SINK DESCRIPTION
Model
Number
G202854 4 5.5, 6.5 Center
G202853 3 5.5, 6.5 Center
G202864
G202861
4
1
5.5, 8
Center
Center
Faucet
Holes
Depth-
Inches
L,R
Drain
Placement
Model
Specied
22"
(589mm)
7.5"
(191mm)
1.875"
(48mm)
16"
(406mm)
4"
(104mm)
4.125"
(105mm)
2.75" (70mm) R. TYP.
(8) Places
33"
(838mm)
8"
(203mm)
1.5" (38mm) DIA. TYP.
3.5" ( 8 9 m m )
DIA. TYP.
21"
(533mm)
4"
(104mm)
4"
(104mm)
.3125" (8mm) R. TYP
(4) Places
SINK OVERALL DIMENSION
COUNTERTOP CUT-OUT
BOWL
DIMENSION
CONTINUOUS
"U" CHANNEL
SINK
CLAMP
COUNTERTOP
SEALANT MATERIAL
• 2000 Series double bowl drop-in sink
• 20 gauge stainless steel, Brushed finish
• Center drain, 1 to 4 faucet holes as indicated
• U-channel mounting system, hardware included
• SoundSHIELD sound absorbing system
CUT OUT DIMENSIONS
• 32 3/8” x 21 3/8” with 3/8” corner radius. Tolerance of plus or
minus 1/16" is acceptable
STANDARDS
• Third party certified by IAPMO to meet ASME A112.19.3/CSA B45.4
and all applicable specifications referenced
WARRANTY
• Limited lifetime warranty against material or manufacturing defects
to the original consumer purchaser
Specifications
5.5, 8
Faucet Hole Configurations
1-1/2" (38mm) diameter faucet holes
4" (102mm) Center
CRITICAL DIMENSIONS
Rev. 4/15
(DO NOT SCALE)
Installation Detail
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
