Page 1
OUTDOOR FIREPLACES
Monessen
Page 2
WARM
WELCOME
Nothing invites or delights
like the dancing flames of a
fire. For thousands of years
fire has been the focal point
of hearth and home and,
like so many families
before, we invite you to
sit by ours and enjoy their
warmth and beauty.
ODWR400
ODWR500
Page 3
MAKE THE OUTDOORS GREAT
AGAIN WITH AN OUTDOOR
FIREPLACE FROM MONESSEN...
HWB700OD WOOD BURNING FIREPLACE
Enjoy the crackling hiss of a roaring wood fire
surrounded by the sophisticated style of the
Monessen outdoor wood burning fireplace.
No longer just the stuff of campfires, the real
wood flames of the Monessen outdoor wood
burning fireplace add elegance and warmth
to any outdoor room or patio setting.
Bring the outdoors in by installing the
Monessen outdoor wood burning fireplace
into any indoor room where a proper venting
system can be installed.
[\
AL FRESCO
ODWR400/500 WOOD BURNING FIREPLACES
Nothing enhances outdoor ambiance like the
elegant stainless steel Al Fresco wood burning
fireplaces from Monessen. Build your outdoor
room around their radiant heat and expansive
view of real wood flames. Available in both
36 and 42 inch sizes and with optional bi fold
stainless steel doors, the Al Fresco will make
the most of your outdoor living space.
HWB700OD Indoor Fireplace
STANDARD FEATURES FOR ALL UNITS:
HWB700OD
• 26 3/8” deep
• Stainless steel
construction
• Herringbone refractory
firebrick lining
• Side gas line access
• Can be installed
indoors or out
• Built in flue damper
• Mesh screen
• Basket grate
ODWR400/500
• 22” deep
• Stainless steel
construction
• Refractory brick
firebox lining
• Side gas line access
• Built in flue damper
• Mesh screen
• Basket grate
Page 4
Monessen
Outdoor Fireplaces
HPBA
Hearth, Patio & Barbecue Association
Model HWB700OD ODWR400 ODWR500
Dimensions (Actual) 53 1/8”W x 52 7/8”H x 26 3/8”D 40”W x 39 5/8”H x 22”D 46”W x 39 5/8”H x 22”D
imensions (Framing) 53 5/8”W x 53 1/8”H x 27 7/8”D 41”W x 43 3/4”H x 22 1/2”D 47”W x 43 3/4”H x 22 1/2”D
D
Viewing Area 27”H x 44”W (1188sq.in.) 36”W x 23”H (828sq.in.) 42”W x 23”H (966sq.in.)
Radiant or Circulating Radiant Radiant Radiant
Design Certified OMNI UL UL
Optional Accessories
HW B70 0OD
• Full framed glass doors
• Stainless steel glass doors
• Outside air kit
• Duct connector
• OSA duct
OD WR4 00/ 5 00
• Bi-fold doors in weather resistant stainless steel
• Outside air kit
MADE IN U.S.A.
Your Monessen Dealer:
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the
product and all applicable building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this
brochure are for illustrative purposes only and are not intended for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the
product are subject to change without notice. © 2008 Monessen Hearth Systems Co.
www.monessenhearth.com
Ver.03 MON9108
