Moen CSI1224 Specifications

Towel Ring is constructed of zinc.

 DN8386BN – Towel Ring

Brushed Nickel Finish

 DN8386CH – Towel Ring

Chrome Finish

Cleaning Instructions:

1. Remove mounting post from product assembly by loosening the setscrew .

2. Position the mounting post on the w all at desired location w ith notch facing
downward, and mark both horizontal hole locations.

3. Drill 2 holes as marked using 5/16” drill bit.

4. Fold ends of the plastic toggle anchor together (see Figure 1) and insert into
each hole in the w all.

5. Lightly tap anchors until flush w ith the wall.

6. One at a time, insert plastic pin into each anchor and lightly tap to activate
anchor (see Figure 2). Remove pin and repeat on other anchor.

7. Place mounting post over anchors w ith notch facing downw ard, and insert
screws through post into anchors.

8. Tighten screw s.

9. Place assembly over the mounting post with setscrew facing down and tighten
setscrew .

Stock Number:______________________Towel Ring
By Creative Specialties

Materials:

Installation Instructions:

Stock Numbers:

Dimensions:

Towel Ring

DN8386

Retreat® Technical Specification

To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.

25300 AL MOEN D RI VE  NORTH OLMSTED, OH 44070
COR POR ATE H EAD QU AR TERS: (800) 321 -8809  FAX: [phone]
IN TERN ATION AL: [phone]  FAX: [phone]
CU STOMER SERVI CE (U SA): 800-882-0116  F AX: [phone]
WW W.MOEN. COM

Copyright Creative Specialties International Literature #BA1328
