Page 1
S p e c i f i c a t i o n s
S p e c i f i c a t i o n s
EASY CLEAN® XLT
Single Function Showerhead
Models: 6313
2-1/2"
(64mm)
1/2" IPS
THREADS
6" (152mm)
ARM
DESCRIPTION
• Various finishes identified by suffix
• Fixed mount showerhead only
• Nonmetallic spray face
• Nonmetallic shell
OPERATION
• Single spray
FLOW
• Showerhead is limited to 1.5 gpm (5.7 L/min) at 80 psi
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B125.1 and
all applicable requirements referenced therein
• EP suffix models are IAPMO Green listed and third party
certified to WaterSense®
WARRANTY
• Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
DESCRIPTION
• Various finishes identified by suffix
• Fixed mount showerhead only
• Nonmetallic spray face
• Nonmetallic shell
OPERATION
• Single spray
FLOW
• Showerhead is limited to 1.5 gpm (5.7 L/min) at 80 psi
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B125.1 and
all applicable requirements referenced therein
• EP suffix models are IAPMO Green listed and third party
certified to WaterSense®
WARRANTY
• Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
EASY CLEAN® XLT
Single Function Showerhead
Models: 6313
6313 SERIES
CRITIC
AL DIMENSIONS
(DO NOT SCALE)
