Moen CSI2169 Specifications

25300 AL MOEN D RI VE  NOR TH OLMSTED , OH 44070
COR PORATE H EADQU ARTERS: [phone]  F AX: [phone]
IN TER NATION AL: [phone]  FAX: [phone]
CU STOMER SERVI CE (USA): 800 -882-0116  FAX: [phone]
WW W. MOEN .C OM

Copyright Creative Specialties International

Towel Bars posts are die cast from
highest quality zinc alloy (zamac) and
finished in a high quality powder
coating or metallic plated finish.

 5318CH – 18” Towel Bar

Polished Chrome Finish
Concealed Screw Mounting
5/8” Round Bar

 BP5318OWB – 18” Towe l Bar

Old World Bronze Finish
Concealed Screw Mounting
5/8” Round Bar

 BP5318SN – 18” Towel Bar

Satin Nickel Finish
Concealed Screw Mounting
5/8” Round Bar

 5324CH (BP5324CH) – 24” Towel Bar

Polished Chrome Finish
Concealed Screw Mounting
5/8” Round Bar

 BP5324OWB – 24” Towe l Bar

Old World Bronze Finish
Concealed Screw Mounting
5/8” Round Bar

 BP5324SN – 24” Towel Bar

Satin Nickel Finish
Concealed Screw Mounting
5/8” Round Bar

“BP” skus in w holesale packaging

Cleaning Instructions:

1. Position the mounting template on the wall in the desired location. Using a

level, align the template and tape it to the wall.

2. Place each mounting plate on the template with “UP” facing you.

3. One at a time, place each anchor screw through the mounting plate,

centered in each large hole. Using a Phillips screwdriver, turn the anchor
screw while applying pressure. Screw will self drill and tap into drywall.
Do not over tighten.

4. Only insert screw ½ to ¾ of the way into wall.

5. After all screws are installed, tear the template away from the wall

6. Tighten all 4 screws. Do not over tighten.

7. Assemble the towel bar and posts.

8. While assembled, position each end post with the setscrew down and place

over both mounting plates. Tighten the setscrew at the bottom of each base.

Stock Number:______________________Towel Bar
By Creative Specialties International

Materials:

Installation Instructions:

Stock Numbers:

Dimensions:

18” & 24” Towel Bar

5318 & 5324

Yorkshire Technical Specification

To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.

Literature #BA1072

Length 18" 24" 30"
Dim. "A" 21.00 27.00 33.00
Dim. "B" 19.75 25.75 31.75
Dim. "C" 15.00 21.00 27.00
