lb) 2.1Kg (4.6lb) 2.72Kg (6lb)

Pre-Construction Bracket CB4 (Pink) CB5 (Blue) CB6 (Purple)

102.8dBA 107.2dBA 110.6dBA

1 x 1” (25mm) Pivoting

II Bass Driver

C-CAM® Gold Dome

Tweeter

Square: 176.7 x 176.7mm

15/16

x 6

”)

1/16

7/8

”) 170mm (6

7/8

”) 99mm (3

ﬁxings

1 x 6” MMP®II Bass Driver

1 x 1” (25mm) Pivoting

C-CAM® Gold Dome

Tweeter

1/8

”)

Round: 204.2mm (8

Square: 199.2 x 199.2mm

13/16

x 7

”) 102.8mm (4

’ dog

3 Position ‘Tri Grip®’ dog

ﬁxings

1/16

”)

13/16

”)

1/16

”) 103.3 (4

11/16

”) 213mm (8

7/8

”) 99.4mm (3

Gold plated ‘push’ type

terminals

Mineral ﬁlled ABS

(UL94-V0 rated, RoHS

complient)

(UL94-V0 rated, RoHS

complient)

1 x 8” MMP®II Bass Driver

1 x 1” (25mm) Pivoting

C-CAM® Gold Dome

Tweeter

x 9

11/16

1/16

3/8

15/16

”)

Round: 251.7mm (9 Square: 246.7 x 246.7mm

11/16

3 Position ‘Tri Grip®’ dog

ﬁxings

Gold plated ‘push’ type

terminals

Mineral ﬁlled ABS

(UL94-V0 rated, RoHS

complient)

”)

Template
