MONARCH INSTRUMENT Track-It XT Instruction Manual

Instruction Manual

Extreme Temperature
(XT) Data Logger

www. .com

[e-mail]1.800.561.8187

Safeguards and Precautions

1. Read and follow all instructions in this manual carefully, and retain this manual
for future reference.

2. Do not open the unit in a high humidity environment; it will cause condensation
inside the unit.

3. Do not operate this device in flammable or explosive atmospheres.

4. This device has no power switch. It will be in operation as soon as power is
connected or battery is inserted.

5. Do not use this instrument in any manner inconsistent with these operating in­structions or under any conditions that exceed the environmental specifications
stated.

6. There are no user serviceable parts in this instrument. Refer service to a quali­fied technician.

7. The Logger may be hot when handling, use safety precautions.

In order to comply with EU Directive 2012/19/EU on Waste Electrical and

ronic Equipment (WEEE): This product may contain material which

Elect

could be hazardous to human health and the environment. DO NOT

DISPOSE of this product as unsorted municipal waste. This product needs to
be RECYCLED in accordance with local regulations, contact your local authorities for
more information. This product may be returnable to your distributor for recycling ­contact the distributor for details.

Monarch Instrument’s Limited Warranty applies.
Warranty Registration and Extended Warranty coverage available online

Extreme Temperature

(XT) Data Logger

TABLE OF CONTENTS:

1.0 INTRODUCTION ........................................................... 1

2.0 GETTING STARTED ....................................................... 1

3.0 LOGGER READER ......................................................... 3

4.0 REPLACING THE BATTERY ............................................ 4

5.0 SPECIFICATIONS .......................................................... 5

6.0 ACCESSORIES............................................................... 6

7.0 OPTIONS ..................................................................... 6

Track-It™ is a trademark of Monarch Instrument, Amherst New Hampshire, USA

Excel is either a registered trademark or trademark of MicrosoŌ CorporaƟon in the United States and/or other

countries

.

www. .com

[e-mail]1.800.561.8187

1.0 INTRODUCTION

The Extreme Temperature (XT) Logger series consists of a self-contained
environmentally sealed (IP68) 316L Stainless Steel enclosure with one or
two temperature channels using probes of various configuraƟons. The
loggers are designed to measure temperatures from -50° to +150°C
(-58° to 302°F). The entire unit may be placed in the temperature environment.
The flexible probe is capable of measuring temperatures from -70° to
+300°C (-94° to +572°F). (Probe only).

The units are programmed via software running on a
Windows PC. Communications is via a USB-A to MiniB
cable from PC to the READER that the logger is inserted
into. See section 3.0 for more on the READER.

Once programmed, the logger will record temperature from once every 2
seconds to once every 24 hours. Advanced temperature compensated
RTD technology allows for extremely accurate measurement with the
enƟre logger in the temperature environment.

The Logger system and soŌware meets the FDA RegulaƟon 21 CFR Part
11 Requirements for Electronic Records, Electronic Signatures, and com­plies with DIN ISO 17665 for moist heat (saturated steam) sterilizaƟon of
medical products.

2.0 GETTING STARTED

2.1 Install USB Driver and Track-It So

IMPORTANT: Do NOT plug the READER into the USB port unl AFTER
the USB Driver and Track-It Soware have been installed.

ware

Track-It™ Extreme Data Logger is a trademark of

Monarch Instrument, all rights reserved.

www. .com

1

[e-mail]1.800.561.8187

1. Click “Install the USB
Driver” and follow the
prompts. Click “Continue
Anyway” if you see the

message about software
installaƟon.

2. Click “Install Software”
and follow the instruc­Ɵons to complete the
installation. The software
is now ready for use.

Logger and SoŌware manuals may also be accessed from the
installaƟon screen.

2.2 Connect Reader and Start Track-It Soware

Connect READER to PC USB port with the supplied cable. If
the “Found New Hardware Wizard” appears, follow the
prompts to complete the installaƟon. Insert the Track-It
logger into READER. Start the Track-It SoŌware by double­clicking the Track-It icon (shown right) on your PC desktop or
from the Start menu.
If the USB driver installed
properly, you will see “Device
Connected” displayed in the
lower right hand corner of the
Track-It Software window.

2.3 Configure Logger

Select the “Device Setup” tab. The soŌware will automaƟcally retrieve
and display the data logger configuraƟon.

Review default factory configuraƟon seƫngs and make any neces­sary changes—sample rates, triggers, alarms, etc. Be sure that the
Ɵme and date is set properly.

Click the “Send Config” buƩon under the Device ConfiguraƟon
secƟon of the window. Your data logger is now operaonal!

2

3.0 LOGGER READER

CAUTION – THE LOGGER MAY BE HOT.
DO NOT INSERT INTO READER WHILE HOT.

To configure or read data from the logger
you will need the logger READER. This
connects to your PC via a USB A-Male to
Mini-B cable (Fig 2). The reader is powered
via the USB plug, however you can also
power the READER through the DC Power
socket. (Fig 3) Use a 9-volt, center posiƟve,
power supply. Monarch part # 6280-022.

Plug the READER into the PC. The “ON”
LED will light (Fig 4). Insert the logger into
the base - the “READY” LED will light green
(Fig 5). Run the “Track-It

TM

SoŌware”.
Whenever the soŌware is communicaƟng
with the logger the READY LED will light
amber. Do not remove the logger when

this LED is amber.

“ON” LED light “READY” LED light

Figure 4—Data Logger Reader Base

Monarch Part Number 5396-9911

Figure 2

Figure 3

Figure 5

3

www. .com

[e-mail]1.800.561.8187

4.0 REPLACING THE BATTERY

To replace the baƩery the top or “lid” of the logger enclosure needs to
be unscrewed (Fig 6) from the boƩom. There are two flats on the “lid” to
facilitate the use of a wrench. Once the baƩery is exposed it may be re­moved and replaced. Note the posiƟve terminal when replacing (Fig 7).

Figure 6-Counterclockwise Figure 7-BaƩery Polarity Figure 8-LED Blinking

Use only a 3B5700 ½ AA Lithium Sulfuryl Chloride 3.9V 800mAh High

Temperature (150°C) baery. Monarch Part No 5396-9934 or similar.

If the new baƩery has been inserted correctly, the LED on the opposite
side of the board will blink twice within 5 seconds (Fig 8). Replace the
boƩom and be sure to Ɵghten it completely to ensure a good seal. The
O-ring should not create a gap between the top and the boƩom.

Inserted Not Tight Enough Figure 9-Good Seal

4

For posiƟon Only

New graphics to come.

LED blinking 2X

FPO

X

√

FPO

For posiƟon Only

New graphics to come.

5.0 SPECIFICATIONS

Measurement
Temperature Range
(fixed probe): -50° to +150°C (-58° to 302°F)
Accuracy: +0.1°C from -30° to +150°C (+0.2°F from -22 to 302°F)

+0.2°C from -50°C to -30 (+0.4°F from -58°F to -22°F)

Temperature Range
(flexible probe): -70° to +300°C (-94° to 572°F) (Probe ONLY)
Accuracy: +0.1°C from -30° to +150°C (+0.2°F from -22° to 302°F)
+25°C from -70° to +300°C (+0.5°F from -22° to 572°F)

Environmental
Temperature Range: -50° to +150°C (-58 to 302°F)
Humidity: 0 to 100% condensing
Pressure: 0 to 9 bar (0 to 130 psi)
Submersion: IP68 – 1.5m (~ 5 feet) of static water indefinitely
Baery: 3B5700 ½ AA Lithium Sulfuryl Chloride 3.9V 800

mAh rated 150°C. Field Replaceable Monarch
P/N 5396-9934

Life: Up to 2 years typical @ 1 minute sample rate

(@20°C)
Enclosure: Material: 316L stainless Steel.
Dimensions: 3.6cm (dia.) x 5.5cm / 1.43” (dia.) x 2.30”

(Excl. probes)
Probe Lengths: 2.5cm, 5cm, 10cm, 56cm flexible.

General
Sample Rate: User configured, 1 sample every 2 seconds to 1 every

No. of Samples: 30,000 stored in non-volatile memory.

Record Trigger: Two independent triggers. Multiple trigger modes:

Instantaneous, on alarm, time and date

1”, 2”, 4”, 22” Flexible.

24 hours

(start and stop).

5

www. .com

[e-mail]1.800.561.8187

SPECIFICATIONS continued

Record Mode: Fill to end of memory or cyclic, number of samples and

time duration.

Alarms: 2 user programmable alarms. High or Low.

Real Time Clock: Accuracy: +1 minute/year at 25°C (77°F)

Communication: READER with USB connection. No need to open Logger

to read data or program.

Calibration: NIST Traceable calibration

Compliance: CE compliant. Low Voltage Directive (LVD) 2014/35/EU

Electromagnetic Compatibility Directive (EMC)

2014/30/EU

Restriction of Hazardous Substances (RoHS) Directive

2011/65/EU

Software: Track-It™ Software —Program device, view data

(historic or real time), plot data, export to Excel™.

FDA Regulation 21CFR Part 11 compliant

Product specifications subject to change without notice.

6.0 ACCESSORIES

Replacement BaƩery & O-ring PN: 5396-9934
Replacement O-rings PN: 5396-9931
USB 2.0 cable PN: 5396-9911
USB Extension Cable PN: 5396-9901
Track-It SoŌware CD PN: 5396-9902
Housing Silicon Gripper PN: 5396-9932
Wrench PN: 5396-9933
Reader PN: 5396-9930

PN: 5396-9931 PN: 5396-9934

PN: 5396-9911 PN: 5396-9901

PN: 5396-9902 PN: 5396-9933

6

www. .com

7

[e-mail]1.800.561.8187

Printed in the U.S.A.

© Copyright 2018 Monarch Instrument, all rights reserved

1071-4396-510-518 JH
