Climate Series 3G
Product Manual
Page 2
Register your Climate Series 3G speakers
to ensure the best possible product and customer support
Register your speakers using the QR code
or visit monitoraudio.com/registration
Welcome to Climate Series 3G
Thank you for purchasing your Climate Series 3G speakers.
In this product manual, you’ll ind information about setting up your system
and how to maintain your speakers for a lifetime of enjoyment.
If you need any further assistance, please contact our technical team
at monitoraudio.com/support
Contents
Unboxing 2
Preparing your installation 4
Mounting bracket 6
Wiring your speakers 8
Positioning and mounting speakers 10
Using your speakers 12
Care & maintenance 13
Warranty 14
Speciications 15
1
Page 3
Unboxing
Before you unpack your speakers, please make sure that there is plenty of clean loor area
available. Pictorial guides printed on the carton show you the ideal method for unpacking.
Inside the carton, you will ind a pair of speakers and the following accessories:
• Brackets
• Quick start guide
• Safety instructions
• Bolts
• Torx tool
Lay the box down on the loor so the top of the carton is facing up. Remove the Accessories and
Documents envelope. Remove the pulp top cap. Carefully lift each speaker out of the box, holding
the sides of the cabinet.
Remove the loudspeakers from the protective bags.
2 3
Page 4
Preparing your installation
Always determine where the Climate 3G speakers will be ixed and the structure of the wall.
The Climate 3G speakers can be mounted in horizontal or vertical orientation.
Note: We do not supply wall ixing screws and plugs with the Climate Series 3G. Please only use
suitable ixings for the type of wall construction the speakers will be ixed to. We recommend
using countersunk screws maximum size M4.
For safety reasons, if you are unsure of your ability to provide a secure and safe ixing, do
not attempt to ix these speakers, please obtain the services of a competent and
qualiied tradesperson.
CAUTION: Ensure that there are no water pipes or electricity cables running within the
wall or ceiling structure before cutting the speaker apertures. Work from secure steps
and avoid trailing wires.
Vertical
Horizontal
4 5
Page 5
Mounting bracket
Peel back the wall bracket terminal cover to reveal the terminals and ixing points.
The terminal cover will peel away at the top but remain connected at the bottom.
Fix the bracket to the wall with the appropiate screws and wall plugs for the wall construction
(not included).
6 7
Page 6
Wiring your speakers
The Climate 3G wall bracket has a channel on the back for external cable management
(maximum cable thickness 4 mm) or the cable can be fed through the wall directly into the
opening.
With the terminals still visible, feed the speaker cable through the opening and lock in place using
the clamping terminals. There is a positive and negative terminal connection. Ensure to keep
positive and negative connections matching from the ampliier.
8 9
Page 7
Positioning and mounting speakers
Position the speaker on the bracket and set the desired angle. The interlocking teeth on the
bracket and speaker insert provide 11 degree increments of movement and then prevent
movement once locked into place.
Support the speaker in position and ix it in place using the supplied bolt and torx tool (size T25).
If you wish to move away from the speaker to check the angle you can tighten the bolt partially to
the point it is holding the speaker in place and then tighten fully once decided.
10 11
Page 8
Using your speakers Care & maintenance
Running in your speakers
Run your speakers in by playing normal music at low-mid listening levels for approximately 5070
hours play time. You may ind the sound will continue to improve even after the 70 hour mark.
This can be done naturally over time: like a ine wine the performance will improve with age.
Upkeep of cabinets
Whilst the Climate Series 3G is weather resistant (IP66 rating) and can be kept outside all year,
to help preserve the inish of your speakers it is suggested that during winter months (when
playback is not as frequent or common) to cover or bring the speakers indoors. A damp cloth can
be used to clean the product.
What is an IP66 rating?
The Ingress Protection Rating, also referred to as IP code or IP rating is an international standard
which indicates the sealing eectiveness against water and dust.
Your Climate Series 3G speakers are IP66 rated. This means that they are dust and water tight.
12 13
Page 9
Warranty
Specications
In the unlikely event that there is a defect with this product, it is covered by
the Monitor Audio manufacturer’s warranty, provided that the product was
supplied by an authorised Monitor Audio retailer.
For the period of cover please refer to the product page on our website
at monitoraudio.com
Register your Climate Series 3G speakers
to ensure the best possible product and customer support
Register your speakers using the QR code
or visit monitoraudio.com/registration
Speciication CL2 S CL2 M
System Format
Frequency Response,
On-Wall (-6 dB)
Sensitivity (2.83 Vrms @ 1 m, Installed)
Nominal Impedance
Minimum Impedance (20 Hz to 20 kHz)
Maximum Peak SPL (AES75, Z-weighted)
Continuous Power Handling (CTA 426B)
Recommended Ampliier Power
(RMS, Music Signal)
Bass Alignment
Crossover Frequency
Drive Unit Complement
Avalible Finishes
Included Accessories
External Dimensions
with all accessories itted
(H x W x D)
Weight (Product, Each)
IP rating
2-way 2-way
56 Hz - 30 kHz 42 Hz - 30 kHz
84 dB 85.5 dB
6 Ohms 6 Ohms
4.9 Ohms 4.8 Ohms
108 dB 110 dB
70 W 100 W
150 W 200 W
Auxiliary Bass Radiator Auxiliary Bass Radiator
3.3 kHz 2.6 kHz
1x 4" CCAM RST II mid-bass driver
1x 25 mm CCAM tweeter
Black
White
Brackets
Quick start guide
Safety instructions
Bolts
Torx tool
247 x 140 x 217 mm
3/4
1/2
9/16
(9
x 5
x 8
")
2.7 kg (5 lb 15 oz) 4.1 kg (9 lb 1 oz)
IP66 IP66
1x 6" CCAM RST II mid-bass driver
1x 25 mm CCAM tweeter
Black
White
Brackets
Quick start guide
Safety instructions
Bolts
Torx tool
332 x 190 x 240 mm
1/16
(13
1/2
7/16
x 7
x 9
")
14 15
Page 10
Listen Again.
Monitor Audio Ltd.
24 Brook Road
Rayleigh, Essex
SS6 7XJ
England
Tel: +44 (0)1268 740580
Email: [email protected]
monitoraudio.com
©Monitor Audio Ltd. | V12024 - Climate Series 3G
