Moffat GLV Installation Manual

GLV

81

OPERATOR MANUAL

Distributed in
Australia by 1 800 337 963
740 SpringvaleRoad, Mulgrave 3170, Victoria, Tel [phone] Fax [phone]

Service 1 800 622 216
Parts

82

8

n

3

6

83

Safe Installation and Use of Wash Equipment

As with all electrical and mechanical equipment dishwashing equipment
can be hazardous if installed or operated incorrectly.

Installation

9 Use qualified, skilled personnel
9 Follow installation instructions
9 Connect to correct voltage and supply current
9 Provide fully accessible Electrical Isolation Switch

Training and Supervision

9 Read and Understand the Operating instructions
9 Train all staff.
9 This appliance is not intended for use by young children.
9 Young Children should be supervised to ensure they do not play with the

appliance.

9 This appliance is not intended for use by infirm persons without supervision

Hot Surfaces

9 Be aware some surfaces can be hot.

Chemicals

9 Commercial dishwashing detergents are hazardous
9 Read and follow the safety information found on the labels of detergent

containers and Material Safety Data Sheets

9 Handle with care
9 Use protective eyewear and clothing if decanting containers

Hot Water

9 Door safety switches are designed for emergency use only.
9 WAIT for the green cycle light to go out before opening the door.
9 Wash water is 60°C and contains caustic detergent so DO NOT put hands in

wash water.

Cleaning

9 DO NOT hose down the machine or splash water over the exterior.
9 Watch for broken glass etc when cleaning the inside of the machine especially

with glasswashers..

If the supply cord is damaged it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.

For further information on any of the above contact

Distributed i
Austr al i a by 1 800 337 96
740 SpringvaleRoad, Mulgrave 3170, Victoria, Tel [phone] Fax [phone]

Service 1 800 622 2 1
Parts

GLV

84

OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS

START UP

Fit wash pump filter, scrap trays and shut door.
Turn wall and machine power switches ON.
ON light glows red and machine fills automatically.
When the RINSE READY light (tick symbol) and WASH READY light (water symbol)
glow amber the machine is ready to run and may be started.

OPERATION

Load rack into machine and shut door.
Press start button (1,2 or 3) for 1,2 or 3 minutes accordingly.
CYCLE light glows green while machine operates.
When CYCLE light goes out, cycle is complete.
Remove rack. Close door.

Note:

Machine will not operate unless READY lights are ON.

SHUT DOWN - IMPORTANT - EVERY NIGHT

Open the door and turn DRAIN switch on.

Allow to drain for approximately 2 minutes
Turn DRAIN and POWER switches off.
Remove scrap trays and wash pump filter, rinse clean and replace.

We recommend regular removal and flushing of wash and rinse arms. To remove arm
assembly, undo thumbscrew.
To clean wash/rinse arms use a toothpick or paperclip, if necessary, to clear the jets,
remove end screws from arms and flush with water/.

Use of correct type and quantities of detergent is essential to the effective operation of
this machine. Use only low foam detergents. Contact your chemical supply company to
either fit an automatic dispenser or to supply suitable powder detergent to manually add
to wash water.

For information on recommended detergent suppliers or local service agents, contact:

Rev 1A
20/5/04
