Moen CSI1223 Specifications

Double towel bar posts are constructed

of zinc. Bars are constructed of brass.

 DN8322BN – 24” Double Towel Bar

Brushed Nickel Finish

 DN8322CH – 24” Double Towel Bar

Chrome Finish

Cleaning Instructions:

1. Position the mounting template on the wall in the desired location.

2. Using a level, align the template and tape it to the w all.

3. Drill tw o 5/16” holes at each mounting post location that corresponds to your
product.

4. Remove the template from the wall.

5. Fold ends of the plastic toggle together (see Figure 1) and insert into each hole
in the wall.

6. Lightly tap anchors until flush with the w all.

7. One at a time, insert plastic pin into each of the anchors and lightly tap to
activate anchor (see Figure 2). Remove pin and repeat on all anchors.

8. Remove mounting posts from the product assemblies by loosening each
setscrew .

9. One at a time, place each mounting post over anchors (notch facing downward)
and insert screws through post into anchors.

10. Tighten screws.

11. Assemble the towel bar and posts.

12. While assembled, position each end post w ith setscrew s facing down and place
over both mounting posts. Tighten the setscrew at the bottom of each post.

Stock Number:__________________Double Towel Bar
By Creative Specialties

Materials:

Installation Instructions:

Stock Numbers:

Dimensions:

24” Double Towel Bar

DN8322

Retreat® Technical Specification

To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.

25300 AL MOEN D RI VE  NORTH OLMSTED, OH 44070
COR PORATE H EADQU AR TER S: [phone]  FAX: [phone]
IN TER NATIONAL: [phone]  FAX: [phone]
CU STOMER SER VI CE (USA): 800 -882 -0116  FAX: [phone]
WW W. MOEN .C OM

Copyright Creative Specialties International Literature #BA1327
