a turbochef speed cook oven
Accelerating the World of Cooking
TM
When a foodservice operator needs to provide hot quality food
to customers quickly, TurboChef offers the C3 speed cook oven.
The C3 uses a patented combination of high speed impinged air
and precise bursts of microwave energy to cook up to 10 times
faster than conventional methods.
Customers agree the C3 cooks, bakes, browns, broils and roasts with quality
comparable or superior to traditional cooking. UL
®
Certified ventless, the C3 does
not require a hood, ventilation or fire suppression equipment, saving thousands in
expenses. Its programmable, push-button control panel makes operation simple for
anyone. And its small, stackable footprint maximizes cooking space.
CHÂTEAUBRIAND (
35:00
8:00
Conventional Oven
The C3 77% Faster
refrigerated
)
CHICKEN WINGS (frozen)
17:30
2:30
86% Faster
“The TurboChef ovens absolutely enhance
“We chose the C3 oven because of its
my ability to be able to serve food in the
way we do at the restaurant – at the last
moment, where everything is just perfectly
cooked, perfectly fresh. Speed, quality,
purity. All these things are answered with
the TurboChef oven.”
— CHARLIE TROTTER, Principal
Trotters to Go
“Consumers don’t have to stand in line to
get our cooked-to-order products.”
— MI CHA EL J . W ATZ , Director, New Concept Development
Loews Cineplex Entertainment
overwhelming versatility.”
— MARK TH O M AS, Vice President
Well Bread Restaurant Services Group,
SportServices Corporation
“TurboChef has been second to none in
labor savings, cooking versatility and food
quality.”
— DENNIS KANE, Executive Chef
Holiday Inn Franchises
“This is the oven that will change
restaurant cooking in the future.”
— DEAN FE A R ING, Executive Chef
Mansion on Turtle Creek
SALMON FILLET (refrigerated)
9:00
1:30
83% Faster
7 PEPPERONI PIZZA
19:00
2:30
All food shown was prepared in a TurboChef speed cook oven.
87% Faster
(frozen)
STANDARD FEATURES
Two Ceramic Cooking Platters and Wave Guide Caps
Forced vertical recirculated impingement hot air system
Bottom-launched microwave system
Variable speed Blower Motor
Programmable with up to 64 product cooking profiles
Computerized, built-in self-diagnostic monitor for
oven components and performance
Stackable design
Catalytic Converter eliminates flavor transfer between
foods, reduces emissions/qualifies for ventless operation
Warranty – one year parts and labor
CONSTRUCTION
Exterior
430 stainless steel front, top, sides and back
4 (102 mm) chrome plated adjustable legs
Powder coated handle
Cool to the touch pull down door with microwave seal
Interior
Fully insulated Cook Chamber
304 stainless steel liner with large radius corners
Removable Ceramic Cooking Platter with moulded
product standoffs
Removable Wave Guide Cap
304 stainless steel removable grease collection pan
DIMENSIONS
Single Units
Height 21.5 (546 mm)
on legs 25.5 (648 mm)
Width 29 (736 mm)
Depth 29.5 (749 mm)
with handle 32.25 (819 mm)
Weight 255 lbs. (116 kg)
Cook Chamber
Height
Width
7.1 (180 mm)
17.8 (452 mm)
Depth 14.5 (368 mm)
Volume 1.1 cu. ft. (31 Liters)
Wall Clearance
Top/Sides 2 (51 mm)
CERTIFICATIONS
UL, NSF, cUL
TurboChef reserves the right to make substitutions of components or
change specifications without prior notice. Multiple patents pending.
CONTROL OPTIONS
C3 Professional
Simplified interface, non-programmable
C3 Smart
Smart intuitive control with built-in cooking profiles
to assist the operator
C3 Custom
Customer/item specific profiles that are developed
with TurboChef for ease of operation
RS 232 communication port provides direct computer
and MIM box access to update menu selections and
change product information
ELECTRICAL SPECIFICATIONS
Europe/Asia/Pacific/Australia
C3/C Mult Model (3 Phase, TC3-0602-1w)
Phase 3 Phase
Voltage 380-415 VAC
Frequency 50 or 60 Hz
Current 16 Amp
Cord 5 wire (inc. ground), 1.5m
H07RN-F
Plug IEC 309, 5pin, 32 Amp, (red)
Max Input 7.4 kW
Microwave Power In 2 kW
C3/C Mult Model
Phase 3 Phase
Voltage 230 VAC
Frequency 50 Hz
Current 30 amp
Cord 4 wire (inc. ground)
Plug IEC 309, 4pin, 32 Amp, (blue)
Max Input 7.4 kW
