ALIGN™ Technical Specication

Single Post Paper Holder

Stock Numbers:

☐ YB0409CH – Single Post
Paper Holder

Chrome Finish

☐ YB0409BN – Single Post
Paper Holder

Brushed Nickel Finish

☐ YB0409BL – Single Post
Paper Holder

Matte Black Finish

Dimensions:

YB0409

4.96"

(126.0)

6.79"

(172.5)

Materials:

Single Post Paper Holder is

constructed of zinc.

1.34"

(34.0)

2.36"

(60.0)

3.94"

(100.0)

Installation Instructions:

Note: Directions below are for installation into drywall. If installing product into a stud,
use the wood screws only.

1 Remove mounting posts from the product assemblies by loosening each setscrew.
2 Position the mounting plate on the wall in the desired location and mark holes
at the Horizontal screw location on the template if installing into drywall or vertical
screw location if installing into a stud.

3 Drill 1/4” pilot holes in marked locations.

4 Lightly tap anchors until ush with the wall.
5 Place each mounting plate over anchors and insert screws through post into anchors.
6 Tighten screws.
7 Place posts over the mounting plates with setscrew facing down and tighten setscrew.

Cleaning Instructions:

To preserve the ne nish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.

Stock Number: YB0409 Single Post Paper Holder
