Copyright Creative Specialties International 2006 Literature #BA1518
Pivoting Paper Holder post is die
cast from highest quality zinc alloy
(Zamac). Casting is plated chrome,
brushed nickel or oil rubbed bronze.
DN4408BN – Pivoting Paper
Holder
Brushed Nickel Finish
DN4408CH – Pivoting Paper
Holder
Chrome Finish
DN4408ORB – Pivoting Paper
Holder
Oil Rubbed Bronze Finish
Cleaning Instructions:
1. Position the mounting template on the wall in the desired location.
2. Using a level, align the template and tape it to the wall.
3. Drill two 5/16” holes at each mounting post location that corresponds to your
product.
4. Remove the template from the wall.
5. Fold ends of the plastic toggle together and insert into each hole in the wall.
6. Lightly tap anchors until flush with the wall.
7. One at a time, insert plastic pin into each of the anchors and lightly tap to
activate anchor. Remove pin and repeat on all anchors.
8. Remove mounting posts from the product assemblies by loosening each
setscrew.
9. Place the mounting plate on the wall over the installed wall anchors with “UP”
facing you.
10. Insert screws through the mounting plate into the anchors. Tighten the screws.
11. Place each assembly over the mounting posts with setscrews facing down.
Pivoting post with bar should be on the left side. Tighten both setscrews.
Stock Number:______________________Pivoting Paper Holder
By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Pivoting Paper Holder
DN4408
Vale™ Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
