Moffat RR11A User Manual
Main Features
SMART CHILL - Variable air velocity.
RC11 - 11kg Blast Chill capacity per cycle.
RC25 - 25kg Blast Chill capacity per cycle.
Food product is required to be correctly portioned
in Gastronorm pans.
(Remote condensing unit not included.)
Description
Removable and adjustable shelf runners able to
accept Gastronorm pans.
Temperature display in °C.
Mode selection timer or four point Frigiprobe by
internal food temperature.
Automatic preservation mode at the end of cycle.
Defrost feature removes ice from evaporator.
R404A refrigerant - CFC free.
Self-closing door magnetically seals. Door remains
open past 90°C for convenient loading and
unloading.
Internal coved corners, removable door gasket.
Water protection index rating IP459.
Adjustable legs for levelling.
Temperature recorder with printer (optional).
Foodservice & Bakery Reach-In Blast Chiller/Freezer
designed to accept Gastronorm 1/1 pans
RR11A Blast Chill
RR25A Blast Chill
120 (A) 60
770
955
190 (A)
790
70 (MIN)
330 (CU)
150
A = Electrical Power Supply
770
1546
230 (D)
190 (A)
430 (D')
790
70 (MIN)
770 (CU)
150
A = Electrical Power Supply D = Liquid line RR25S only
D' = Suction line RR25S only
610 (D)
385 (D')
531
120 (A)
445 (CU)
1500
60
531
445 (CU)
1500
Refrigeration Equipment RR25S only
• Complete remote condensing unit.
Suitable for local conditions.
• Condensing capacity upright Blast Chiller
930/1900W for the respective evaporation
temperatures of -20/0°C.
• Remote condensing unit with ‘pump
down’ control.
Disclaimer:
All unit capacities are based on subjective
testing. Moffat accepts no liability for
production values.
