Moen MOE8512 Specifications

Eva™ Technical Specication

YB2863

3-Globe Light Fixture

Dimensions:

15/16"
24mm

6-1/2"

165mm

6-1/2"

165mm

584mm

WEIGHT 10.0 lbs.

Product Information:

Stock Numbers: YB2863CH – CHROME
YB2863BN – BRUSHED NICKEL
YB2863ORB – OIL RUBBED BRONZE

Globe Service Kit: YB2869

23"

5-7/16"

138mm

9-9/16"

243mm

Materials: Zinc, glass

Voltage: 120v

Bulb: 100w max (not included); medium base

UL Listed: Yes – for dry locations

Important Notes: Turn off power during installation. Do not connect or disconnect under load.

Cleaning Notes: Clean only with a soft damp cloth. Do not use commercial or abrasive cleaners.

Stock Number: _________________________

Light Fixture By Moen Incorporated

25300 AL MOEN DRIVE • NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: [phone] • FAX: [phone]
INTERNATIONAL: (440 ) 962-2000 • FAX: [phone]
CUSTOMER SERVICE (USA): 800-882-0116 • FAX: [phone]
WWW.MOEN.COM
©2016 Moen Incorporated. Moen is a registered trademark and Eva™ is a trademark of Moen Incorporated. All rights reserved.
