Moen CSI1368 Specifications

 DN4418BN – 18” Towel Bar
Brushed Nickel Finish
DN4424BN – 24” Towel Bar
Brushed Nickel Finish
DN4418CH – 18” Towel Bar
Chrome Finish
DN4424CH – 24” Towel Bar
Chrome Finish
DN4418ORB – 18” Towel Bar
Oil Rubbed Bronze Finish
DN4424ORB – 24” Towel Bar
Oil Rubbed Bronze Finish
Copyright Creative Specialties International Literature # BA1519
Towel bar post is a die cast from the highest quality zinc alloy (Zamac). Casting is plated in chrome, brushed nickel or oil rubbed bronze. Towel bar is aluminum for brushed nickel and chrome finishes and brass for oil rubbed bronze.
Cleaning Instructions:
1. Position the mounting template on the wall in the desired location.
2. Using a level, align the template and tape it to the w all.
3. Drill two 5/16” holes at each mounting post location that corresponds to
your product.
4. Remove the template from the wall.
5. Fold ends of the plastic toggle together and insert into each hole in the
wall.
6. Lightly tap anchors until flush with the wall.
7. One at a time, insert plastic pin into each of the anchors and lightly tap
to activate anchor. Remove pin and repeat on all anchors.
8. Remove mounting posts from the product assemblies by loosening
each setscrew .
9. Place the mounting plate on the wall over the installed w all anchors
w ith “UP” facing you.
10. Insert screw s through the mounting plate into the anchors. Tighten
the screws.
11. Assemble the towel bar and posts.
12. While assembled, position each end post with setscrews facing down
and place over both mounting posts. Tighten the setscrew at the bottom of each post.
Stock Number:______________________Towel Bar By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
18” & 24” Towel Bar
DN4418 & DN4424
Vale™ Technical Specification
To preserve the fine finish of this product, clean only with a soft damp cloth. Dry well. Do not use commercial or abrasive cleaners.
