Directions below are for installation into drywall. If installing product into a stud, use the
wood screws only.
1. Position the mounting template on the w all in the desired location.
2. Using a level, align the template and tape it to the wall.
3. Drill tw o 5/16” holes at each mounting post location that corresponds to your
product. (We recommend using the horizontal holes for drywall installation).
4. Remove the template from the wall.
5. Fold ends of the plastic toggle together and insert into each hole in the wall.
6. Lightly tap anchors until flush w ith the wall.
7. One at a time, insert plastic pin into each of the anchors and lightly tap to activate
anchor. Remove pin and repeat on all anchors.
8. Remove mounting posts from the product assemblies by loosening each setscrew.
9. One at a time, place each mounting post over anchors (notch facing downward) and
insert screws through post into anchors.
10. Tighten screws.
11. Assemble the tow el bar and posts.
12. While assembled, position each end post w ith setscrews facing down and place over
both mounting posts. Tighten the setscrew at the bottom of each post.
25300 AL MOEN DR IVE N ORTH OLMSTED, OH 44070
COR PORATE HEAD QUAR TER S: (800) 321-8809 FAX: (800) 848 -6636
IN TERNATI ONAL: (440) 962 -2000 FAX: (440) 962-2726
CU STOMER SER VIC E (USA): 800 -882-0116 FAX: (888) 379-2720
WW W.MOEN. COM
Copyright Creative Specialties International Literature #BA1241
Towel bar posts are constructed of
zinc. Bar is constructed of brass.
DN0818ORB – 18” Towel Bar
Oil Rubbed Bronze Finish
DN0824ORB – 24” Towel Bar
Oil Rubbed Bronze Finish
Cleaning Instructions:
Stock Number:______________________Towel Bar
By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
18” & 24” Towel Bar
DN0818 & DN0824
Gilcrest® Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
