Moffat has built its reputation on a tradition of developing innovative products and

supporting this with exceptional customer service.

As part of the ALI Group, one of the world’s largest designers, manufacturers
and suppliers of equipment to the foodservice industry, the continued success of
Moffat is built around a long-term commitment to research and development and the
introduction of innovative new products to the market.

The range of Moffat Rotel Ovens incorporate the latest in bakery technology
and are proudly designed and manufactured in Australia. They offer unique
advantages over traditional ovens and are presently being exported around the world.

Design

Designed specifically for heavy duty retail use, all models have
stainless steel internal chambers. The design of the Rotel ovens
ensures all products within the chamber experience uniform
baking conditions, therefore giving a superior even bake over
other conventional deck ovens.
The Rotel is ideal for the baker who requires a multi chambered
oven with excellent heat recovery and live steaming system
inbuilt.

Features

The Rotel steaming system produces steam within the oven
chamber and therefore eliminates the expensive repairs
necessary on conventional static deck ovens. Unlike other
models that rely on expensive independent steaming systems,
the only moving part incorporated into the design of the Rotel
Steaming system is a solenoid.
The internal rotation of the oven guarantees a perfect bake every
time and gives excellent results for all types of bread, rolls, cakes

and pastry products.

Applications

Designed and
manufactured in
Australia the Rotel oven
has been installed into
bakeries for over two
decades. Both the Mini
and Slimline Rotels
have been designed for
heavy-duty use in
bakeries, cafes,
restaurants,
supermarkets, clubs
and government
departments. They are

currently used in more
than 20 countries for general purpose or specific dedicated
functions.

Rotel 2

Mini Rotel Oven

This compact oven can be used to
produce an extensive range of bakery
products. Various models are
available and range in size from 4 to
12 tray capacity. All are supplied
with glass doors, internal lighting
and inbuilt steaming systems. The
split deck option provides double the
tray capacity within the one baking
chamber.

Split deck -

two turntables within the one baking chamber

Stainless steel internal chambers

Independent temperature controls for each oven chamber

Timer and steam controls fitted to all chambers

Supplied with O.H.&S. Manuals as required under Australian standards

All models fitted with wheels

Options:

Steel plate sole for split deck chambers

Ceramic sole for standard deck chambers

Setter loader available

High crown height 300mm.

(Note crown at 300mm is total height. Recommended product height 270mm)

Model Capacity Dimensions (w x d x h) Electrical Specifications Weight

R6/16 6 tray 1390mm x 1405mm x 2195mm 3P+N+E, 400-415V, 50Hz, 19.5kW 720kg
R10/16 10 tray 1390mm x 1405mm x 2060mm 3P+N+E, 400-415V, 50Hz, 27kW 900kg
R12/16 12 tray 1390mm x 1405mm x 2180mm
MR4D2S/16 12 tray 1390mm x 1405mm x 2450mm 3P+N+E, 400-415V, 50Hz, 32kW 1220kg

3P+N+E, 400-415V, 50Hz, 30kW 980kg

More bakers have won
awards baking in a ROTEL
than in any other oven
sold in Australia

R6/18 6 tray 1490mm x 1505mm x 2195mm
R10/18 10 tray 1490mm x 1505mm x 2060mm 940kg
R12/18 12 tray 1490mm x 1505mm x 2180mm
MR4D2S/18 12 tray 1490mm x 1505mm x 2450mm 3P+N+E, 400-415V, 50Hz, 32kW 1260kg

3P+N+E, 400-415V, 50Hz, 19.5kW 760kg
3P+N+E, 400-415V, 50Hz, 27kW
3P+N+E, 400-415V, 50Hz, 30kW 1020kg

The Slimline Rotel is used in more
bakeries throughout Australia than
any other type of baking oven.

Designed in Australia for all types of
bakeries, the Rotel has proven to be
far more flexible than conventional
decks ovens, rack ovens or
convection ovens.

It is perfectly suited to producing a
large variety of baked product each
requiring a different baking time and
temperature.

Stainless steel internal chambers

Independent temperature controls for each oven chamber

Timer and steam controls fitted to all chambers

Supplied with O.H.&S. Manuals as required under Australian standards

All models fitted with wheels

Rotel 2

Slimline Rotel Oven

Options:

Steel plate sole for split deck chambers

Ceramic sole for standard deck chambers

Setter loader available

High crown height 300mm.

(Note crown at 300mm is total height. Recommended product height 270mm)

Model Capacity Dimensions (w x d x h) Electrical Specifications Weight

SR3D1S/16 16 tray 2610mm x 1405mm x 2210mm 3P+N+E, 400-415V, 50Hz, 45kW 1400kg
SR3D2S/16 20 tray 2610mm x 1405mm x 2280mm
SR24/16 24 tray 2610mm x 1405mm x 2270mm 3P+N+E, 400-415V, 50Hz, 60kW 1900kg
SR4D2S/16 24 tray 2610mm x 1405mm x 2500mm 3P+N+E, 400-415V, 50Hz, 65kW 2040kg

SR3D1S/18 16 tray 2870mm x 1505mm x 2210mm
SR3D2S/18 20 tray 2870mm x 1505mm x 2280mm 1600kg
SR24/18 24 tray 2870mm x 1505mm x 2270mm
SR4D2S/18 24 tray 2870mm x 1505mm x 2500mm 3P+N+E, 400-415V, 50Hz, 65kW 2240kg

In line with policy to continually develop and improve its products, Moffat reserves the right to change specifications and design without notice.
