Paper Holder is constructed of zinc.

 YB2808BN – Pivoting Paper

Holder

Brushed Nickel Finish

 YB2808CH – Pivoting Paper

Holder

Chrome Finish

 YB2808ORB – Pivoting Paper

Holder

Oil Rubbed Bronze Finish

Cleaning Instructions:

This product features the Pro+Fit Installation Mounting System. If you do not
have the Pro+Fit Installation Template please use the following instructions.
(Note: only one hole is required per mounting post.)

1. Mark on the wall where you want to install the product.

2. Using ¼” drill bit, drill one pilot hole for the post.

3. Position mounting post to wall by inserting wall anchor into pilot hole and

pressing firmly.

4. Make sure that locking tab on mounting post is facing down (6 o’clock).

5. Tighten wall anchor screw while holding mounting post firmly in place. DO

NOT over tighten (6 – 8 full turns will secure the anchor).

6. Attach post by pressing firmly to mounting post until it clicks. (The square

opening at the base of the post must be facing down to match-up with
locking tab.)

If you are mounting any parts into a hard surface snap off the anti-rotation fins

on the back of the mounting post.

Stock Number:______________________Paper Holder
By Creative Specialties

Materials:

Installation Instructions:

Stock Numbers:

Dimensions:

Paper Holder

YB2808

Eva® Technical Specification

To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.

25300 AL MOEN D RIVE  N ORTH OLMSTED, OH 44070
CORPOR ATE HEADQU ARTER S: [phone]  FAX: [phone]
IN TERN ATI ONAL: [phone]  FAX: [phone]
CU STOMER SERVI CE (USA): 800 -882-0116  F AX: [phone]
WW W.MOEN.C OM

Copyright Creative Specialties International Literature #BA1345
