Page 1
I l l u s t r a t e d P a r t s
Order by Part Number
There is more than 1 version of this model.
Page down to identify the version you have.
Spout Tube Kit
176077BRB Mediterranean Bronze
176077MSRS Spot Resist Stainless
176077 Chrome
Dome
158532BRB Mediterranean Bronze
158532SRS Spot Resist Stainless
158532 Chrome
Cartridge Nut
Note: Must change nut with cartridge
144266
Set Screw
155023
BENTON™
Single-Handle High Arc Pull Out
Kitchen Faucet
MODEL HANDLE FINISH
87211BRB Lever Mediterranean Bronze
87211SRS Lever Spot Resist Stainless
87211 Lever Chrome
87211SRSSD Lever Spot Resist Stainless
w/ Soap Dispenser
Handle
157718BRB Mediterranean Bronze
157718SRS Spot Resist Stainless
157718 Chrome
Screen Washer (1.5gpm)
158550
Wand Kit
162464BRB Mediterranean Bronze
162464SRS Spot Resist Stainless
162464 Chrome
Cartridge, Cartridge Nut
and Set Screw
Escutcheon Kit
141002BRB Mediterranean Bronze
141002SRS Spot Resist Stainless
141002 Chrome
Mounting
Hardware
113173
Deck
Gasket
143338BL
Installation Tool
118305
1255
Soap Dispenser
100509 Chrome
100509SRS Spot Resist Stainless
Hose Kit
150259
Underdeck Service Kit
344113
Weight Kit
150260
Rev. 4/15
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Page 2
I l l u s t r a t e d P a r t s
Order by Part Number
Spout Tube Kit
148972BRB Mediterranean Bronze
158198SRS Spot Resist Stainless
158198 Chrome
Dome
158532BRB Mediterranean Bronze
158532SRS Spot Resist Stainless
158532 Chrome
Cartridge Nut
Note: Must change nut with cartridge
144266
Set Screw
155023
BENTON™
Single-Handle High Arc Pull Out
Kitchen Faucet
MODEL HANDLE FINISH
87211BRB Lever Mediterranean Bronze
87211SRS Lever Spot Resist Stainless
Handle
157718BRB Mediterranean Bronze
157718SRS Spot Resist Stainless
157718 Chrome
Screen Washer (1.5gpm)
158550
Wand Kit
162464BRB Mediterranean Bronze
162464SRS Spot Resist Stainless
162464 Chrome
Cartridge, Cartridge Nut
and Set Screw
Escutcheon Kit
141002BRB Mediterranean Bronze
141002SRS Spot Resist Stainless
141002 Chrome
Mounting
Hardware
113173
1255
Deck
Gasket
143338BL
Hose Kit
150259
Clip
152767
Installation Tool
118305
Weight Kit
150260
Rev. 11/13
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Page 3
I l l u s t r a t e d P a r t s
Order by Part Number
Spout Tube Kit
148972BRB Mediterranean Bronze
158198SRS Spot Resist Stainless
158198 Chrome
Dome
158532BRB Mediterranean Bronze
158532SRS Spot Resist Stainless
158532 Chrome
Cartridge Nut
Note: Must change nut with cartridge
144266
Set Screw
155023
BENTON™
Single-Handle High Arc Pull Out
Kitchen Faucet
MODEL HANDLE FINISH
87211BRB Lever Mediterranean Bronze
87211SRS Lever Spot Resist Stainless
Handle
157718BRB Mediterranean Bronze
157718SRS Spot Resist Stainless
157718 Chrome
Screen Washer (2.2gpm)
141025
Wand Kit
162464BRB Mediterranean Bronze
162464SRS Spot Resist Stainless
162464 Chrome
Cartridge, Cartridge Nut
and Set Screw
Escutcheon Kit
141002BRB Mediterranean Bronze
141002SRS Spot Resist Stainless
141002 Chrome
Mounting
Hardware
113173
1255
Deck
Gasket
143338BL
Hose Kit
150259
Clip
152767
Installation Tool
118305
Weight Kit
150260
Rev. 11/13
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
