USER GUIDE
BAOBOO COAT RACK
Natural / Stylish / Unique
HARDWARE
DRAWER ASSEMBLY INSTRUCTIONS
Front Back
(a) Side Frame x 2
(Left and Right)
w/ hole
on back side
(c) Panel x 1 (Smaller than others)
(d) Panel x 1 (With groove on one side)
(e) Small Back Panel x 1
(f) Large Back Panel x 2 (k) Top Hanging Rod
(l) Drawer Side Panel x 2
(o) Short Screw
(p) Medium Screw
(m) Top Frame x 2 (n) Hooks x 8
(g) Panel x 2 (With holes on both side)
(j) Drawer Bottom Panel x 1
(q) Long Screw
(h) Drawer Back Panel x 1
(i) Drawer Front Panel x 1
(r) Bolt
w/ hole
on back side
①
Secure Drawer Front Panel (i) and
Drawer Side Panels (l) with Medium
Screws (p).
②
Insert Drawer Bottom Panel (j)
along the Groove.
© 2020-2021 by Pundarika LLC - MoNiBloom.com
③
Secure Drawer Back Panel (h) with
Medium Screws (p).
DOOR PANEL WITH STOPPER ASSEMBLY INSTRUCTIONS
①
Install Door Gaskets (t) on the Back of Door Panels (b) with
Short Screws (o).
②
Install Door Stoppers (u) on Panel (g) with Short Screws
(o).
ATTENTION
1
Please always read and follow the assembly, maintenance and operating
instruction.
2
Do not discard any of the packaging until you have checked that you have all
the parts and pack of fittings.
3
Keep children away during assembly. This item contains small parts which can
be swallowed by children.
4
Wipe frames with water gently, do not use bleach, acid, or other solvents.
5
Check all hardwares before assembly. Incorrect parts used may lead to
damage.
(b) Door Panel x 2
(Left and Right)
Scan the QR code to view the
(s) Dowel
© 2020-2021 by Pundarika LLC - MoNiBloom.com © 2020-2021 by Pundarika LLC - MoNiBloom.com
(t) Door Gasket (v) Allen Wrench
(u) Door Stopper
assembly video.
FINISHED PRODUCT
ASSEMBLY INSTRUCTIONS
Panel (g)
Panel (d)
Panel (g)
Panel (c)
1
Secure Side Frame (a) and Panel (g) with Long Screws (q). Keep grooves aligned.
Small Back
Panel (e)
Large Back Panel (f)
4
Insert rest of Small and Large Back Panels (e)(f) along the groove.
2
Secure Panels (c)(d)(g) with Long Screws (q) as picture shown. Keep grooves
aligned on all panels.
© 2020-2021 by Pundarika LLC - MoNiBloom.com
5
Secure Side Frame (a) with Long Screws (q).
3
Insert Large Back Panel (f) along the groove.
6
Insert Dowel (s) in the pre-drilled hole on Panel (g) as picture shown.
7
Insert Bolts (r) on Door Panel (b) then install on the main frame.
8
Install Top Frames (m) and Top Hanging Rod (k) with Long Screws (q).
© 2020-2021 by Pundarika LLC - MoNiBloom.com
9
Install all Hooks (n) with Long Screws (q). Insert the drawer. Done!
